Side Chair
IMPORTANT NOTE
.
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
A.
Seat
1 Pc.
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Home Styles Consumer Assistance : www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Leg
1 Pc.
M6x40
Head Cap Bolt (Short)
3 Pcs.(+1 extra)
C.
Leg
1 Pc.
M6x50
M6x70
Head Cap Bolt
Head Cap Bolt (Long)
4 Pcs. (+1 extra)
4 Pcs.(+1 extra)
D.
Back Frame
1 Pc.
Flat Washer
11 Pcs. (+1 extra)
Spring Washer
11 Pcs. (+1 extra)
