Freewing F-22 RAPTOR User Manual page 5

PNP Assembly Instructions
As the photo show:
I.Place the horizontal tail on the rotating shaft at the rear fuselage and push it to the fuselage.
Then fix with screws to prevent its fall off.
(Repeat this step for the other Horizontal tail)
Attention: When the screw is
Then twist the screw in the opposite direction by half
of the rotating shaft.At this point, rotating
it will not fall off, indicating that the installation meets the requirements.
Screw (KM 3*6mm 2PCS)
As the photo show:
1. Press the main wing screw-less quick install switch to unlock it
Two different status diagrams of the main wing screw-less quick install switch: (The working mode is to press the
button to the bottom and release it. The button pops up to the highest position, which is the unlocked status.Once the
button is pressed to the bottom again and released, but the button does not pop up, which is the locked status)
As shown in the following photo:
Press the main wing screw-less quick install switch to the
bottom and release it. The button pops up to the highest
position, indicating that the main wing has been unlocked
and can be easily removed and installed.
Freewing F-22 Raptor 70mm EDF Jet
Item No.:FJ222
Ver.:FJ222.01
tightened all the way down, please
a turn,
the horizontal tail can
The main wing screw-less
quick install switch
stop immediately when the resistance suddenly increases;
leaving a certain gap between
move normally, and pulling the horizontal tail outward,
,
As shown in the following photo:
After installed the main wing, press again the main wing
screw-less quick install switch to the bottom and release it.
If the button does not pop up, it is the locked status. At this
point, pull the main wing outward and can not remove it.
www.freewing-model.com
the screw and the groove
The main wing screw-less
quick install switch
