CCL-WBM-SMART-MID-16A

6.5.2 WIRING

SINGLE-PHASE WIRING
-
Perform the 230V AC Single-phase connection as shown.
-
Do not forget to connect the ground cable (PE) to the supply terminal.
L
N
PE
20
INSTALLATION MANUAL
