Truflo — PPB Series
®
Battery Operated Digital Pressure Gauge
LCD Display
with Backlight On|OFF Option
Battery Charge Indicator
Carbon Zinc Battery (3A)
Process Connection
SS | PP | PVDF

Technical Specifications

Sensor Diaphragm
Measured Fluids
Accuracy
Repeatability
Battery
Current Consumption
Pressure Unit
Display Range
Sampling Frequency
Thermal Drift
Housing Materials
Process Connection
Operating Temperature
Protection Class
Model Selection
Part Number
PPB-10-PP-K
24-0388 © Icon Process Controls Ltd.
Pressure Units
Psi | Bar | KPa | MPa | Kg/Cm
Ceramic (AL O 96%) | SS316L*
2 3
H O | Liquid Chemicals | Gases
2
Ceramic : ± 1.0% of FS @ 25ºC Max. | SS316L : ± 0.3% of FS @ 25ºC Max.
Ceramic : ≤± 1.0% FS Max. | SS316L : ≤± 0.3% FS Max.
Carbon Zinc Battery (3A)
2µA max.
Psi | Bar | KPa | MPa | Kg/cm
-19999 ~ 99999
1/4 Hz | 1 Hz | 16Hz
Ceramic : ± 0.1% FS/ºC | SS316L : ± 0.05% FS/ºC
PP
SS : 1/4" - 1/2" MNPT | 1/2" FNPT || PVDF & PP : 1/2" MNPT | 1/2" FNPT
-40 ~ 248 F | -40 ~ 120 C
o o
IP67 | NEMA 4X
Description
0-145 Psi ,1/2" MNPT, PPB Digital Pressure Gauge
2
2
3 x AAA Batteries
Inside
Battery Cover Screw
Remove the Cover to Replace
Batteries
*Optional
