- Page 2 Catalog www.freewing-model.com Introduction Product Basic Information Package list PNP Assembly Instructions Install Horizontal Tail Install Main Wing Install Vertical Tail Install Nose Cone Battery Instructions Pushrod Instructions Center of gravity Control Direction Test Dual Rates Servo Direction Motor Specification...
- Page 3 With the use of flaps, the aircraft can land at a slower speed and shorten the landing distance. Thank you again. I hope this new F-22 Raptor model jet can bring you a better experience. I wish you a successful flight! Note: www.freewing-model.com...
-
Page 4: Product Basic Information
Product Basic information www.freewing-model.com Wingload : 150 g/dm* Wing Area: 15.2d m Servo: 9gHybrid digital servo(9pcs) 9gDigital plastic servo(1pcs) Motor: 2957-2210KV I/R Motor Ducted fan: 70mm 12-blade fan ESC : 80A Brushless(7A UBEC) Weight: 1740g(w/o Battery) Landing gear: Electric landing gear Li-Po Battery: 6S 3500-5000mAh 1150mm(45.3in) - Page 5 The main wing screw-less The main wing screw-less quick install switch quick install switch Freew • m• Freewing F-22 Raptor 70mm EDF Jet www.freewing-model.com Item No.:FJ222 Ver.:FJ222.01...
- Page 6 (Repeat this step for the other main wing) The latch toggle lever of “quick” portable install structure is in unlock status. 3. Press 4pcs main wing screw-less quick install switch, put it in the locked status. www.freewing-model.com Freewing F-22 Raptor 70mm EDF Jet Item No.:FJ222 Ver.:FJ222.01...
- Page 7 2. Insert the vertical tail into the fuselage, turn over the fuselage, and then tighten it with screws. (Repeat this step for the other vertical tail) Screw (KM3*6mm 4PCS) step@ As the photo show: 1. Install the nose cone onto the fuselage • Freew m•^ Freewing F-22 Raptor 70mm EDF Jet www.freewing-model.com Item No.:FJ222 Ver.:FJ222.01...
- Page 8 Noae gear steering puehrod length Noae gear steering puahrod mounting hole Pushrod diameter 0 1.2mm 75mm Nose Cabin door pushrod length Nose cabin door pushrod mounting hole Pushrod diameter 0 1.2mm Freew m• • www.freewing-model.com Freewing F-22 Raptor 70mm EDF Jet Item No.:FJ222 Ver.:FJ222.01...
- Page 9 As the photo show, We marked the center of gravity on the bottom of the Main wing. Please confirm the CG based on this marked position. CG 1O8mm « Freew Freewing F-22 Raptor 70mm EDF Jet www.freewing-model.com www.freewing-model.com Item No.:FJ222 Ver.:FJ222.01...
- Page 10 Aileron Stic k Left Stic k Rig ht Rudder Stic k Left Stic k Rig ht Elevator Stick down Stick up Flaps Flaps down Freew • m• www.freewing-model.com Freewinq F-22 Raptor 70mm EDF Jet Item No.:FJ222 Ver.:FJ222.01...
-
Page 11: Control Direction Test
Futaba brand Remote Control : EXP A -30 EXPB EXPB EXPB Spektrum brand Remote Control : EXPO 30% 30% Spektrum brand Remote Control : EXPO 30% 30% Spektrum brand Remote Control : EXPO 30% 30% Freewing F-22 Raptor 70mm EDF Jet www.freewing-model.com Item No.:FJ222 Ver.:FJ222.01... - Page 12 100 mm Rudder(R) Use Voltage Use ESC EDF Weight Max power Efficiency Motor size MOtOF(KV) Thrust(g) Current(A) Item N o. (g/w) 1 68 2600 22 2 (6S) E7218 2957-2210KV 2210KV 1550 www.freewing-model.com Freewing F-22 Raptor 70mm EDF Jet Item No.:FJ222 Ver.:FJ222.01...
