Summary of Contents for ekwb EK-Velocity sTR4
- Page 1 EK-Velocity sTR4 CPU WATER BLOCK USER GUIDE 2nd Revision, July 29th 2021...
- Page 2 The following instructions are subject to change without notice. Please visit our website at www.ekwb.com for updates. Before installation of this product, please read important notice, disclosure, and warranty conditions that are printed on the back of the box.
-
Page 3: Table Of Contents
TABLE OF CONTENT GENERAL INFORMATION ON WATER BLOCK COMPATIBILITY SUPPORT AND SERVICE BOX CONTENTS SOCIAL MEDIA WATER BLOCK DIMENSIONS TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS QUICK INSTALLATION GUIDE INSTALLING THE WATER BLOCK CONNECTING THE RGB LED STRIP (for full nickel version) CONNECTING THE RGB LED STRIP CONNECTING THE D-RGB MODELS CONNECTING THE D-RGB LED STRIP... -
Page 4: General Information On Water Block Compatibility
GENERAL INFORMATION ON WATER BLOCK COMPATIBILITY This CPU liquid cooling unit is pre-assembled for use with modern AMD desktop socket type motherboards. By default (out of the box) this water block supports the following CPU sockets: - AMD TR4 socket - AMD SP3 socket - 4 -... - Page 5 BOX CONTENTS Thermal grease (1 pc) EK-Velocity sTR4 CPU water block (1 pc) - 5 -...
-
Page 6: Water Block Dimensions
WATER BLOCK DIMENSIONS 30.8 mm 85.4 mm 14.3 mm - 6 -... -
Page 7: Technical Specifications And Water Block Parts
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS Technical Specification: - Dimensions (L x H x W): 117x85x31 mm - D-RGB cable length: 500 mm - D-RGB LED count: 6 - D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Position EAN Description Quantity 100612 TOP PLATE - Acetal 100611 TOP PLATE - Plexi... - Page 8 Technical Specification: - Dimensions (L x H x W): 117x85x31 mm - D-RGB cable length: 500 mm - D-RGB LED count: 1 - D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Position EAN Description Quantity 100614 TOP PLATE - Nickel 100618 STICKOUT - Black 100620 MOUNTING BRACKET - sTR4 100685 COLDPLATE - Nickel...
- Page 9 INSTALLING THE WATER BLOCK STEP 1 Cleaning the CPU: Wipe the CPU’s contact surface (by using non– abrasive cloth or Q-tip, as shown on sample photo). Non-abrasive Cloth Applying thermal compound: EK recommends blob or line method of applying the enclosed EK-TIM Ectotherm (1g) thermal compound to the CPU heatspreader (IHS) Applying thermal compound: On a clean IHS, apply a line of thermal compound and spread it over the whole CPU heat spreader...
- Page 10 STEP 2 Align the water block properly on the motherboard, because the screws MOUNTING are not positioned in a square pattern. SCREW Before proceeding with the installation, it is mandatory to remove the protective foil from the backside of the water block.
- Page 11 CONNECTING THE RGB LED STRIP (for full nickel version) CONNECTING THE RGB LED STRIP STEP 1 Plug the 4-pin connector from the water block and fan’s RGB LED light to the RGB HEADER on the motherboard. The LED will work if the pin layout on the header is as follows: +12V G R B.
- Page 12 CONNECTING THE D-RGB MODELS CONNECTING THE D-RGB LED STRIP STEP 1 Plug the 4-pin connector from the water block’s D-RGB LED light to the DRGB HEADER on the motherboard. The LED will work if the pin D-RGB HEADER layout on the header is as follows: +5V, Digital, empty, Ground. Please ensure that the arrow indicated on the connector is RGB HEADER plugged into the +5V line as indicated on your motherboard.
-
Page 13: Support And Service
SUPPORT AND SERVICE In case you need assistance or wish to order spare parts or a new mounting mechanism, please contact: https://www.ekwb.com/customer-support/ For spare parts orders, refer to the page with “TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS” where you can find the EAN number of each part you might need.
