CHARACTERISTICS:
The "HD674-A004" series are rugged devices used to interface Modbus devices with EtherNet/IP network.
With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal,
vertical, oblique).
It is possible to have the device varnished or totally resined and also in both cases with "Mini-Fit®" connectors or "AMP SuperSeal 1.5"
connectors. If is resined, the enclosure, like the "AMP SuperSeal 1.5" connectors, is waterproof.
All the four series have these characteristics:
Triple 4kV isolation between Power Supply / EtherNet/IP / Modbus;
Varnished / Resined (optionally);
Wide power supply input range: 8...26V AC | 10...40V DC;
Mini-Fit® / AMP SuperSeal 1.5 connectors;
Metal enclosure with fixing lugs;
Possibility to use Metal hose clamps for fixing it without using lugs;
Microprocessor for data control;
Wide temperature range: -40°C / 105°C (-40°F / 221°F).
CONFIGURATION:
You need Compositor SW674-A004 software on your PC in order to perform the following:
Define the parameter of Ethernet/IP line;
Define the parameter of Modbus line;
Determinate which Ethernet/IP byte transfer in Modbus and vice versa;
Update the device.
