REVO I
2PH from 100A to 700A
Caution: this procedure must be performed only by qualified persons.
Branch Circuit
Protection
L3
L2
L1
3
T3
T2
T1
NOTE:
1 The user installation must be protecting by electromagnetic circuit breaker or by fuse isolator.
The Fuse must be branch circuit protection. For UL any listed UL branch circuit fuse would be acceptable
as an external fuse, following national electric code guide for resistive heating of 125% load current rating
to protect external wires.
2 For SSR input connection follow next page schematic.
3 IMPORTANT! Starting Strategy (Enable):
1: Feed the unit with L1-L2-L3 power voltage supply
2: Feed the auxiliary supply
3: Close the Enable contact to start with the regulation
Fuse
1A Max
Fan Supply
230Vac Standard
115Vac Option
M1
24Vdc Option
See Order Code
AUX
AUX
18
20
15
9
10 13
M1
Indicative connection diagrams. Refer to local
regulations for proper system protection.
MICRO
USB 2.0
16
5
6
12
11
4
10
9
10
Analog Inp.1
Analog Inp.2
Analog SetPoint
Reference
Ext.FeeDBack
28
User's manual
4
11
3
1
2
8
NC
NO
C
Function
Thermal
SC/HB
B-
9
7
A+
