AB950

AB950_950744_OM_20240419

AIR BIKE

Online Support

If you require assistance or are

experiencing issues with your

Spirit Machine, please contact

customer care for additional help.

1-800-258-8511

questions@spiritfitness.com

Warranty Registration

Scan to quickly and easily

Fitness machine.

Table of Contents

Need help?

Do you have a question about the Air Bike and is the answer not in the manual?

Questions and answers

Laurie Madsen

February 13, 2025

Change battery in bike

1 comments:

Mr. Anderson

May 14, 2025

To change the battery in a Spirit Air Bike:

1. Locate the battery compartment on the back side of the console.
2. Open the battery compartment.
3. Insert 4 AA batteries (not included) into the compartment.
4. Close the battery compartment securely.

The console will operate once the batteries are installed.

This answer is automatically generated

Summary of Contents for Spirit Air Bike

Page 1 Online Support If you require assistance or are experiencing issues with your Spirit Machine, please contact customer care for additional help. 1-800-258-8511 questions@spiritfitness.com Warranty Registration Scan to quickly and easily register your new Spirit AB950 Fitness machine. AIR BIKE AB950_950744_OM_20240419...
Page 3: Table Of Contents
Maintenance & Care ............27 Parts and Assembly Exploded View Diagram ..........31 Parts Included ..............5 Parts List ................32 Parts of Your Air Bike ............6 Warranty Pre-Assembly ............... 7 Warranty ................34 Assembly ................8 Setting Up Your Unit ............12 Using Your Bike ..............14...
Page 4: Product Registration
PRODUCT REGISTRATION Congratulations on your new Air Bike, and welcome to the Spirit WARRANTY REGISTRATION Fitness family! Thank you for your purchase of this quality unit from Spirit Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
Page 5: Product Labels
PRODUCT LABELS SERIAL NUMBER STICKER SERIAL NUMBER This sticker will be found near the rear stabilizer. Please re- cord the number below the barcode for the purpose of regis- tering your Bike’s warranty. XXXXXXXXXXXXXXXX (870) 935-1107 PROPOSITION 65 WARNING This sticker will be found near the rear stabilizer. The State of California requires us to inform you that this unit was manufactured using chemicals that could cause harm with improper use.
Page 6: Safety Instructions
SAFETY INSTRUCTIONS To reduce risk of injury to persons: Please ensure that you review and adhere to the user Read all instructions before using this appliance. weight restrictions of your new machine. Failure to do so may result in serious injury or damage to your WARNING - To reduce the risk of injury to persons: This exercise equipment is not intended for use by persons with reduced machine.
Page 7: Parts Included
PARTS INCLUDED STEP1 STEP3 #81-5/16"x20x3T(2pcs) #50-3/8"x53L(2pcs) #71-3/8"x25x2T(4pcs) #75-M6(2pcs) #84-3/8"x2-1/4"(2pcs) #135-3/8"(2pcs) #136-8x20L(2pcs) #159-M10x40L(2pcs) STEP2 STEP4 TOOLS #93-Phillips Head Screw driver (1 pc) #90-M6x10L(3pcs) #58-M5x12L(4pcs) #94-10mm Wrench (1 pc) #157-#8 L Allen Wrench (1 pc) #100-14/15mm Wrench (1 pc) #158-13/15mm Wrench (1 pc) #90-M6x10L(2pcs) #126-#4 L Allen Wrench (1 pc)
Page 8: Parts Of Your Air Bike
PARTS OF YOUR BIKE A. LCD Screen B. Hand Grips C. Foot Peg D. Console E. Seat Adjustments F. Swing Arm G. Shroud H. Seat I. Flywheel J. Pedal K. Transport Wheels L. Levelers...
Page 9: Pre-Assembly
PRE-ASSEMBLY 1. Place all parts from the box in a cleared area and position them on the floor in front of you. 2. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
Page 10: Assembly
ASSEMBLY - STEP ONE Use the WRENCH (100) to fasten the FRONT STABILIZER (2) onto the MAIN FRAME (1) with two sets of HEX HEAD BOLTS (84) and FLAT WASHERS (71). Use the WRENCH (100) to fasten the REAR STABILIZER (5) onto the MAIN FRAME (1) with two sets of CARRIAGE BOLTS (50), FLAT WASHERS (71), AND CAP NUTS (135).
Page 11 ASSEMBLY - STEP TWO Insert the CABLE (23) through the hole of the CONSOLE BASE (10) carefully. 2. Use the SCREW DRIVER (93) to fasten the CONSOLE BASE (10) onto the MAIN FRAME (1) with three PHILLIPS HEAD SCREWS (90).
Page 12 ASSEMBLY - STEP THREE Attach the LEFT HANDLEBAR (3) and right HANDLEBAR (4) with the ROCKER LINKS (8) on both sides of the main frame with two sets of BOLTS (136), ROD END BEARINGS (64), FLAT WASHERS (81), NYLON NUTS (75). Use the WRENCH (94) and the ALLEN WRENCH (126) to fasten all bolts and washers.
Page 13 ASSEMBLY - STEP FOUR Connect the CABLE (23) to the CONSOLE SET (34) carefully. Use a SCREW DRIVER (93) to fasten the CONSOLE SET (34) onto the CONSOLE BASE (10) with four SCREWS (58). Use a WRENCH (100) to fasten the LEFT PEDAL (45L) onto the LEFT CRANK ARM (16L) and RIGHT PEDAL (45R) onto the RIGHT CRANK ARM (16R) respectively.
Page 14: Seat Adjustments
SETTING UP YOUR AIR BIKE Testing Your Bike Seat Adjustments Use this checklist to perform the bike test procedure. • Proper bike setup gives you a more comfortable ride and reduces your risk of injury. To adjust the seat height: •...
Page 15: Moving And Leveling
SETTING UP AND MOVING YOUR BIKE Moving and Leveling • To move the bike to a new location: Lift the bike from the rear and use the front wheels (located on the front leg, below the handlebar) to roll the bike from one location to another.
Page 16: Using Your Bike
USING YOUR BIKE Your Air Bike is easy to use. There are no resistance knobs Before Beginning to adjust as the resistance comes from the isokinetic Be sure the seat is adjusted for your body size and comfort before resistance created by the movement of air with the fan- beginning your workout.
Page 17: About Your Machine
ABOUT YOUR MACHINE Always use care and caution when operating your Be sure to follow Spirit Fitness on your favorite social machine. Follow instruction in this manual to ensure safe media platforms to view and share the latest fitness videos, operation and maintenance of your Air Bike.
Page 18: Console Screen - Overview
CONSOLE SCREEN - OVERVIEW INTERVAL DISPLAY PANEL QUICK MODE BUTTONS QUICK MODE BUTTONS TIME, DISTANCE, CALORIES, WATTS, SPEED, RPM DISPLAY PANEL BLUETOOTH BUTTON HEART RATE DISPLAY PANEL CONTROL KEYPAD...
Page 19 CONSOLE SCREEN - BUTTONS The Quick Mode buttons will go into the asso- ciated mode immediately The ▲/▼ Arrow buttons allow the user to increase or decrease console values The Start button will go into a mode; restart a paused mode or temporarily pause a running mode The Enter button is used to confirm a value as mak-...
Page 20: Features
FEATURES - CONSOLE DISPLAY INTERVAL DISPLAY The Interval Display Panel will show all details for the Interval 20/10, Interval 10/20 and Interval Custom mode. In upper banner will tell which interval mode is operating. This display will instruct whether the current operating interval is in WORK or REST period. The TOTAL TIME launch will show the total run time while the large numeric display will show the WORK or REST segment time.
Page 21: Workout Summary
FEATURES - CONSOLE SETUP BATTERY INSTALLATION SLEEP MODE The console operates on 4*AA batteries (not included). The After 60 seconds of inactivity, the console will switch into the power- battery compartment is on the back side of the console. saving Sleep Mode. The display will switch off. Rotating the pedals or pressing any button on the console will launch the Ready Mode.
Page 22: Heart Rate Chest Strap
HEART RATE CHEST STRAP* (NOT INCLUDED) 1. Attach the transmitter to the elastic strap using the Note: The transmitter is automatically activated when it detects interlocking key. activity from the user’s heart. Additionally, it automatically 2. Adjust the strap as tightly as possible as long as the strap deactivates when it does not receive any activity.
Page 23: Chest Strap Warning
CHEST STRAP WARNING* (NOT INCLUDED) Erratic Operation Caution! Do not use this Air Bike for Heart Rate programs unless a steady, solid Actual Heart Rate value is being displayed. High, wild, random numbers being displayed indicate a problem. Areas to look for interference which may cause erratic heart rate: 1.
Page 24: Heart Rate Exertion
HEART RATE EXERTION The old motto, “no pain, no gain”, is a myth that has been The two most popular reasons for, or goals, of exercise are cardiovascular overpowered by the benefits of exercising comfortably. A great deal fitness (training for the heart and lungs) and weight control. The black of this success has been promoted by the use of heart rate monitors.
Page 25 HEART RATE - PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how Rating Perception of Effort hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humid- ity, the time of day, the last time you ate and what you ate all contribute to the intensity at which you should workout.
Page 26: Programs
PROGRAMS Quick Start Interval Custom Mode The Quick Start Mode automatically begins displaying workout Interval Custom Mode allows the length of the work/rest segments information as soon as pedaling begins. to be customized as well as the total number of intervals. Launch: Press the Interval Custom Mode button.
Page 27 PROGRAMS Target Time, Distance, Calories Mode Target Heart Rate Mode Target Time, Target Distance and Target Calories Mode The Target Heart Rate Mode allows the maximum beats per allows the target goal of each value to be customized. minute (BPM) target to be customized to maximize cardiovascular training, according to the user’s age The Heart Rate Mode Launch: Press the desired Target button (TIME, DISTANCE, calculates the maximum heart rate value to optimize the training...
Page 28 PROGRAMS Bluetooth The Bluetooth function will only connect when the console is in the Stop Mode. When the console is in Stop Mode, press the Bluetooth button. The Bluetooth symbol will flash on the display. Connect to the console through the Bluetooth function on your device.
Page 29: Maintenance
Working on this product will require basic and/or sometimes 75% solution. specialty tools based on the type of service that will be performed at any time. To assist, Spirit Fitness recommends • For more details on sanitization, or to learn how to make your...
Page 30: Weekly Maintenance
Have an experienced rider ride each bike to Dry the Air Bike after each use to remove sweat and identify and help diagnose any vibration, noises, and any “unusual” moisture. It is best to use a liquid non-abrasive cleaner feeling from the drive belt.
Page 31 MAINTENANCE & CARE - CONTINUED Inspect major moving parts that require constant proper torque. Frame Care Loose or mis-adjusted parts can result in personal injury or damage It is recommended that the frame on the bike is sealed from to the bike. Check the following parts for security and/or proper sweat impurities that may speed the corrosion process at torque.
Page 32: Engineering Mode
ENGINEERING MODE Press Start and Enter buttons for 2 seconds to enter Engineering Audio ON/OFF Mode. The console will also beep for 1 second. DISTANCE banner • Under Engineering Mode of the Audio ON/OFF setting. The will blink first. Press▲ or ▼ button to select setting section. SOUND sign will blink.
Page 33: Exploded View Diagram
EXPLODED VIEW DIAGRAM...
Page 34: Parts List
PARTS LIST Main Frame Handgrip End Cap Front Stabilizer M20 × P1.0 × 12.5T_Nylon Nut Handle Bar (L) Sleeve Handle Bar (R) Pedal (L.R) Rear Stabilizer Transportation Wheel Seat Slider Pedal Bar Sliding Seat Mount 3/8" × 53L_Carriage Bolt Armrest Handle(L) Rocker link Console Base Armrest Handle(R)
Page 35 PARTS LIST M6 × 57L_Idle Wheel Screw Connecting Arm Cover (L) M6 × 6T_Nylon Nut Ø6_Nut Stopper 3/8" × UNF26 × 7T_Nut M6 × 40L_Idle Wheel Screw M6 × P1.0 × 10L_Button Head Socket Bolt Ø14 × Ø35 × 3T_Flat Washer M8 ×...
Page 36: Warranty
Effective April 23, 2024- AB950 Air Bike LIMITED WARRANTY Spirit Fitness warrants all its Air Bike parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’ responsibilities include providing new or remanufactured parts, at Spirit Fitness’...
Page 37 9. Warranties outside of the United States may vary. Please contact your local dealer for details. Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by Spirit Fitness, Inc. This warranty...
Page 38 4. Spirit Fitness’ obligation under this warranty is limited to repairing or replacing, at Spirit Fitness’ option, the product through one of our authorized service centers. All repairs must be preauthorized by Spirit Fitness. If the product is shipped to a service center freight charges to and from the service center will be the customer’s responsibility.
