IXW-MAA-SOFT Programming Guide
Page 2
Page 3-4
Page 4-5
Page 6
ATTENTION:
This is an abbreviated programming manual addressing basic program settings for an IXG Series system using the
IXG Support Tool. A complete set of instructions
www.aiphone.com/ix-ixg-series, along with additional literature and media.
IXG SERIES
IP Video Intercom
IXG Support Tool version 5.0.1.1
Table of Contents
Introduction and Adding IXW-MAA and IX-SOFT to the System
Network and SIF Settings
Relay Output Settings
Uploading and Exporting the Setting File
(IXG Operation Manual / IXG Support Tool Setting Manual)
can be found at
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Aiphone IXG Series
Summary of Contents for Aiphone IXG Series
- Page 1 Page 6 Uploading and Exporting the Setting File ATTENTION: This is an abbreviated programming manual addressing basic program settings for an IXG Series system using the IXG Support Tool. A complete set of instructions can be found at (IXG Operation Manual / IXG Support Tool Setting Manual)
- Page 2 Example: Connection(S), Upload Settings. This guide assumes that the rest of the system has already been programmed in IXG Support Tool. If this is not the case, follow the IXG Series Complete Quick Start Programming Guide here: https://www.aiphone.com/IXG-Series-QuickStartGuide IXG Support Tool can be downloaded here: https://www.aiphone.com/IXG-SupportTool...
-
Page 3: Network Settings
Network Settings Navigate to Network Settings, IP Address. This will display the stations and their network information. These can be adjusted as needed, including for the IX-SOFT instances. Record the IP address of the IXW-MAA-SOFT for the next step, then click Save If an instance of IX-SOFT was created, it is recommended to make sure that the proper NIC on the PC is selected to connect with the rest of the system. - Page 4 List applied to one of the stations found in Station Search. To associate a station that came up in station search, select the desired settings from the Station Settings List, the physical station under the Station List, and click Apply 4 | IXG Series - IXW-MAA-SOFT Programming...
- Page 5 Association Settings (continued) The process shown on the previous page is the preferred method for associating the IXW-MAA-SOFT itself, and can be used to configure an instance of IX-SOFT running on the programming PC. However, other PCs on the network may not be discovered by station search. These can be associated manually. First, make sure that IX-SOFT is open and running on the other PCs.
- Page 6 IX-SOFT to receive its software license. Use these settings for all other IX | IXG Series stations that will send signals to the IXW-MAA-SOFT: Program Type: 0100 IPv4: The IP address for the IXW-MAA-SOFT...
-
Page 7: Relay Output Settings
Relay Output Settings The configured stations will now send SIF signals when their relay output is triggered, and the IX-SOFT instances will reach out to the IXW-MAA-SOFT for their licenses. If SIF settings were only configured for IX-SOFT instances, skip to page 7 for instructions on uploading the settings. To configure the outputs on the IXW-MAA-SOFT for door release, navigate to Option Input / Relay Output Settings, Relay Output. -
Page 8: Export System Configuration
The entire folder is needed to restore the system. For more details about the features and information above, please contact Technical Support. Aiphone Corporation | www.aiphone.com | (800) 692-0200 8 | IXG Series - IXW-MAA-SOFT Programming...
