AMGO MC-1200P Installation And Service Manual

Motorcycle lift

Advertisement

Quick Links

Model: MC-1200P
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must not ate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
Motorcycle Lift
!
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.
DANGER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-1200P and is the answer not in the manual?

Questions and answers

Summary of Contents for AMGO MC-1200P

  • Page 1 Motorcycle Lift Model: MC-1200P △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and safety precautions could result in serious Cargo Claims injury or even death. Make sure all other If there is any missing or damaged operators also read this manual.
  • Page 2: Table Of Contents

    CONTENTS PROFILE ..................1 IMPORTANT SAFETY INSTRUCTIONS ..........3 I. PRODUCT FEATURES AND SPECIFICATIONS ........5 II. INSTALLATION REQUIREMENT ............. 7 III. INSTALLATION STEPS ............... 9 IV. EXPLODED VIEW ..............12 V. TEST RUN ................15 VI. OPERATION INSTRUCTIONS ............. 17 VII. MAINTENANCE SCHEDULE ............19 VIII.
  • Page 3: Profile

    PROFILE This instruction manual is specially prepared for you. Your new lift is the product of over a decade of continuous research, testing and development and is the most technologically advanced lift on the market today. Please make sure to read through this manual before operating the lift. Record the information on the nameplate label here: Model No.:_______________ Serial No.:_______________...
  • Page 4: Safety Warning Label

    SAFETY WARNING LABEL Fig.1...
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Ensure product installation complies with all applicable local regulations and rules, such as Occupational Safety and Health Administration regulations and electrical codes.
  • Page 6 the lounge or basement. 16. Maintain with care. Keep the machine clean for better and safer operation. Perform proper lubrication and maintenance procedures according to the manual. Keep handles or buttons clean, dry, and free of oil. 17. Stay alert. Use common sense to observe what you are doing and stay alert. 18.
  • Page 7: Product Features And Specifications

    I. PRODUCT FEATURES AND SPECIFICATIONS (See Fig.2) Fig .2 MC-1200P: FEATURES OF MODEL ● Hydraulic cylinders, designed and made by USA standard, utilizing oil seal in cylinder. ● Self-lubricating UHMW Polyethylene sliders and bronze bush. ● Non-skid diamond platforms. ● Automatic safety release system.
  • Page 8 MODEL MC-1200P DIMENSION AND SPECIFICATION Fig .3 Fig.1 Lifting Max Lock Overall Runway Overall Minimum Model Capacity Height Height Length Length Width Height 42 29/32" 40 9/16" 106 5/16" 88 19/32" 29 17/32" 6 3/32" 1200lbs MC-1200P (1090mm) (1030mm) (2700mm)
  • Page 9: Installation Requirement

    II. INSTALLATION REQUIREMENT A. TOOLS REQUIRED Rotary Hammer Drill (Φ10) Ratchet Spanner with Socket #   :(28 Pliers  Screw  English Spanner (12")  Wrench Set # # # #  :(13 、15 、17 、19 Fig.4...
  • Page 10 B. Equipment storage and installation requirements. 1.Store the equipment in a dry, non-moldy, non-flammable environment. 2.The lift is only approved for indoor installation and use, and outdoor installation is prohibited. 3.When installing the device, take safety precautions according to the instructions to avoid device damage.
  • Page 11: Installation Steps

    III. INSTALLATION STEPS A. Check the parts before assembly to make sure all the parts are completed. 1. Packaged cargo (lift, drive-in ramp,pneumatic pump, tool tray, wheel vise). Move the parts aside, open the outer packing and check the parts according to the shipment parts list. see Fig.6 Fig.6 2.
  • Page 12 B. Place the lift and control cabinet to the installation site, connect the oil hose and tighten the fitting (see Fig.8) Fig.8 C. Install adjustable wheel vise. 1.The wheel vise can be installed in two positions on the platform, allowing users to choose their preferred installation position.(See Fig 9) Fig.9...
  • Page 13 3. Exploded view of wheel vise (See Fig 11) 31 32 Fig.11 D. Install Optional Width Extension Kit(MC001). See Fig.12 Fig.12 E. Install Optional Length Extension Kit (MC002) . See Fig 13 Note: Connect the length extension kit to one of the wheel vise install holes on the platform. Move the wheel vise to extension platform.
  • Page 14: Exploded View

    IV. EXPLODED VIEW MODEL:MC-1200P Fig.14...
  • Page 15 Parts list of Lift Description Note Item Part# QTY. 11720022 Drive-in ramp 10217069 Hex bolt M12*30 11720723 Cover plate of platform 11720020-01 Platform 86010782 Wheel vise assy. M10*25 Hex bolt (with flat washer,lock 1003085008 washer,nut) 11720023-01 Outer scissor 11720024-01 Inner scissor 10650024 Nylok nut M16 1103082011A...
  • Page 16 Description Item Part# Note QTY. 10209066 Hex nut M16 1103083012 Adjusting pin 1103083007 Handle connecting board 1103083017 Control handle 10410040 Socket bolt M12*110 10440042 Oil hose 10209064 Straight fitting 1/4JIC(M)*1/4NPT(M) Pneumatic hydraulic pump 10670002 11720100 Tool tray bracket 10206156 Tool tray 10620071 Anchor bolt M10*100 Straight fitting 3/8NPT(M)*1/4JIC(M)
  • Page 17: Test Run

    Parts for cylinder Note Item Part# Description QTY. 20-1 11640030A Bore Weldment 20-2 11640031A Piston Rod 20-3 10201034 Bleeding Plug 20-4 11201033 Head Cup 20-5 10209078 Dust Ring 20-6 10201032 O Ring 20-7 10201035 O Ring 20-8 11201028 Piston 20-9 10206069 O Ring 20-10...
  • Page 18 ⚠ WARNING Don’t lift vehicles over the rated capacity of the lift. Please Don’t leave the lever until the safety lock of the lift is locked. Only trained personnel can raise and lower the lift. . Adjust height of safety device Rise the lift to the highest position (See Fig.18), rotating the safety lock handle according to the direction of arrow.
  • Page 19: Operation Instructions

    VI. OPERATION INSTRUCTIONS A. Preparation work before operation: 1. Please prepare the air supply unit in advance. 2. An oil-water separator must be installed on the air supply unit. It may be damage without oil-water separator . 3. Hydraulic pump has been filled up with the hydraulic oil. It doesn’t need to add any more hydraulic oil, unless it leaks the hydraulic oil during transportation.
  • Page 20 pneumatic pump pedal, start to fill gas into the oil pump, and the machine rises. Press the "RELEASE" of the pneumatic pump pedal after rising to the proper position, meanwhile lock on the nearest safety lock position. Then begin the maintenance operation. (Put up the foot stool Of motorcycle) Fig.21...
  • Page 21: Maintenance Schedule

    VII.MAINTENANCE SCHEDULE A.Monthly maintenance: 1. Check all connectors, bolts and pins to insure proper mounting. 2. Make a visual inspection of all hydraulic hoses/lines for possible wear or leakage. B.Every six months: 1. Make a visual inspection of all moving parts for possible wear, interference or damage; 2.
  • Page 22: Trouble Shooting

    VIII.TROUBLE SHOOTING TROUBLE CAUSE REMEDY 1. Oil line leakage 1. Check the oil connection and 2. Dirty hydraulic oil tighten the fitting 3. Cylinder leakage 2. Check the oil, replace and clean 4. Spring of pedal for reset Lift does not hydraulic system release is stuck stay up...
  • Page 23: Car Lift Safety Tips

    IX. CAR LIFT SAFETY TIPS Put this safety tips in a place where you can always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use original equipment parts to repair.
  • Page 24 72267705 2024/07...
