IXW-MAA-SOFT Programming Guide
Page 2
Page 3-4
Page 4-5
Page 6
ATTENTION:
This is an abbreviated programming manual addressing basic program settings for an IXG Series system using the
IXG Support Tool. A complete set of instructions
www.aiphone.com/ix-ixg-series, along with additional literature and media.
IXG SERIES
IP Video Intercom
IXG Support Tool version 5.0.1.1
Table of Contents
Introduction and Adding IXW-MAA and IX-SOFT to the System
Network and SIF Settings
Relay Output Settings
Uploading and Exporting the Setting File
(IXG Operation Manual / IXG Support Tool Setting Manual)
can be found at

Advertisement

loading
Need help?

Need help?

Do you have a question about the IXG Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiphone IXG Series

Summary of Contents for Aiphone IXG Series

  • Page 1 Page 6 Uploading and Exporting the Setting File ATTENTION: This is an abbreviated programming manual addressing basic program settings for an IXG Series system using the IXG Support Tool. A complete set of instructions can be found at (IXG Operation Manual / IXG Support Tool Setting Manual)
  • Page 2 Save To finish the initial setup for the added IX-SOFT instances and I/O adaptor, use the IXG Series Complete Quick Start Guide linked above and follow the steps listed on pages 3-10 for initial setup and programming. This will cover providing the stations with network information, which is needed for the next step of this guide.
  • Page 3 Network and SIF Settings Navigate to Network Settings, IP Address. This will display the stations and their network information. These can be adjusted as needed. Record the IP address of the IXW-MAA-SOFT for the next step, then click Save Navigate to Function Settings, SIF. Set SIF Functionality to Enable for each station that will send signals to the IXW-MAA-SOFT, as well as for the IX-SOFT instances that will get their licenses from the IXW-MAA-SOFT.

  • Page 4: Relay Output Settings

    Network and SIF Settings (continued) Use these settings for all other IX | IXG Series stations that will send signals to the IXW-MAA-SOFT: Program Type: 0100 IPv4: The IP address for the IXW-MAA-SOFT Destination Port: 65014 SSL: Enable Connection: Socket...
  • Page 5 Relay Output Settings (continued) Scroll right to the column labeled Contact Change SIF Event. Click to bring up a list of stations. Select Station Choose one station to assign to this relay on the IXW-MAA-SOFT, then click . Click to finalize the Save settings, then repeat these steps for each output to be configured.

  • Page 6: Export System Configuration

    The entire folder is needed to restore the system. For more details about the features and information above, please contact Technical Support. Aiphone Corporation | www.aiphone.com | (800) 692-0200 6 | IXG Series - IXW-MAA-SOFT Programming...
