Side Chair
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Seat
1 pc.
HARDWARE LIST
Small
Hex Wrench
1 pc.
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
(White Finish)
B.
Leg
1 pc.
Key Wrench
1 pc.
Bolt (long)
4 pcs.(+1 extra)
servicedesk@homestyles-furniture.com
Casual Attire For Today's Home
C.
Leg
1 pc.
Bolt
3 pcs.(+1 extra)
Bolt
4 pcs.(+1 extra)
D.
Back Frame
1 pc
.
Flat Washer
11 pcs.(+1 extra)
Spring Washer
11 pcs.(+1 extra)
Advertisement
Related Manuals for Home Styles Warwick 88 5177 80C
Summary of Contents for Home Styles Warwick 88 5177 80C
- Page 1 Key Wrench Bolt 1 pc. Flat Washer 3 pcs.(+1 extra) 11 pcs.(+1 extra) Small Bolt Bolt (long) Spring Washer 4 pcs.(+1 extra) 4 pcs.(+1 extra) Hex Wrench 11 pcs.(+1 extra) 1 pc. Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319 servicedesk@homestyles-furniture.com...
- Page 2 Assembly Instructions IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Attach Leg (B) and (C) to Seat (A) with Flat Washers ,Spring Washers and Head Cap Bolts.
