Freewing F-22 RAPTOR User Manual page 6

PNP Assembly Instructions
2. Align the main wing carbon tube with the fuselage, remove the ribbon cable from one end of the fuselage,
connect it to the main wing slot, and push the main wing into the installation position of the fuselage;
(Repeat this step for the other main wing)
The latch toggle lever of "quick" portable
install structure is in unlock status.
3. Press 4pcs main wing screw-less quick
install switch, put it in the locked status.
