6.3.3 RECOMMENDATIONS

Ethernet communications wiring is optional; the unit can operate as standalone.
Please provide communications to the unit if it is required to remote monitoring or use
OCPP integration. Use only one of the following interfaces:
- Ethernet communications (all models).
- Integrated 3G modem (only 3G models).
Please take attention into the following instructions:
Ethernet communications cable (if necessary)
should be introduced at the top of the unit and
power supply wires below the unit.
Power wires and communications wires must be
installed using different electrical pipes to ensure
properly function of the charge point.
15
INSTALLATION MANUAL
*
*
Optional
