Freewing F-22 introduction
Thank you for purchasing our Freewing 70mm EDF super scale jet, F-22 Raptor. Before you assemble this
F-22 model jet, please carefully read the instructions and follow the correct process for assembly and
adjustment. If you encounter problems during assembly and debugging, please first resolve them by
referring to the instructions. If the problem persists, please contact the distributor or directly contact us.
The F-22 Raptor is a single seat, twin engine, high stealth, supersonic fighter jet launched by Lockheed
Martin in the United States. It is the world's first fifth generation fighter jet to enter service. This Free-
wing 1/16.5 scale F-22 Raptor 70mm EDF electric model jet uses EPO material, length is 1150mm, wing
span is 817mm and uses the plastic structure and carbon tubes to strengthen.Standard grey camouflage
color scheme used silver and grey color with a good metallic texture. The mold uses a concave convex
pattern production process to make the surface of the aircraft appear more three-dimensional, present-
ing the concave convex details of the real fighter maintenance hatch. The vulnerable parts such as the
fuselage and wings are protected with plastic covers to prevent damage. From a visual perspective, the
edges appear sharper.
The PNP version can be assembled without glue. Among them, the main wing adopts the screw-less
"QUICK" portable install structure. It makes the use and storage of the aircraft more convenient. The
Freewing F-22 Raptor model jet uses electric retractable landing gear, while further improving the quality
of the landing gear structure, with overall higher strength and smoother damping. In addition, it also
includes front landing gear doors controlled by the servo, further reducing drag during flight. This model
jet includes the rudder, aileron, flap and full elevator. When PNP at factory, it pre-installed with a 70mm
12 blade duct fan, a 2957-2210KV brushless in-runner motor, and an 80A ESC. Under this configuration,
the maximum level flight speed reaches 170KM/H, and the powerful power brings a more enjoyable flying
experience!
From the actual flying experience, the F-22 Raptor 70mm EDF model jet is very suitable as a beginner
model jet. It has excellent flight stability, even in a low-speed cruising state at 30% throttle, still with
excellent performance. Powerful power and fast power response make it very easy to complete various
routine flight maneuvers. With the use of flaps, the aircraft can land at a slower speed and shorten the
landing distance.
Thank you again. I hope this new F-22 Raptor model jet can bring you a better experience. I wish you a
successful flight!
Note:
This is not a toy! Operater should have a certain experience, beginners should operate under the guidance of
1.
professional players.
Before install, please read through the instructions carefully and operate strictly under instructions.
2.
Cause of wrong operation,Freewing and its vendors will not be held responsible for any losses.
3.
Model planes' players must be on the age of 14 years old.
4.
This plane used the EPO material with surface spray paint, don' t use chemical to clean, otherwise it will damage.
5.
You should be careful to avoid flying in areas such as public pIaces,high-voltage-intensive areas,near the highway,
6.
near the airport or any other place where laws and regulation clearly prohibit.
You cannot fly in bad weather conditions such as thunderstorms,snows....
7.
Model plane's battery, don't allowed to put in everywhere. Storage must ensure that there is no inflammable
8.
and explosive materials in the round of 2M range.
Damaged or scrap battery should be properly recycled, it can't discard to avoid spontaneous combustion
9.
and fire.
In flying field, the waste after flying should be properly handIed,it can't be abandoned or burned.
10.
In any case, you must ensure that the throttle is in the low position and transmitter switch on, then it can connect
11.
the lipo-battery in aircraft.
Do not try to take planes by hand when flying or slow landing process. You must wait for landing stop, then carry it.
12.
NOTE: This is not a toy. Not for children under 14 years. Young people under the age of 14 should onIy be permitted to operate this model
under the instruction and supervision of an adult. Please keep these instructions for further reference after completing model assembly.
