Preface - Circontrol WALLBOX SMART Series Installation Manual

CCL-WBM-SMART-MID-16A

1 PREFACE

THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
This manual provide commissioning information for Wallbox, which has been designed
and tested to allow electric vehicle charging, specified in IEC 61851.
This document has different sections where describes electrical components inside the
charge station and a step-by-step installation procedure.
Certification

Complies with IEC 61851, Electric vehicle conductive charging system (IEC
61851-1 and IEC 61851-22)

Complies with IEC 62196, Plugs, socket-outlets, vehicle couplers and vehicle
inlets (IEC 62196-1 and IEC 62196-2).

Directives 2004/108/EC, EMC; 2006795/EC, Low voltage Directive

RFID complies with ISO 14443A/B
SAFETY INFORMATION IN THIS DOCUMENT
ELECTRIC RISK!
Take precautions to make the electrical connection
inside the unit.
Unit must be disconnected from any power source
during commissioning.
ATTENTION!
Indicates that the damage to property can occur if
appropiate precautions are not taken.
