CD Automation REVO I 2PH User Manual page 25

REVO I
2PH from 100A to 700A
8.5.1 Bar dimensions S14 (300-500A)
Current
300A (S14) 71mm
400A (S14) 71mm
450A (S14) 71mm
500A (S14) 71mm
600A (S14) 54mm
700A (S14) 54mm
A B B
E E
M M
300 to 400A
A B B
E E
F F
2xM 2xM
450 to 500A
A B C
60mm 45mm
60mm 45mm
60mm 45mm
60mm 45mm
76mm 21mm
76mm 21mm
A
E
C D
G
M
To other
A
screw
E
C
F
D
G
2xM
To other
screw
D E
57mm 30mm
57mm 30mm
57mm 30mm
57mm 30mm
37mm 66mm
37mm 66mm
25
User's manual
BAR
H
F G H
- 350mm 174mm
- 350mm 174mm
- 350mm 174mm
- 350mm 174mm
35mm 390mm 165mm
35mm 390mm 165mm
M
M10
M10
M10
M10
M10
M10
