PNP Parameter Setting
After installed this F22 model plane, please connect to the receiver and power on, then adjust it.
When all channels of radio are fine tuned to zero and the control stick is centered: check whether each control surface on the aircraft is
1.
in the center position. If it is found that the control surface is not in the center position, please adjust the control rod to center it;
Please refer to the diagram below and use the radio to test each control surface to ensure that its movement direction matches the
2.
diagram. If the opposite movement occurs, first check whether the relevant channel in the radio has enabled the reverse function; If the
problem persists, please contact us for assistance in resolving it.
Aileron
Stic k Left
Rudder
Stic k Left
Elevator
Stick down
Flaps
Flaps down
Freew i n g •
m• 4 ae c
www.freewing-model.com
Stic k Rig ht
Stic k Rig ht
Stick up
