ELECTROSTATIC WARNING

BOARD USE REQUIREMENTS

PROCESSOR FEATURES
Downloaded from Elcodis.com electronic components distributor
The MOD-IO board is shipped in protective anti-static packaging. The board must
not be subject to high electrostatic potentials. General practice for working with
static sensitive devices should be applied when working with this board.
Cables: The cable you will need depends on the programmer/debugger you
use. If you use AVR-PG1, or AVR-JTAG, you will need RS232 cable, if
you use AVR-PG2, you will need LPT cable, if you use AVR-USB-
JTAG, AVR-ISP500, AVR-ISP500-TINY, AVR-ISP500-ISO, AVR-ISP-
MK2 you will need 1.8 meter A-B USB cable.
Hardware: One of Olimex programmers/debuggers – AVR-PG1, AVR-PG2,
AVR-ISP500, AVR-ISP500-TINY, AVR-ISP500-ISO, AVR-JTAG,
USB-JTAG, AVR-ISP-MK2
tool.
Make sure to check if the above programmer/debugger is supported
by the IDE you are going to use.
Software: AVR C Compiler
MOD-IO use 8-bit AVR Microcontroller with 16K Bytes In-System Programmable
Flash, with these features:
High-performance, Low-power AVR
–
Advanced RISC Architecture
–
131 Powerful Instructions – Most Single-clock Cycle Execution
–
32 x 8 General Purpose Working Registers
–
Fully Static Operation
–
Up to 16 MIPS Throughput at 16 MHz
–
On-chip 2-cycle Multiplier
–
High Endurance Non-volatile Memory segments
–
16K Bytes of In-System Self-programmable Flash program memory
–
512 Bytes EEPROM
–
1K Byte Internal SRAM
–
Write/Erase Cycles: 10,000 Flash/100,000 EEPROM
–
Data retention: 20 years at 85°C/100 years at 25°C
–
Optional Boot Code Section with Independent Lock Bits
–
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
or other compatible programming/debugging
® 8-bit Microcontroller
Page 4
AVR-
