REVO I
2PH from 100A to 700A
6

Technical Specifications

6.1 General features

Operative voltage:
Cover and Socket material:
Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage:
Order code RI2_ _ _ -_1 = line voltage 100/120V transformer range 90:135V (8 VA Max)
Order code RI2_ _ _ -_2 = line voltage 200/208/220/230/240V transformer range 180:265V (8 VA Max)
Order code RI2_ _ _ -_5 = line voltage 380/400/415/440/480V transformer range 342:528V (8 VA Max)
Relay output for Heater Break Alarm
(only with HB option):

6.2 Input features

Digital Input:
Volt Analogic input:
Current Analogic input:
Potentiometer:
Logic input SSR (Fast Enable):

6.3 Output features (power device)

Voltage Repetitive peak
Current
range reverse voltage
(A) (V) (480V)
100A 24÷600 1200
125A 24÷600 1200
150A 24÷600 1200
200A 24÷600 1200
300A 24÷600 1200
400A 24÷600 1200
450A 24÷600 1200
500A 24÷600 1200
600A 24÷600 1200
700A 24÷600 1200
480V +10% max -10% min; 600V +10% max -10% min
Polymeric V2
AC-51 AC-55b
20
Load in Delta, Load in Star
0.5A a 125Vac
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 0,5Hz max
0 ÷ 10Vdc impedance 15 kΩ
0 ÷ 20mA impedance 100 Ω
4 ÷ 20mA impedance 100 Ω
10 kΩ min.
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
duty cycle min. 100 ms max 3Hz
Latching Max peak
current one cycle
(600V) (mAeff) (10msec.)
1600 600 1900
1600 600 1900
1600 400 1900
1600 400 1900
1600 200 7800
1600 200 7800
1600 200 7800
1600 200 8000
1600 1000 178000
1600 1000 17800
2
Leakage I t value
current for fusing
(mAeff) tp=10msec
15 16940
15 16940
15 27500
15 84700
15 73500
15 149000
15 215600
15 215600
15 294000
15 294000
17
User's manual
Frequency Isolation
Power loss
range Voltage
(Hz) I=Inom (W)
47÷70 290 3000
47÷70 398 3000
47÷70 409 3000
47÷70 598 3000
47÷70 903 3000
47÷70 1092 3000
47÷70 1259 3000
47÷70 1407 3000
47÷70 1528 3000
47÷70 1753 3000
Vac
