Summary of Contents for Canon LBP-5100

Page 1 User's Guide User's Guide IMPORTANT: Read this manual carefully before using your printer. Save this manual for future reference.
Page 2 LBP5100 Laser Printer User's Guide...
Page 3: Troubleshooting
(This manual is also included in the CD-ROM supplied with the optional network board.) To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe Reader/Adobe Acrobat Reader is not installed on your system, please download it from the Adobe Systems Incorporated website.
Page 4: How This Manual Is Organized
Installing the Optional Accessories Chapter 9 Appendix Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, as we are constantly improving our products, if you need an exact speciﬁcation, please contact Canon.
Page 5: Table Of Contents
Abbreviations Used in This Manual ........xi...
Page 6 Power Supply Requirements ........2-4 Installation Requirements........2-4 Installation Space.
Page 7 For Windows XP/Server 2003 ........4-50...
Page 8 Installing from [Windows Explorer] ......4-74 Uninstalling the CAPT Software........4-76...
Page 9 Editing/Deleting a Proﬁle ........5-75...
Page 10 The Alarm Indicator is Blinking ........7-24...
Page 11 Method for Expressing Color ........
Page 12: Preface
Reading these notes is highly recommended. Buttons Used in This Manual The following button names are a few examples of how buttons to be pressed are expressed in this manual: Buttons on Computer Operation Screen: [Button Name] •...
Page 13: Displays Used In This Manual
Click this button for operation. Illustrations Used in This Manual Although the names of the indicator and key are not indicated in the illustrations of • the control panel used in this manual, the names are indicated above the respective icons depending on the country or region.
Page 14: Abbreviations Used In This Manual
Abbreviations Used in This Manual In this manual, product names and model names are abbreviated as follows: ® ® Microsoft Windows 95 operating system: Windows 95 ® ® Microsoft Windows 98 operating system: Windows 98 ® ® Microsoft Windows Millennium Edition operating system: Windows Me ®...
Page 15: Legal Notices
Connect the equipment into an outlet on a circuit different from that to which the • receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Page 16: Emc Directive (220 - 240 V Model)
EMC Directive. The product is in conformity with the EMC directive at nominal mains input 230 V, 50 Hz although the rated input of the product is 220 - 240 V, 50/60 Hz. C-tick marking on the rating label means that we declare the product is in conformity with the relevant requirements at nominal mains input 230 V, 50 Hz although the rated input of the product is 220 - 240 V, 50/60 Hz.
Page 17: International Energy Star-Program
The label shown below is attached to the laser scanner unit inside the machine. CLASS 1 LASER PRODUCT LASER KLASSE 1 APPAREIL A RAYONNEMENT LASER DE CLASSE 1 APPARECCHIO LASER DI CLASSE 1 PRODUCTO LASER DE CLASE 1 APARELHO A LASER DE CLASSE 1...
Page 18: Weee Directive
WEEE Directive European Union (and EEA) only. This symbol indicates that this product is not to be disposed of with your household waste, according to the WEEE Directive (2002/96/EC) and your national law. This product should be handed over to a designated collection point, e.g., on an...
Page 19: Copyright
Copyright Copyright 2006 by Canon Inc. All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written permission of Canon Inc.
Page 20: Legal Limitations On The Usage Of Your Product And The Use Of Images
This list is intended to be a guide only. If you are uncertain about the legality of using your product to scan, print or otherwise reproduce any particular document, and/or of the use of the images scanned, printed or otherwise reproduced, you should consult in advance with your legal advisor for guidance.
Page 21: Important Safety Instructions
If ﬂammable substances come into contact with electrical parts inside the printer, it may result in a ﬁre or electrical shock. Do not place the following items on the printer. If these items come into contact with • a high-voltage area inside the printer, it may result in a ﬁre or electrical shock.
Page 22 Blocking the ventilation slots can cause the printer to overheat, resulting in a ﬁre. Do not install the printer in the following locations, as this may result in a ﬁre or • electrical shock: - A damp or dusty location - A location exposed to smoke and steam such as cookeries and humidiﬁers...
Page 23: Power Supply
Do not plug the power cord to a multiplug power strip, as this may cause a ﬁre or • electrical shock. Do not bundle up or tie the power cord in a knot, as this may result in a ﬁre or • electrical shock.
Page 24: Handling
If these items come into contact with a high-voltage area inside the printer, it may result in a ﬁre or electrical shock. If these items are dropped or slipped inside the printer, immediately turn OFF the power switch and disconnect the USB cable if it is connected.
Page 25: Maintenance And Inspections
Unplug the power plug from the AC power outlet regularly, and clean the area around • the base of the power plug's metal pins and the AC power outlet with a dry cloth to ensure that all dust and grime is removed. If the power plug is plugged for a long period of time in a damp, dusty, or smoky location, dust can build up around the power plug and become damp.
Page 26 When removing jammed paper or replacing a toner cartridge, take care not to allow • the toner to come into contact with your hands or clothing, as this will dirty your hands or clothing. If they become dirty, wash them immediately with cold water.
Page 27: Consumables
• remaining inside the cartridge to ignite and result in burns or a ﬁre. Do not store a toner cartridge or copy paper in places exposed to open ﬂames, as • this may cause the toner or paper to ignite and result in burns or a ﬁre.
Page 28: Before You Start
Parts and Their Functions........
Page 29: Features And Beneﬁts
LBP5100 is supplied with the duplex unit. Therefore, you can automatically perform 2-sided printing with paper (A4, Legal, Letter, and Foolscap size) loaded in the manual feed slot or paper cassette. By doing so, you can save paper and make the ﬁle space more efﬁcient.
Page 30 (Black and white printing only). Although LBP5100 is designed for printing media of A4 size or smaller, you can print A3 and B4 size data on A4 size paper by using the function to reduce the standard paper sizes.
Page 31: Cd-Rom
■ CAPT (Canon Advanced Printing Technology) software, USB class driver The CAPT (Canon Advanced Printing Technology) software included on the supplied CD-ROM is software that is required to print using this printer. Be sure to install the CAPT software on the computer you are using.
Page 32: Cd-Rom Setup
Clicking this button allows you to install the printer driver and the instruction manuals simultaneously. ■ Custom Installation Clicking this button allows you to select whether to install the printer driver only or install the manuals only. ■ Additional Software Programs Clicking this button allows you to install "NetSpot Device Installer".
Page 33 Reader/Adobe Acrobat Reader is not installed on the system you are using, download it from the Adobe Systems Incorporated website. * The following PDF manuals are included in the "Manuals" folder in the supplied CD-ROM. User's Guide: UsersGuide.pdf Network Guide: NetworkGuide.pdf Remote UI Guide: RemoteUIGuide.pdf...
Page 34: Parts And Their Functions
Parts and Their Functions This printer consists of components that perform various functions. This section describes the name and function of each part in order for you to use this printer properly to make full use of its functions. Printer Unit The following are the parts and functions of the printer unit.
Page 35: Rear View
Align them with the width of the paper so that the paper is fed straight. Rear View The following are the parts on the rear side of the printer and their functions. a a a a Ventilation Slots e e e e Expansion Slot Ventilate air to cool the insides of the printer.
Page 36: Inner View
Inner View The following are the parts inside the printer and their functions. a a a a Static Charge Eliminator Cleaner d d d d C (Cyan) Toner Cartridge Slot Used when cleaning the static charge eliminator. The C (cyan) toner cartridge is installed in this slot.
Page 37: Indicators
NOTE You can conﬁrm information about the printer status using the Printer Status Window from the computer you are using. For details on the Printer Status Window, see "Printer Status Window," on p. 5-89. * Unlike in the above illustration, the indicator names are indicated above the respective icons depending on the country or region.
Page 38: Optional Accessories
Paper Feeder Unit PF-92 NOTE • The paper feeder is designed for LBP5000/5100. You cannot use a paper feeder designed for other models. • For details on the procedure for installing the paper feeder, see "Paper Feeder," on p. 8-2. Optional Accessories 1-11...
Page 39: Network Board
NOTE • For details on "Remote UI", see "Remote UI Guide". • For more details on "NetSpot Device Installer", see "Network Guide". • For details on the procedure for installing the network board, see "Network Board," on p. 8-18. 1-12...
Page 40: Installing The Printer
Setting Up the Printing Environment........
Page 41: Installation Procedure
Installation Procedure According to your installation condition, perform the relevant procedure. When you do not install the optional accessories, skip the procedures indicated with (Optional). (Optional) Installing the Paper Feeder (See p. 8-2) Installing the Printer Unit (See p. 2-9) Installing the Toner Cartridges (See p.
Page 42: Installation Site
- When the room where the printer is installed is heated rapidly - When the printer is moved from a cool or dry location to a hot or humid location • If water droplets form inside the printer, the paper transport path will not function properly, and this may result in paper jams or poor print quality.
Page 43: Power Supply Requirements
ﬁre or electrical shock. CAUTION • • • • Do not install the printer in the following locations, as this may result in a ﬁre or electrical shock. - A damp or dusty location - A location exposed to smoke and steam such as cookeries and humidiﬁers...
Page 44: Installation Space
• • • • Do not install the printer in unstable locations, such as unsteady platforms or inclined ﬂoors, or in locations subject to excessive vibrations, as this may cause the printer to fall or tip over, resulting in personal injury.
Page 45: Foot Positions
Foot Positions 117.2 161.3 (mm) Front Surface 255.5 NOTE The front feet are 5.6 mm high and their top surface is 11.5 mm square. The rear feet are 5.0 mm high and their top surface is 14 mm square. Installation Site...
Page 46 (mm) 82.5 239.2 86.8 95.7 239.2 73.6 NOTE The front feet are 3.1 mm high and their top surface is 17.3 mm square. The rear feet are 2.5 mm high and their top surface is 17.3 mm square. Installation Site...
Page 47: Conﬁrming The Package Contents
• Remote UI Guide • CAPT Windows Firewall Utility NOTE This printer does not come with an interface cable. Have an appropriate one available for the computer you are using or the connecting method. Use a USB cable with the following symbol.
Page 48: Carrying The Printer To The Installation Site And Removing The Packing Materials On The Outside Of The Printer
Keep them where they will not get lost. NOTE The packing materials may be changed in form or position to be placed, or may be added or removed without notice. Carrying the Printer to the Installation Site and Removing the Packing Materials on the Outside of the...
Page 49 Carry the printer unit to the installation site. Carry the printer with 2 or more people by holding the center of the lift handles on the lower portion of the printer and lifting it up at the same time. CAUTION •...
Page 50 • • • • Be sure not to hold the printer by the paper cassette, output area, or any portions other than the lift handles. If you do so, you may drop the printer, resulting in personal injury. • • • • The front portion of the printer (A) is relatively heavy. Be careful not to get off-balanced when lifting the printer.
Page 51 Remove the tape attached to the printer (6 locations). This packing material is to be removed later. These packing materials are to be removed later. 2-12 Carrying the Printer to the Installation Site and Removing the Packing Materials on the Outside of the Printer...
Page 52: Removing The Packing Materials Inside The Printer And Installing The Toner Cartridges
• For details on how to handle a toner cartridge, see "Precautions for Handling Toner Cartridges," on p. 6-13. • The packing materials may be changed in form or position to be placed, or may be added or removed without notice.
Page 53 IMPORTANT • Do not remove the packing material shown in the ﬁgure with the toner cartridges installed. • The toner cartridges are installed in order of black, yellow, cyan, and magenta from the top as shown in the ﬁgure. Black...
Page 54 Remove the packing materials shown in the ﬁgure. Remove the packing materials not vertically but diagonally toward the printer. Remove the packing materials shown in the ﬁgure. Removing the Packing Materials inside the Printer and Installing the Toner Cartridges 2-15...
Page 55 ETB unit (A) as shown in the ﬁgure so that the paper is not shifted. IMPORTANT • When installing or removing the toner cartridges, be sure to place paper on the transfer belt of the ETB unit to protect the belt. 2-16...
Page 56 ETB unit is supplied with a function that cleans itself, therefore, do not clean the belt even when the toner is on it. If the ETB unit is broken or transfer belt is damaged, this may result in misfeeds or deterioration in print quality.
Page 57 Holding a toner cartridge by the blue tabs on the both sides, pull it horizontally. Holding the toner cartridge with your both hands ﬁrmly, pull it out so that you do not touch the transfer belt of the ETB unit.
Page 58 • If toner is not distributed evenly, this may result in deterioration in print quality. Be sure to carry out this procedure properly. • Be sure to shake the toner cartridge gently. If you do not shake the cartridge gently, toner may spill out.
Page 59 • Do not pull the sealing tape diagonally, upwards, or downwards. If the tape is severed, it may become difﬁcult to pull out completely. • Pull out the sealing tape completely from the toner cartridge. If any tape remains in the toner cartridge, this may result in poor print quality.
Page 60 • When pulling out the sealing tape, be careful not to hold the drum protective shutter (A) with your hands. Hold the toner cartridge properly with the arrowed side facing up as shown in the ﬁgure. Removing the Packing Materials inside the Printer and Installing the Toner Cartridges...
Page 61 Remove the packing materials in all the toner cartridges, then install the cartridges into the printer unit. Align (A) of the toner cartridge with the slots (B) to which the label of the same color is attached, then insert the cartridge until it stops.
Page 62 • If you cannot close the front cover, check if the toner cartridge is installed properly. If you try to close the front cover forcefully, this may result in damage to the printer. • Do not leave the front cover open for a long time after installing the toner cartridge.
Page 63: Removing The Packing Material In The Paper Cassette And Loading Paper
Loading Paper Remove the packing material in the paper cassette and load paper. NOTE The packing materials may be changed in form or position to be placed, or may be added or removed without notice. Pull out the paper cassette.
Page 64 While holding the lock release lever of the side paper guides, slide the paper guides. The side paper guides move together. While holding the lock release lever of the rear paper guide, slide the paper guide. Removing the Packing Material in the Paper Cassette and Loading Paper...
Page 65 Install the cassette protective cover. Install the left side of the cassette protective cover a on the printer, then while pressing the right side of the cover b, insert the cover into the back of the printer c as shown in the ﬁgure.
Page 66: Load Paper
"Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in the Paper Source" (See p. 3-51) If you want to load paper in the manual feed slot, load the paper after performing Step 7.
Page 67 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. CAUTION When setting the paper cassette in the printer, be careful not to catch your ﬁngers.
Page 68: Connecting The Power Cord
• Do not plug the power plug into the auxiliary outlet on a computer. • One AC power outlet should be used exclusively for the printer. • Do not connect this printer to an uninterruptible power source. This may cause printer malfunction or breakdown at the occurrence of a power failure.
Page 69 Plug the supplied power cord into the power socket. Plug the power plug into the AC power outlet. NOTE The form of the supplied power cord may differ from the one in the above illustration. 2-30 Connecting the Power Cord...
Page 70: Connecting To A Computer
IMPORTANT • Do not plug or unplug the USB cable while the computer and printer are ON, as this may result in damage to the printer. • This printer uses bi-directional communication. Operation of the printer when connected...
Page 71 - Click [Cancel] and install the software from CD-ROM Setup. - Install with Plug and Play. • If you are not sure about the USB cable that is supported by the computer you are using, contact the store where you purchased the computer.
Page 72: Using A Lan Cable
• The network board for this printer cannot be connected to networks other than those listed above. • Make sure that there is a port available on the hub to which the printer will be connected. An additional hub must be installed if there is no free port.
Page 73 Connect the LAN cable to the LAN connector of the network board. Connect a LAN cable that is compatible with the LAN connector of the network board according to the network. Connect the other end of the LAN cable to the hub.
Page 74: Setting Up The Printing Environment
■ Sharing the printer on a network (See p. 4-55) If you share this printer on a network and use it from a computer on the network, you must specify the settings for the computer and install the printer driver on the client computers.
Page 75: Turning The Printer On/Off
IMPORTANT • Do not turn the power ON immediately after turning it OFF. If you want to turn the printer ON again after turning it OFF, wait at least 10 seconds after turning the printer OFF before turning it ON again.
Page 76: Turning The Printer Off
Turn the printer OFF using the following procedure. IMPORTANT • If the printer is used on a network, make sure that it is not printing data from another computer before turning the power OFF. • If you turn the printer OFF, all print data remaining in the printer memory will be erased.
Page 77: Power Saving (Sleep Mode)
6-16). NOTE • You can select [5], [10], [15], [30], [60], [90], [120], [150], or [180] minutes for [Time to Enter Sleep Mode]. The default value is [30] minutes. You can also conﬁgure the printer not to enter the sleep mode.
Page 78 From the [Options] menu in the Printer Status Window, select [Device Settings] ➞ [Sleep Settings]. Select the [Use Sleep Mode] check box in the [Sleep Settings] dialog box to specify the time to switch to the sleep mode in [Time to Enter Sleep Mode]. Click [OK].
Page 79 2-40 Turning the Printer ON/OFF...
Page 80: Loading And Outputting Paper
Loading Index Card Size Media in the Paper Cassette .......3-29...
Page 81: Paper Requirements
IMPORTANT • Print speed may drop depending on the settings for the paper size, paper type, and print copies. When printing heavy paper, transparencies, labels, or envelopes, the print speed may be as slow as approximately 2 pages/min.
Page 82: Paper Type
76.2 mm x 127.0 mm Paper Type The following shows the paper types that can be used with this printer. The symbol " " indicates that the paper is available for the 1-sided printing and automatic 2-sided printing; the symbol " " indicates that the paper is available for only 1-sided printing.
Page 83: Plain Paper
When printing envelopes, the printer automatically applies the appropriate print mode to the envelope type by specifying [Output Size] in the [Page Setup] sheet. Set [Paper Type] to [Envelope L] when the ﬂaps of envelopes stick to the body on printing with [Paper Type] set to [Envelope].
Page 84 Envelope C5 (104.9 mm x 241.3 mm) (162.0 mm x 229.0 mm) *You cannot use envelopes at sizes of DL, COM 10, Monarch, and C5 that have a ﬂap on the short edge. IMPORTANT • Do not use the following types of envelopes. Using inappropriate envelopes may result in paper jams that are difﬁcult to clear or may result in damage to the printer.
Page 85: Abbreviations Of Paper Sizes
• When printing envelopes of the Envelope B5 size, close the ﬂaps and load them so that the envelopes are printed from the top(the edge with the ﬂap). : Feeding direction) • Printing speed drops when printing envelops. NOTE When printing envelopes, they may be creased.
Page 86: Unusable Paper
5 mm 5 mm ■ Envelope You cannot print on any area within 10 mm of the edges of an envelope. You may have to change the printable area before printing, depending on the application you use. (Sample: Envelope COM10) 241.3 mm...
Page 87: Storing Paper
• Avoid physical damage to stored paper. • Do not store paper vertically or store too many stacks of paper in one pile. • Do not store paper in places exposed to direct sunlight or places with high or low humidity.
Page 88: Storing Printouts
When paper is moved to a location where the temperature or humidity differs signiﬁcantly, the paper may curl or become creased.
Page 89: Paper Source
The paper cassette has a paper level indicator (A) that shows the amount of paper remaining in the cassette. If the cassette is full, the paper level indicator is at the top. Because the indicator moves down as the amount of paper drops, this gives a rough estimate of the amount of paper remaining.
Page 90: Paper Capacity Of Paper Source
IMPORTANT If you are printing from Cassette 2, make sure that Cassette 1 is set before printing. If you print from Cassette 2 when Cassette 1 is not set, this will cause paper jams. Paper Capacity of Paper Source Paper Source...
Page 91: Selecting A Paper Source
Selecting a Paper Source A paper source can be selected in the [Paper Source] sheet in the printer driver. Display the [Paper Source] sheet and specify the paper source. For details on the procedure for displaying the [Paper Source] sheet in the printer driver, see "Specifying the Printing Preferences,"...
Page 92: Precautions For Handling The Manual Feed Slot Or Paper Cassette
If you are printing from the paper cassette, remove any paper loaded in the manual feed slot. • Do not pull out the paper cassette while the printer is printing. This may result in paper jams or damage to the printer.
Page 93 • Do not touch the paper in the manual feed slot or pull it out during printing. This may result in a faulty operation. • Reﬁll the paper cassette after all the loaded paper runs out. If the cassette is reﬁlled when paper still remains in the cassette, it may result in misfeeds.
Page 94: Output Tray
Output Tray Output Tray Printed paper is output to the output tray on the top of the printer unit with the printed side facing down. Printed paper is output in order of page. CAUTION Keep your hands or clothing away from the roller in the output area. Even if the printer is not printing, sudden rotation of the roller may catch your hands or clothing, resulting in personal injury.
Page 95: Paper Capacity Of The Output Tray
(When heavy paper that weighs 128 g/m is used) Transparency Approx. 10 sheets (Black and white printing only) Label Approx. 10 sheets Envelope Approx. 10 sheets * Actual paper capacity varies depending on the installation environment or paper type. 3-16 Output Tray...
Page 96: Loading Plain Paper, Heavy Paper, Transparencies, Or Labels In The Paper Source
If you want to print continuously, load the paper in the paper cassette. When printing only a sheet of paper that is different in size or type from the one loaded in the paper cassette, load the paper in the manual feed slot.
Page 97 Pull out the paper cassette. Pull out the paper cassette gently a. While holding the paper cassette with both hands, remove it from the printer unit as shown in the ﬁgure b. CAUTION Be sure to take the paper cassette out of the printer before loading paper.
Page 98 ● While holding the lock release lever of the side paper guides, slide the guides to the mark for the size of the paper to be loaded. The side paper guides move together. Align the position of (A) with the mark for the size of the paper to be loaded.
Page 99 ● While holding the lock release lever of the rear paper guide, slide the guide to the size mark for the paper to be loaded. Align the position of (A) with the mark for the size of the paper to be loaded. Before loading transparencies or labels, fan them in small batches and align the edges.
Page 100: Paper Guide
IMPORTANT • Be sure to check if the paper guide is at the position of the size of the loaded paper. If the paper guide is set at a wrong position, this may result in misfeeds. • If you use paper that has been poorly cut, multiple sheets of paper may be fed at once.
Page 101 NOTE To print letterhead paper or paper printed with a logo, load the paper so that the printing side is facing up, as shown in the following ﬁgure. : Feeding direction) 3-22 Loading Plain Paper, Heavy Paper, Transparencies, or Labels in the Paper Source...
Page 102 (B) on the paper guides. Make sure that there is sufﬁcient space between the hooks of the paper guides and the paper stack. If there is no sufﬁcient space, slightly reduce the amount of paper.
Page 103 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. CAUTION When setting the paper cassette in the printer, be careful not to catch your ﬁngers.
Page 104 Display the Printer Status Window. For details on methods for displaying the Printer Status Window, see "Displaying the Printer Status Window," on p. 5-92. From the [Options] menu, select [Device Settings] ➞ [Register Paper Size in Cassettes]. Select the size of the paper loaded in the paper cassette, then click [OK].
Page 105: Loading Paper In The Manual Feed Slot
Loading Paper in the Manual Feed Slot Load paper in the manual feed slot using the following procedure. Be sure to load paper in portrait orientation when loading it in the manual feed slot. Adjust the paper guides to the width of the loaded paper as shown in the ﬁgure.
Page 106 IMPORTANT Be sure to align the paper guides with the width of the paper. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. NOTE To print letterhead paper or paper printed with a logo, load the paper so that the printing side is facing down, as shown in the following ﬁgure.
Page 107 IMPORTANT • Load the paper so that it is straight. • If the paper is curled or folded at corners, ﬂatten it before loading it in the printer. Next, conﬁgure the printer driver (See p. 3-65). 3-28 Loading Plain Paper, Heavy Paper, Transparencies, or Labels in the Paper Source...
Page 108: Loading Index Card Size Media In The Paper Source
If you want to print continuously, load the Index Card size media in the paper cassette. When printing only a sheet of paper that is different in size or type from the one loaded in the paper cassette, load the Index Card size media in the manual feed slot.
Page 109 Pull out the paper cassette. Pull out the paper cassette gently a. While holding the paper cassette with both hands, remove it from the printer unit as shown in the ﬁgure b. CAUTION Be sure to take the paper cassette out of the printer before loading paper.
Page 110 IMPORTANT If you use Index Card size media that has been poorly cut, multiple sheets of that may be fed at once. In this case, fan the Index Card size media thoroughly, and then align the edges of the stack on a hard, ﬂat surface.
Page 111 NOTE To print letterhead paper or paper printed with a logo, load the paper so that the printing side is facing up, as shown in the following ﬁgure. : Feeding direction) While holding the lock release lever of the side paper guides, slide the guides to the mark for the size of the loaded Index Card size media.
Page 112 IMPORTANT Be sure to align the paper guides with the width of the Index Card size media. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. While holding the lock release lever of the rear paper guide, slide the guide to the size mark for the loaded Index Card size media.
Page 113 (A), and then set it under the hooks (B) on the paper guides. Make sure that there is sufﬁcient space between the hooks of the paper guides and the stack of the Index Card size media. If there is no sufﬁcient space, slightly reduce the amount of Index Card size media.
Page 114 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. Register the size of the loaded paper using the following procedure.
Page 115 From the [Options] menu, select [Device Settings] ➞ [Register Paper Size in Cassettes]. Select [Index Card], then click [OK]. Next, conﬁgure the printer driver (See p. 3-65). 3-36 Loading Index Card Size Media in the Paper Source...
Page 116: Loading Index Card Size Media In The Manual Feed Slot
Loading Index Card Size Media in the Manual Feed Slot Load Index Card size media in the manual feed slot using the following procedure. Be sure to load Index Card size media so that the printing side is facing down when loading it in the manual feed slot.
Page 117 IMPORTANT Be sure to align the paper guides with the width of the Index Card size media. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. NOTE To print letterhead paper or paper printed with a logo, load the paper so that the printing side is facing down, as shown in the following ﬁgure.
Page 118 IMPORTANT • Load the Index Card size media so that it is straight. • If the Index Card size media is curled, ﬂatten the curls by warping it in the opposite direction before loading it. Next, conﬁgure the printer driver (See p. 3-65).
Page 119: Loading Envelopes In The Paper Source
The paper source that you can load envelopes is the paper cassette and manual feed slot. If you want to print continuously, load the envelopes in the paper cassette. When printing only one envelope that is different from those loaded in the paper cassette, load the envelope in the manual feed slot.
Page 120 • When printing envelopes of the Envelope B5 size, close the ﬂaps and load them so that the printing side is facing up and the envelopes are printed from the top (the edge with the ﬂap). : Feeding direction) NOTE Load envelopes in Cassette 2 (Only when the optional paper feeder is installed) in the same manner as you load envelopes in Cassette 1.
Page 121 Place the stack of envelopes on a ﬂat surface, ﬂatten them to release any remaining air, and be sure that the edges are pressed tightly. CAUTION When loading paper, take care not to cut your hands with the edges of the paper. 3-42 Loading Envelopes in the Paper Source...
Page 122 Load the envelopes so that the edge of the envelopes is aligned with the front side of the paper cassette. IMPORTANT • Up to approximately 10 envelopes can be loaded in the paper cassette. Loading Envelopes in the Paper Source 3-43...
Page 123 The side paper guides move together. IMPORTANT Be sure to align the paper guides with the width of the envelopes. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. 3-44...
Page 124 (B) on the paper guides. Make sure that there is sufﬁcient space between the hooks of the paper guides and the stack of the envelopes. If there is no sufﬁcient space, slightly reduce the amount of the envelopes.
Page 125 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. CAUTION When setting the paper cassette in the printer, be careful not to catch your ﬁngers.
Page 126 Display the Printer Status Window. For details on methods for displaying the Printer Status Window, see "Displaying the Printer Status Window," on p. 5-92. From the [Options] menu, select [Device Settings] ➞ [Register Paper Size in Cassettes]. Select the size of the paper loaded in the paper cassette, then click [OK].
Page 127: Loading An Envelope In The Manual Feed Slot
• When loading an envelope at sizes of DL, COM10, C5, or Monarch in the manual feed slot, be sure to load it in portrait orientation so that the printing side is facing down and the ﬂap is toward the right of the printer when viewed from the front.
Page 128 The paper guides move together. IMPORTANT Be sure to align the paper guides with the width of the envelopes. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. Gently insert the envelope until it touches the back of the printer while supporting the envelope with hands as shown in the ﬁgure.
Page 129 When the envelope is loaded, it is sent into the slot a little. CAUTION When loading paper, take care not to cut your hands with the edges of the paper. IMPORTANT Load the envelope so that it is straight. Next, conﬁgure the printer driver (See p. 3-65).
Page 130: Loading Custom Size Paper (Non-Standard Paper) Or Paper At A Size Of Statement, Foolscap, Or 16K In The Paper Source
When printing only a sheet of custom size paper or paper at a size of Statement, Foolscap, or 16K that is different in size or type from the one loaded in the paper cassette, load the custom size paper or paper at a size of Statement, Foolscap, or 16K in the manual feed slot.
Page 131: Loading Custom Size Paper Or Paper At A Size Of Statement, Foolscap, Or 16K In The Paper Cassette
16K in portrait orientation when loading it in the paper cassette. NOTE Load custom size paper or paper at a size of Statement, Foolscap, or 16K in Cassette 2 (Only when the optional paper feeder is installed) in the same manner as you load custom size paper or paper at a size of Statement, Foolscap, or 16K in Cassette 1.
Page 132 When loading paper that is larger than A4 size (297.0 mm), adjust the length of the paper cassette while holding the lock release lever shown in the ﬁgure. Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in 3-53 the Paper Source...
Page 133 IMPORTANT If you use paper that has been poorly cut, multiple sheets of paper may be fed at once. In this case, fan the paper thoroughly, and then align the edges of the stack on a hard, ﬂat surface.
Page 134 The side paper guides move together. Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in 3-55 the Paper Source...
Page 135 IMPORTANT Be sure to align the paper guides with the width of the paper. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. While holding the lock release lever of the rear paper guide, slide the guide to the size mark for the loaded paper.
Page 136 Make sure that there is sufﬁcient space between the hooks of the paper guides and the paper stack. If there is no sufﬁcient space, slightly reduce the amount of paper. Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in 3-57 the Paper Source...
Page 137 This printer's paper cassette cannot automatically detect the paper size. Therefore, you need to register the size of the loaded paper in the Printer Status Window. 3-58 Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in the Paper Source...
Page 138 When loading paper at a size of Statement, Foolscap, or 16K, conﬁgure the printer driver next (See p. 3-65). Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in 3-59 the Paper Source...
Page 139: Loading Custom Size Paper Or Paper At A Size Of Statement, Foolscap, Or 16K In The Manual Feed Slot
Adjust the paper guides to the width of the loaded paper as shown in the ﬁgure. The paper guides move together. 3-60 Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in the Paper Source...
Page 140 IMPORTANT Be sure to align the paper guides with the width of the paper. If the paper guides are too loose or too tight, this may result in misfeeds or paper jams. NOTE To print letterhead paper or paper printed with a logo, load the paper so that the printing side is facing down, as shown in the following ﬁgure.
Page 141: Registering A Custom Paper Size (Non-Standard Paper)
• Load the paper so that it is straight. • If the paper is curled or folded at corners, ﬂatten it before loading it in the printer. When loading custom size paper, register the custom paper size next (See p. 3-62).
Page 142 Specify the height and width of the custom paper size ([Height] [Width]). Specify the custom paper size in portrait orientation ([Height] [Width]) within user-deﬁnable sizes. Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in 3-63 the Paper Source...
Page 143 2000/XP/Server 2003, the number depends on the system environment. Conﬁrm the settings, then click [OK]. Next, conﬁgure the printer driver (See p. 3-65). 3-64 Loading Custom Size Paper (Non-Standard Paper) or Paper at a Size of Statement, Foolscap, or 16K in the Paper Source...
Page 144: Setting Up The Printer Driver And Printing
• For details on the procedure for installing the printer driver, see "Installing the CAPT Software," on p. 4-4. • For more details on the settings for the printer driver, see "Various Pages in the Printer Driver" (p. 5-25) or Online Help. For details on methods for displaying Online Help, see "How to Use Online Help,"...
Page 145 NOTE If you set [Page Size] to [Envelope DL], [Envelope COM10], [Envelope C5], [Envelope Monarch], or [Envelope B5], the following message appears, and [Paper Type] is automatically speciﬁed.
Page 146 From [Output Size], select the size of the loaded paper as needed. Leave the setting at [Match Page Size] when the paper size speciﬁed for [Page Size] and that of the paper loaded in the paper cassette are the same, since there is no need to change the setting. IMPORTANT The print will be automatically reduced or enlarged to ﬁt on the page when the...
Page 147 [Cassette 2], and the [Detect Paper Size] check box in the [Finishing Details] dialog box in the printer driver is not selected, the printer does not check the paper size. When the size of the paper loaded in the paper cassette and the speciﬁed settings are different from each other, and the [Detect Paper Size] check box is selected (default setting), the printer operations vary as the following examples.
Page 148 [Register Paper Size in Cassettes] dialog box. When printing the currently loaded paper, click the [Resolve Error] button. If [Paper Source] is set to [Auto], the printer checks the paper size regardless of the setting for [Detect Paper Size].
Page 149 * When printing envelopes, the printer automatically applies the appropriate print mode to the envelope type by specifying [Output Size] in the [Page Setup] sheet. Set [Paper Type] to [Envelope L] when the ﬂaps of envelopes stick to the body on printing with [Paper Type] set to [Envelope].
Page 150: Click [Ok] To Close The Properties Dialog Box
Click [OK] to close the Properties dialog box. Click [OK] to start printing. Setting Up the Printer Driver and Printing 3-71...
Page 151: 2-Sided Printing
• During automatic 2-sided printing, do not touch the paper until it is output to the output tray completely. During automatic 2-sided printing, the paper is ﬁrst output partially after the front side is printed, and then it is fed again to be printed on the reverse side. NOTE...
Page 152 - When paper is fed from the paper cassette, load the paper so that the printing side (front side) is facing down, as shown in the following ﬁgures. : Feeding direction) 2-sided Printing 3-73...
Page 153 - When paper is fed from the manual feed slot, load the paper so that the printing side (front side) is facing up, as shown in the following ﬁgures. : Feeding direction) • Load paper in Cassette 2 (Only when the optional paper feeder is installed) in the same manner as you load paper in Cassette 1.
Page 154 Select [Print] from the [File] menu in the application. Select the name of this printer for [Name] or [Printer Name], and then click [Properties]. Display the [Page Setup] sheet, then from [Page Size], select the size of a document that you have created with the application.
Page 155 From [Output Size], select the size of the loaded paper as needed. Leave the setting at [Match Page Size] when the page size and the size of the paper loaded in the paper source are the same, since there is no need to change the setting.
Page 156: Print Style
[Print Style]. Display the [Paper Source] sheet, then select [Paper Source]. Specify the same setting as the one for [Paper Source], although the setting for [Paper Source] changes to ones such as [First Page] or [Other Pages] when [Paper Selection] is set to other than [Same Paper for All Pages].
Page 157 60 - 74 g/m [Plain Paper L] Plain paper 75 - 90 g/m [Plain Paper] Heavy paper 91 - 105 g/m [Heavy Paper 1]* * You cannot perform automatic 2-sided printing on heavy paper that weighs between 106 and 163g/ 3-78 2-sided Printing...
Page 158 Click [OK] to close the Properties dialog box. Click [OK] to start printing. 2-sided Printing 3-79...
Page 159 3-80 2-sided Printing...
Page 160: Setting Up The Printing Environment
For Windows 98/Me/2000............4-51 Checking the Operations by Conﬁguration Page Print ......4-52 Printing from a Network Computer by Sharing the Printer on a Network .
Page 161: Introduction
■ Sharing the printer on a network (See p. 4-55) If you share this printer on a network and use it from a computer on the network, you must specify the settings for the computer and install the printer driver on the client computers.
Page 162 89 MB or more (PC/AT Compatibles) *1 As the amount of available memory varies depending on the system conﬁguration of the computer or application you are using, the above environment does not guarantee printing in all cases. *2 This indicates free hard disk space required for installing the printer driver and manuals using Easy Installation.
Page 163: Installing The Capt Software
Windows 98/Me: p. 4-45 *1 If you want to install the manuals only, see "Installing the Manuals," on p. 5-85. *2 When installing the CAPT software from [Add Printer Wizard], the USB port for connecting this printer has to have already been registered.
Page 164: Installing From Cd-Rom
"Print Server Settings" (p. 4-56) and install the additional driver again. • This printer does not come with a USB cable. Have an appropriate one available for the computer you are using. Use a USB cable with the following symbol.
Page 165 Insert the supplied "LBP5100 User Software" CD-ROM into the CD-ROM drive. If the CD-ROM is already in the drive, eject the disk and re-insert it into the drive. IMPORTANT If CD-ROM Setup does not appear, select [Run] from the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
Page 166 Click [Easy Installation] or [Custom Installation]. [Easy Installation] allows you to install the printer driver and the instruction manuals simultaneously. If you do not install the manuals, select [Custom Installation]. Click [Install]. Installing the CAPT Software...
Page 167 If you selected [Custom Installation] in Step 6, clear the [Online Manuals] check box, and then click [Install]. Conﬁrm the contents, then click [Yes]. Click [Next]. Installing the CAPT Software...
Page 168 Click [Yes] when you share the printer on a network. After completing the installation, see "Printing from a Network Computer by Sharing the Printer on a Network" (p. 4-55) and specify the settings for sharing the printer on the network. Click [No] when you do not share the printer on a network.
Page 169 NOTE • Depending on the system environment, it may take a long time to complete the installation. • If you are using Windows 2000 and the [Digital Signature Not Found] dialog box appears, click [Yes]. • If you are using Windows XP/Server 2003 and the [Hardware Installation] dialog box appears, click [Continue Anyway].
Page 170 If [Easy Installation] is selected in Step 6, the manuals are installed. Conﬁrm the installation results, then click [Next]. NOTE If the printer driver is not installed properly, see "Installation Problems," on p. 7-39. Installing the CAPT Software 4-11...
Page 171 Select the [Restart Computer Now (Recommended)] check box, then click [Restart]. Windows restarts. The installation of the USB class driver and the printer driver is completed. 4-12 Installing the CAPT Software...
Page 172: Installing With Plug And Play
Installing with Plug and Play For Windows XP/Server 2003 If you are using an operating system other than Windows XP/Server 2003, see the following. • For Windows 2000 (See p. 4-18) • For Windows 98/Me (See p. 4-23) The screen shots used in this section are from Windows XP.
Page 173 Connect the A-type (ﬂat) end of the USB cable to the USB port on the computer. Press " " of the power switch to turn the printer ON. Turn the computer on and start up Windows XP/Server 2003. Log on as a member of Administrators.
Page 174 ● If the following screen is displayed ❑ Select [Install from a list or speciﬁc location (Advanced)], then click [Next]. ● If the following screen is displayed ❑ Select [No, not this time], then click [Next]. ❑ Select [Install from a list or speciﬁc location (Advanced)], then click [Next].
Page 175 [Include this location in the search] check box. Click [Browse], then select the folder. Select [D:\English\Win2K_XP], then click [OK]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. 4-16...
Page 176 Click [Finish]. IMPORTANT If you are using a computer with Windows XP Service Pack 2 or another operating system equipped with Windows Firewall as the print server, you need to conﬁgure Windows Firewall to unblock communication with the client computers. (See p.
Page 177: For Windows 2000
For Windows 2000 If you are using an operating system other than Windows 2000, see the following. • For Windows XP/Server 2003 (See p. 4-13) • For Windows 98/Me (See p. 4-23) Make sure that the printer and computer are OFF.
Page 178 Press " " of the power switch to turn the printer ON. Turn the computer on and start up Windows 2000. Log on as a member of Administrators. The [Found New Hardware Wizard] dialog box appears. NOTE Full Control Permission is required for the installation of the printer driver.
Page 179 Select [Search for a suitable driver for my device (recommended)], then click [Next]. NOTE [Unknown] may be displayed as the name of the device. Clear the [Floppy disk drives] check box and the [CD-ROM drives] check box, select the [Specify a location] check box, and then click [Next].
Page 180 Select [D:\English\Win2K_XP]. Select [CNAC6STK.INF], then click [Open]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Make sure that the folder to be browsed is displayed for [Copy manufacturer's ﬁles from], and then click [OK].
Page 181 Copying ﬁles is started. NOTE If the [Digital Signature Not Found] dialog box appears, click [Yes]. Click [Finish]. The installation of the USB class driver (supplied with an operating system) and the printer driver is completed. 4-22 Installing the CAPT Software...
Page 182: For Windows 98/Me
For Windows 98/Me If you are using an operating system other than Windows 98/Me, see the following. • For Windows XP/Server 2003 (See p. 4-13) • For Windows 2000 (See p. 4-18) The screen shots used in this section are from Windows Me.
Page 183 Press " " of the power switch to turn the printer ON. Turn the computer on and start up Windows 98/Me. The [Add New Hardware Wizard] dialog box appears. ● For Windows Me If the following dialog box appears, proceed to Step 6.
Page 184 ● For Windows 98 If the following dialog box appears, click [Next], then proceed to Step 6. If the following dialog box appears, click [Next], then proceed to Step 13. Select [Specify the location of the driver (Advanced)], then click [Next].
Page 185 For Windows Me: Select [D:\English\USBPORT\WinMe], and then click [OK]. For Windows 98: Select [D:\English\USBPORT\Win98], and then click [OK]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using.
Page 186 Make sure that the folder to be browsed is displayed for [Specify a location], and then click [Next]. Click [Next]. Installation of the USB class driver starts. Click [Finish]. The printer is detected automatically. Please wait a moment. Installing the CAPT Software...
Page 187 The [Add New Hardware Wizard] dialog box appears. For Windows 98, click [Next]. Select [Specify the location of the driver (Advanced)], then click [Next]. For Windows 98: Select [Search for the best driver for your device. (Recommended).], then click [Next].
Page 188 [Specify a location] check box. Click [Browse], then select the folder. Select [D:\English\Win98_Me], then click [OK]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Installing the CAPT Software...
Page 189 Make sure that the folder to be browsed is displayed for [Specify a location], and then click [Next]. Click [Next]. Enter a new name in [Printer name] if you want to change the printer name. NOTE If another printer driver has already been installed in the computer, the message <Do you want your Windows-based programs to use this printer as the default...
Page 190 Click [Finish]. Copying ﬁles is started. When the dialog box for completing the installation appears, click [OK]. Click [Finish]. The installation of the USB class driver and the printer driver is completed. Installing the CAPT Software 4-31...
Page 191: Installing From [Add Printer Wizard]
The screen shots used in this section are from Windows XP. IMPORTANT When printing a test page, make sure that the printer is properly connected to the computer and the printer is ON before installing the CAPT software. Turn the computer on and start up Windows XP/Server 2003.
Page 192 Click [Add a printer]. For Windows Server 2003: Double-click [Add Printer]. Click [Next]. Make sure that [Local printer attached to this computer] is selected, then click [Next]. Installing the CAPT Software 4-33...
Page 193 NOTE Do not select the [Automatically detect and install my Plug and Play printer] check box. Make sure that [Use the following port] is selected, select the USB port to which this printer is connected, and then click [Next]. Click [Have Disk].
Page 194 Select [D:\English\Win2K_XP]. Select [CNAC6STK.INF], then click [Open]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Conﬁrm the contents of [Copy manufacturer's ﬁles from], then click [OK].
Page 195 [Next]. NOTE If another printer driver has already been installed in the computer, the message <Do you want to use this printer as the default printer?> appears. In this case, select [Yes] or [No]. 4-36 Installing the CAPT Software...
Page 196 Click [Next]. NOTE When sharing this printer on a network, select [Share name], and then click [Next]. The window for entering [Location] and [Comment] is displayed. Enter them as needed, then click [Next]. When printing a test page, click [Yes], then click [Next].
Page 197 Click [Finish]. Copying ﬁles is started. When printing a test page, a dialog box will appear after printing. Click [OK] to close the dialog box. NOTE If the [Hardware Installation] dialog box appears, click [Continue Anyway]. If the printer and computer are not connected, turn the computer off, connect the computer and printer with a USB cable, and then turn them ON.
Page 198: For Windows 2000
• For Windows 98/Me (See p. 4-45) IMPORTANT When printing a test page, make sure that the printer is properly connected to the computer and the printer is ON before installing the CAPT software. Turn the computer on and start up Windows 2000.
Page 199 Make sure that [Local printer] is selected, then click [Next]. NOTE Do not select the [Automatically detect and install my Plug and Play printer] check box. Select the USB port for connecting this printer, and then click [Next]. 4-40 Installing the CAPT Software...
Page 200 If CD-ROM Setup appears, click [Exit]. Select [D:\English\Win2K_XP]. Select [CNAC6STK.INF], then click [Open]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Installing the CAPT Software...
Page 201 Conﬁrm the contents of [Copy manufacturer's ﬁles from], then click [OK]. For example, when your CD-ROM drive is drive [D:], it is displayed as [D:\English\Win2K_XP]. Click [Next]. Enter a new name in [Printer name] if you want to change the printer name, then click [Next].
Page 202 In this case, select [Yes] or [No]. Click [Next]. NOTE When sharing this printer on a network, select [Share as], and then click [Next]. The window for entering [Location] and [Comment] is displayed. Enter them as needed, then click [Next].
Page 203 Click [Finish]. Copying ﬁles is started. When printing a test page, a dialog box will appear after printing. Click [OK] to close the dialog box. NOTE If the [Digital Signature Not Found] dialog box appears, click [Yes]. If the printer and computer are not connected, turn the computer off, connect the computer and printer with a USB cable, and then turn them ON.
Page 204: For Windows 98/Me
For Windows 98/Me If you are using an operating system other than Windows 98/Me, see the following. • For Windows XP/Server 2003 (See p. 4-32) • For Windows 2000 (See p. 4-39) The screen shots used in this section are from Windows Me.
Page 205 Select [Local printer], then click [Next]. NOTE This screen does not appear when the network settings have not been conﬁgured. Click [Have Disk]. Insert the supplied "LBP5100 User Software" CD-ROM into the CD-ROM drive, and then click [Browse]. If CD-ROM Setup appears, click [Exit].
Page 206 Select [D:\English\Win98_Me], then click [OK]. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Conﬁrm the contents of [Copy manufacturer's ﬁles from], then click [OK].
Page 207 Select the USB port for connecting this printer, and then click [Next]. Enter a new name in [Printer name] if you want to change the printer name. NOTE If another printer driver has already been installed in the computer, the message <Do you want your Windows-based programs to use this printer as the default...
Page 208 When the dialog box for completing the installation appears, click [OK]. If the printer and computer are not connected, turn the computer off, connect the computer and printer with a USB cable, and then turn them ON. The installation of the printer driver is completed.
Page 209: After Completing Installation
After Completing Installation When the installation of the CAPT software is completed, an icon and folder for this printer will be created. For Windows XP/Server 2003 • The icon for this printer is displayed in the [Printers and Faxes] folder.
Page 210: For Windows 98/Me/2000
• The icon for the printer is displayed in the [Printers] folder. • [Canon Printer Uninstaller] is added to [Programs] under the [Start] menu. • If the manuals are installed, [LBP5100 Online Manuals] is created on the desktop, and [LBP5100 Online Manuals] under [Canon LBP5100] is added to [Programs] under the [Start] menu.
Page 211: Checking The Operations By Conﬁguration Page Print
[Number of Total Printed Pages]. NOTE • Conﬁguration Page Print is designed to be printed on A4 size paper. Load A4 size paper. • The screen shots used in this section are from Windows XP Professional. Display the [Printers and Faxes] folder or the [Printers] folder.
Page 212 ] (Display Printer Status Window) to run the Printer Status Window. NOTE For details on the Printer Status Window, see "Printer Status Window," on p. 5-89. From the [Options] menu, select [Utility] ➞ [Conﬁguration Page Print]. Checking the Operations by Configuration Page Print...
Page 213 IMPORTANT This is a sample of Conﬁguration Page Print. The contents may differ from the Conﬁguration Page Print printed by your printer. NOTE If Conﬁguration Page Print is not printed properly, see "Chapter 7 Troubleshooting".
Page 214: Printing From A Network Computer By Sharing The Printer On A Network
Printing from a Network Computer by Sharing the Printer on a Network When you share this printer on a network, you can use it as a network printer, which enables printing from other computers that are not directly connected to this printer.
Page 215: Print Server Settings
* Download installation is to download the printer driver from the print server to client computers and install it without using the supplied CD-ROM when an additional driver (alternate driver) is installed on the print server. When using a print server, perform the following settings:...
Page 216: Preparing The Printer Sharing Settings
From the [Start] menu, select [Control Panel], and then click [Network and Internet Connections] ➞ [Network Connections]. For Windows 2000: From the [Start] menu, select [Settings] ➞ [Network and Dial-up Connections]. For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞...
Page 217: Printer Sharing Settings
Networks] is selected, then click [OK]. ■ Printer Sharing Settings NOTE For Windows XP, the printer cannot be shared on a network at the default settings (the settings immediately after the installation). Printer sharing settings require running [Network Setup Wizard] to enable the sharing settings.
Page 218 For Windows 2000: Select [Shared as]. NOTE • You can also specify the sharing settings during the local installation. • Do not enter blank or special characters for the share name. Printing from a Network Computer by Sharing the Printer on a Network...
Page 219 NOTE To update the additional driver (alternate driver), uninstall the printer driver used in the print server, install the new printer driver, and then see "Print Server Settings" (p. 4-56) and install the additional driver again. Select the [Windows 95, 98 and Me] check box, then click [OK].
Page 220 Click [Browse]. When your CD-ROM drive is drive [D:], select [D:\English\Win98_Me], and then click [OK]. Copying ﬁles is started. Click [OK] or [Close]. The printer icon changes to the shared printer icon. Printing from a Network Computer by Sharing the Printer on a Network 4-61...
Page 221 - If you clicked [No], however, Windows Firewall was conﬁgured to block communication with the client computers, and you will need to use the following method to clear that block. 1. From the [Start] menu, select [Control Panel], and then click [Network and Internet Connections] ➞...
Page 222: Installation On Clients
• Installing from [Windows Explorer] (See p. 4-74) IMPORTANT • If you are using Windows 2000/XP/Server 2003, be sure to log on as a member of Administrators when starting up. Printing from a Network Computer by Sharing the Printer on a Network...
Page 223: Installing From Cd-Rom Setup
Insert the supplied "LBP5100 User Software" CD-ROM into the CD-ROM drive. If the CD-ROM is already in the drive, eject the disk and re-insert it into the drive. IMPORTANT If CD-ROM Setup does not appear, select [Run] from the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
Page 224 Click [Easy Installation] or [Custom Installation]. [Easy Installation] allows you to install the printer driver and the instruction manuals simultaneously. If you do not install the manuals, select [Custom Installation]. Click [Install]. Printing from a Network Computer by Sharing the Printer on a Network...
Page 225 If you selected [Custom Installation] in Step 2, clear the [Online Manuals] check box, and then click [Install]. Conﬁrm the contents, then click [Yes]. Click [Next]. 4-66 Printing from a Network Computer by Sharing the Printer on a Network...
Page 226 Select [Manually Set Port to Install], then click [Next]. Click [Add Port]. Select [Network], then click [OK]. Printing from a Network Computer by Sharing the Printer on a Network 4-67...
Page 227 Select the icon for the shared printer in the print server, then click [OK]. Select whether or not to use this printer as the default printer, then click [Next]. Click [Start]. 4-68 Printing from a Network Computer by Sharing the Printer on a Network...
Page 228 Do you want to continue?> appears. Click [Yes]. Installation of the printer driver starts. NOTE Depending on the system environment, it may take a long time to complete the installation. If [Easy Installation] is selected in Step 2, the manuals are installed.
Page 229 Conﬁrm the installation results, then click [Next]. NOTE If the printer driver is not installed properly, see "Installation Problems," on p. 7-39. Select the [Restart Computer Now (Recommended)] check box, then click [Restart]. Windows restarts. IMPORTANT If you are using Windows XP Service Pack 2 or another operating system equipped with Windows Firewall on the client computers, conﬁgure Windows Firewall to...
Page 230: Installing From [Add Printer Wizard]
For Windows XP Professional/Server 2003: From the [Start] menu, select [Printers and Faxes]. For Windows XP Home Edition: From the [Start] menu, select [Control Panel], and then click [Printers and Other Hardware] ➞ [Printers and Faxes]. Display the [Add Printer Wizard] dialog box.
Page 231 For Windows 98/Me/2000: Select [Network printer] then click [Next]. Select [Connect to this printer (or to browse for a printer, select this option and click Next)], then click [Next]. For Windows 98/Me, click [Browse]. 4-72 Printing from a Network Computer by Sharing the Printer on a Network...
Page 232 • If you are using Windows XP/Server 2003 and the [Connect to Printer] dialog box appears, follow the directions in the message. • When specifying the path to the network using "\" directly, specify it as "\\the print sever name (the computer name of the print server)\the printer name".
Page 233: Installing From [Windows Explorer]
Click [Finish]. IMPORTANT If you are using Windows XP Service Pack 2 or another operating system equipped with Windows Firewall on the client computers, conﬁgure Windows Firewall to unblock communication with the print server. If you do not clear the block, the printer status may not be displayed properly in the Printer Status Window, and some of the printer functions may not operate properly.
Page 234 Select the print server from [My Network Places] (from [Network Neighborhood] for Windows 98), then double-click the icon for this printer. Alternatively, you can drag and drop the icon for the printer into the [Printers and Faxes] folder or [Printers] folder. Follow the instructions on the screen.
Page 235: Uninstalling The Capt Software
• If the printer driver was installed on Windows 2000/XP/Server 2003 logged on by a user who is a member of Administrators, it cannot be uninstalled from the computer logged on by anyone other than users who are members of Administrators. Be sure to log on as a member of Administrators before the uninstallation.
Page 236 Select the name of this printer, then click [Delete]. NOTE Even if [Canon LBP5100] is not on the list in the [Delete Printer] dialog box, you can delete the ﬁle and information related to this printer by clicking [Delete]. Click [Yes].
Page 237 Click [Exit]. NOTE If the CAPT software cannot be uninstalled, see "When Uninstallation Fails," on p. 7-43. 4-78 Uninstalling the CAPT Software...
Page 238 Displaying Online Help on the Options Displayed on the Screen ..... . .5-79 Displaying Online Help on the Operation Procedures ....... .5-80...
Page 239 Displaying Printer Status When Using a Print Server ....... .
Page 240: Setting Printer Information Before Printing
For Windows XP Professional/Server 2003: From the [Start] menu, select [Printers and Faxes]. For Windows XP Home Edition: From the [Start] menu, select [Control Panel], and then click [Printers and Other Hardware] ➞ [Printers and Faxes]. Select the icon for this printer, then select [Properties] from the [File] menu.
Page 241 2003) or [Conﬁguration] (for Windows 98/Me) sheet, then specify the settings for [Paper Source Options]. NOTE You can also obtain the printer status such as the paper feeder automatically by clicking [Get Device Status]. Click [OK]. Setting Printer Information before Printing...
Page 242: Printing From An Application
Printing from an Application After installing the CAPT software, you can now print jobs on the printer. This section describes the procedure for printing from an application, taking Adobe Reader 7.0 as an example. Load paper in the paper cassette or manual feed slot.
Page 243 NOTE The printer name displayed in this dialog box can be changed in the [Printers and Faxes] folder (the [Printers] folder for Windows 98/Me/2000). If you want to specify more detailed printing preferences, click [Properties].
Page 244 [Finishing], [Paper Source], and [Quality] sheets. NOTE • For more details on the settings, see "Various Pages in the Printer Driver" (p. 5-25) or Online Help. For details on methods for displaying Online Help, see "How to Use Online Help," on p. 5-79.
Page 245 • "Using the Various Printing Functions" (See p. 5-18) describes how to use the various functions of the printer and printer driver. By specifying the settings for the printer and printer driver for each job, you can make the best use of the printer and its functions.
Page 246: Specifying The Printing Preferences
• Full Control Permission is required to specify the settings for the [Printers and Faxes] folder or the [Printers] folder. If you cannot display the [Document Properties] dialog box from the [Printers and Faxes] folder or the [Printers] folder, display the dialog box from the application.
Page 247 Conﬁrm the printer name, then click [Properties]. The [Document Properties] dialog box is displayed. 5-10 Specifying the Printing Preferences...
Page 248: Displaying The [Document Properties] Dialog Box From The [Printers And Faxes] Folder Or The [Printers] Folder
For Windows XP Professional/Server 2003: From the [Start] menu, select [Printers and Faxes]. For Windows XP Home Edition: From the [Start] menu, select [Control Panel], and then click [Printers and Other Hardware] ➞ [Printers and Faxes]. Select the icon for this printer, then select [Printing Preferences] from the [File] menu.
Page 249: Displaying The [Printer Properties] Dialog Box From The [Printers And Faxes] Folder Or The [Printers] Folder
For Windows XP Professional/Server 2003: From the [Start] menu, select [Printers and Faxes]. For Windows XP Home Edition: From the [Start] menu, select [Control Panel], and then click [Printers and Other Hardware] ➞ [Printers and Faxes]. Select the icon for this printer, then select [Properties] from the [File] menu.
Page 250: For Windows 98/Me
NOTE The [Conﬁguration] sheet that allows you to specify various settings for the printer can be displayed only by using the procedure described in "Displaying the [Printer Properties] Dialog Box from the [Printers] Folder"...
Page 251 Select the name of this printer for [Name] or [Printer Name], and then click [Properties]. The [Document Properties] dialog box is displayed. 5-14 Specifying the Printing Preferences...
Page 252: Displaying The [Printer Properties] Dialog Box From The [Printers] Folder
Select the icon for this printer, then select [Properties] from the [File] menu. The [Printer Properties] dialog box is displayed. NOTE The [Printer Properties] dialog box can also be displayed by right-clicking the icon for this printer and selecting [Properties] from the pop-up menu. Specifying the Printing Preferences 5-15...
Page 253: Deleting/Pausing/Resuming A Print Job
[Current Print Job] tab or [My Job Operation] tab. The following message is displayed and the [My Job Operation] tab is selected on the top by clicking the [Pause Job] button in the [Current Print Job] tab. 5-16...
Page 254 ] (Pause Job). ● Resuming the Job ❑ Click [ ] (Resume Job). NOTE You cannot control another user's job. For more details, see "Displaying Printer Status When Using a Print Server," on p. 5-98. Deleting/Pausing/Resuming a Print Job 5-17...
Page 255: Using The Various Printing Functions
■ Scaling Print Output (See p. 5-50) Specify this option when A4 size data is reduced in size and printed on B5 size paper, or B5 size data is enlarged and printed on A4 size paper. You can specify an arbitrary scaling.
Page 256 ■ Poster Printing (See p. 5-52) You can magnify a single page image and print it out on multiple sheets of paper. You can join these printouts together to make one large poster. ■ Watermark Printing (See p. 5-53) You can superimpose watermarks (such as [COPY], [DRAFT], etc.) over the documents created by an application.
Page 257 Allows you to print 2-page document on the both sides of one sheet of paper. • [Booklet Printing] By printing 2 pages on both sides of paper and folding the paper into two, the pages are aligned properly and ready to be bound into a booklet (Therefore, 4 pages in total are printed on a single sheet of paper).
Page 258 Printouts of a complete job are grouped. For example, if you are printing three copies of a 3-page document, printouts of a complete job are grouped, arranged in this page order: 1, 1, 1, 2, 2, 2, 3, 3, 3. • [Collate] Printouts of a complete job are collated.
Page 259 ■ Printing with the Data 180 Degrees Rotated (See p. 5-63) You can print with the image 180 degrees rotated. This option is useful for printing envelopes and Index Card size media that can be fed only in speciﬁc orientations.
Page 260 ■ Color Settings (See p. 5-67) You can perform color printing with the colors originally speciﬁed. ■ Specifying the Brightness and Contrast (See p. 5-69) You can perform color printing with the brightness and contrast speciﬁed. Using the Various Printing Functions 5-23...
Page 261 Adjustment] sheet. ■ Editing Jobs with PageComposer (See p. 5-76) You can combine two jobs into one and change the job settings for the combined job. You can edit a job in another application. You can also preview the job.
Page 262: Various Pages In The Printer Driver
The [Printer Properties] dialog box and the [Document Properties] dialog box contain the following sheets that allow you to specify the various printing functions. You can switch among the sheets by clicking the tabs across the top of the dialog box.
Page 263: [Page Setup] Sheet
- [Conﬁguration] Sheet NOTE The [General], [Details], [Sharing], and [Color Management] sheets in the [Printer Properties] dialog box are displayed by Windows. For details on these sheets, see Windows Help. [Page Setup] Sheet The [Page Setup] sheet allows you to specify the following printing preferences:...
Page 264 ■ [Custom Paper Size Settings] Dialog Box The following dialog box is displayed by clicking [Custom Paper Size]. This dialog box allows you to specify the height and width of custom paper size, which is different from the standard paper sizes.
Page 265 Registers custom paper sizes. ■ [Edit Watermark] Dialog Box (See p. 5-54) The following dialog box is displayed by clicking [Edit Watermark]. This dialog box allows you to add new watermarks and edit the added watermarks. 5-28 Using the Various Printing Functions...
Page 266 Displays a list of registered watermarks. The watermarks with a small [Watermark List] red mark placed at the left side of the name are provided by default. These provided watermarks cannot be deleted. Allows you to add and specify a new watermark in the [Edit [Add] Watermark] dialog box (Up to 50 watermarks can be added).
Page 267 ■ [Page Options] Dialog Box (See p. 5-55) The following dialog box is displayed by clicking [Page Options]. This dialog box allows you to specify borders, date, and page numbers, etc. to be printed on the printouts. Setting/Button Contents You can select the type of edging to print as a border. When a...
Page 268: [Finishing] Sheet
Displays a dialog box for detailed settings for [Paper Alignment]. Displays the settings speciﬁed in the [Detailed Settings] dialog [Paper Alignment] box. [Binding Location] (See You can specify which edge of the printed paper is to be bound. p. 5-59) Using the Various Printing Functions 5-31...
Page 269 ﬁnishing details and print mode appropriate to the paper. ■ [Detailed Settings for Booklet] Dialog Box When [Booklet Printing] is selected, click [Booklet] to display the following dialog box as needed. This dialog box allows you to specify the settings for booklet printing.
Page 270 ﬁt the remaining space. ■ [Gutter Settings] Dialog Box (See p. 5-59) The following dialog box is displayed by clicking [Gutter]. This dialog box allows you to specify the width of the gutter and image processing method. Using the Various Printing Functions...
Page 271 Setting/Button Contents When a value is speciﬁed, a margin of white space is created on one side of the printed paper (This margin is called [Gutter]). The [Gutter] gutter is useful when binding pages. Valid values for [Gutter] range from 0 to 30 mm.
Page 272 - When [Paper Type] in the [Paper Source] sheet is set to [Heavy Paper 1], [Heavy Paper 2], [Transparency], or [Label]: The job is paused (If paper is loaded in the manual feed slot, however, the printer does not pause the job but prints using the paper).
Page 273: [Paper Source] Sheet
■ [Advanced Settings] Dialog Box The following dialog box is displayed by clicking [Advanced Settings] in the [Finishing Details] dialog box. This dialog box allows you to specify the ﬁnishing details. Setting/Button Contents Print quality may deteriorate depending on the type of...
Page 274: Quality] Sheet
You can specify the type of paper. (See p. 3-3) It is not recommended to print the other side of paper previously printed by this printer. However, if you have to print on both sides [Print on the Other Side] of paper, select the [Print on the Other Side] check box when printing the other side of the previously printed paper.
Page 275 Server 2003 only) (See is printed in the center of the paper, and this is surrounded by p. 5-71) images where the color tone is changed by 1 unit in each of the corresponding directions. ■ [Custom Settings] Dialog Box The following dialog box is displayed by clicking [Settings].
Page 276 [Toner Density] Adjusts the toner density for the print data. (See p. 5-66) The toner save mode is used to print a test page. By using the toner [Toner Save]* save mode, you can print by thinning out the print data.
Page 277 * Using the toner save mode may decrease print density, making printed text look patchy. - When printing without using the toner save mode - When printing using the toner save mode ■ [Color Settings] Dialog Box The following dialog box is displayed by clicking [Color Settings].
Page 278 Contents [Matching Mode] You can specify the method for color correction. [Application Color If the check box for this option is cleared, you can print with the Matching Priority] color matching process speciﬁed in the printer driver prioritized. (Windows 2000/XP/...
Page 279: [Conﬁguration]/[Device Settings] Sheet
[Single-page Batch Performs CanoFine processing by treating all of the bitmap data Processing] in one page as a single piece of data. When the check box for (Windows 2000/XP/ this option is selected, revolved or cut-out bitmap data may be Server 2003 only) printed clearly.
Page 280: [Proﬁle] Sheet (Windows 2000/Xp/Server 2003 Only)
[Proﬁle] Sheet (Windows 2000/XP/Server 2003 only) This sheet allows you to add new "Proﬁles" and edit the previously registered "Proﬁles". For details on specifying "Proﬁles", see "Specifying "Proﬁles"," on p. 5-72.
Page 281 Contents [Comment] Displays a comment about the "Proﬁle" selected in [Proﬁle List]. Displays the [View Settings] dialog box. You can view and conﬁrm all of [View Settings] the current page settings. Displays the [Add/Edit Proﬁle] dialog box and allows you to add a new [Add] "Proﬁle".
Page 282 The following dialog box is displayed by clicking [Add] or [Edit]. This dialog box allows you to enter [Name], [Icon], [Comment], and the printing preferences for the newly added "Proﬁle" or the one that you want to edit. Setting/Button Contents [Name] You can enter the name for the "Proﬁle".
Page 283: Preview
Right-clicking on Preview selects [1 Page per Sheet [1-sided]], [2 Pages per Sheet [1-sided]], [4 Pages per Sheet [1-sided]], [1 Page per Sheet [2-sided]], [2 Pages per Sheet [2-sided]], [4 Pages per Sheet [2-sided]], [Black and White], [Color], or [Auto Detect].
Page 284 Left-clicking the paper source image (manual feed slot or paper cassette image) on Preview speciﬁes the paper source. If you want to switch the paper source automatically according to the size or type of paper, left-click [Auto] on the lower right on Preview. Also, right-clicking on Preview speciﬁes [Finishing].
Page 285: Printing Multiple Pages On One Sheet
Display the [Page Setup] sheet, then select the number of the pages to be printed on one sheet from [Page Layout]. The number of pages that can be selected is 1, 2, 4, 6, 8, 9, or 16 (Pages per Sheet).
Page 286 When [Page Layout] is set to 2, 4, 6, 8, 9, or 16 (Pages per Sheet), [Page Order] appears. Specify how the pages are aligned. NOTE The options under the [Page Order] pull-down menu differ depending on the paper orientation or the number of pages to be printed on one sheet.
Page 287: Scaling Print Output
Scaling Print Output You can select a scale when [Page Layout] is set to [1 Page per Sheet]. When the settings for [Page Size] and [Output Size] are different from each other, the scale factor is adjusted automatically. The scale factor can also be speciﬁed manually.
Page 288: Scaling A Document Manually
Scaling a Document Manually Display the [Page Setup] sheet, then specify the page size in [Page Size]. Specify the paper size in [Output Size]. Select the [Manual Scaling] check box, then specify the value in the spin box. Conﬁrm the settings, then click [OK].
Page 289: Poster Printing
Poster Printing You can magnify a single page image and print it out on multiple sheets of paper. You can join these printouts together to make one large poster. If you are using Windows 2000/XP/Server 2003, display the [Device Settings] sheet, and then make sure that [Spooling at Host] is set to [Auto].
Page 290: Watermark Printing
You can superimpose watermarks (such as [COPY], [DRAFT], etc.) over the documents created by an application. Select the desired character string from the list of the character strings registered as watermarks. Also, you can add new watermarks or edit the already registered watermarks by clicking [Edit Watermark] in the [Page Setup] sheet.
Page 291: Editing Watermarks
Editing Watermarks If you are using Windows 2000/XP/Server 2003, display the [Device Settings] sheet, and then make sure that [Spooling at Host] is set to [Auto]. Display the [Page Setup] sheet, select the [Watermark] check box, and then click [Edit Watermark].
Page 292: Printing Borders And Printing Date
NOTE • For more details on the settings, see "Various Pages in the Printer Driver" (p. 5-25) or Online Help. For details on methods for displaying Online Help, see "How to Use Online Help," on p. 5-79. • When adding a new watermark, click [Add].
Page 293 Specify the options as needed. NOTE For more details on the settings, see "Various Pages in the Printer Driver" (p. 5-25) or Online Help. For details on methods for displaying Online Help, see "How to Use Online Help," on p. 5-79.
Page 294: Selecting A Print Style
Selecting a Print Style Allows you to select the print style (1-sided Printing, 2-sided Printing, or Booklet Printing). IMPORTANT For Windows 2000/XP/Server 2003, [Booklet Printing] is disabled when [Spooling at Host] is set to [Disabled] in the [Device Settings] sheet.
Page 295 NOTE For more details on the settings, see "Various Pages in the Printer Driver" (p. 5-25) or Online Help. For details on methods for displaying Online Help, see "How to Use Online Help," on p. 5-79.
Page 296: Printing With A Gutter
Printing with a Gutter You can specify a gutter on the printouts. Valid gutter values range from 0 to 30 mm. When a gutter is speciﬁed, the position of the page image is adjusted to make room for the gutter. At this point, you can select whether to reduce the size of the image to ﬁt the remaining space.
Page 297: Specifying The Paper Output Method
Printouts of a complete job are grouped. For example, if you are printing three copies of a 3-page document, printouts of a complete job are grouped, arranged in this page order: 1, 1, 1, 2, 2, 2, 3, 3, 3. • [Collate] Printouts of a complete job are collated.
Page 298: Printing With Upper Left Of Sheet As Starting Point
IMPORTANT • The edge of paper may be missing partly, or optimum print quality may not be obtained depending on the print data to be printed. • The function of [Print with Upper Left of Sheet as Starting Point] may be disabled depending on the application you are using.
Page 299 Select the [Print with Upper Left of Sheet as Starting Point] check box. Conﬁrm the settings, then click [OK]. The [Finishing] sheet reappears. Click [OK]. Click [OK] or [Print]. The printer starts printing. 5-62 Using the Various Printing Functions...
Page 300: Printing With The Data 180 Degrees Rotated
Printing with the Data 180 Degrees Rotated Prints with the image 180 degrees rotated. This option is useful for printing envelopes and Index Card size media that can be fed only in speciﬁc orientations. Display the [Finishing] sheet, then click [Finishing Details].
Page 301: Smoothing Out Rough-Textured Images
Smoothing Out Rough-Textured Images When image data such as photographic images are enlarged in size in an application and printed, the printed images can look rough or jagged. You can print this kind of low-resolution image data with smoothing it out.
Page 302 Select the [Enable Image Correction] check box. Conﬁrm the settings, then click [OK]. The [Quality] sheet reappears. Click [OK]. Click [OK] or [Print]. The printer starts printing. Using the Various Printing Functions 5-65...
Page 303: Printing With Toner Density Adjusted
Adjust the toner density by dragging the [Toner Density] slider of each color from side to side. Move the slider to the right to make it darker and to the left to make it lighter. 5-66 Using the Various Printing Functions...
Page 304: Color Settings
[Preview Image] at the center of [Adjustment Grid] from side to side or up and down. When [Preview Image] is in the center, the image has not been adjusted. There are three methods to adjust it as follows: •...
Page 305 • Dragging [Preview Image] in the center onto the desired color. Conﬁrm the settings, then click [OK]. The [Quality] sheet reappears. If you are using Windows 2000/XP/Server 2003, you can print an adjusted color sample. For more details, see "Printing a Color Sample (Windows 2000/XP/Server 2003 only)," on p. 5-71.
Page 306: Specifying The Brightness And Contrast
Specifying the Brightness and Contrast You can perform color printing with the brightness and contrast speciﬁed. Display the [Quality] sheet, select the [Manual Color Settings] check box, and then click [Color Settings]. Using the Various Printing Functions 5-69...
Page 307 Display the [Color Adjustment] sheet, then adjust the brightness and contrast for the print data. Move the [Brightness] slider to the right to make it lighter and to the left to make it darker. Move the [Contrast] slider to the right to make it higher and to the left to make it lower.
Page 308: Printing A Color Sample (Windows 2000/Xp/Server 2003 Only)
Adjustment] sheet. [Preview] is printed in the center of the paper, and this is surrounded by images where the color tone is changed by 1 unit in each of the corresponding directions. This is useful to adjust the colors on the printed paper.
Page 309: Specifying "Proﬁles
- [Prioritize Printing of Colored Lines and Text] NOTE • For Windows 98/Me, up to 50 "Proﬁles" can be added. To make it possible to add up to 50 "Proﬁles" for each user account, double-click [My Computer] ➞ [Control Panel] ➞...
Page 310: Adding A "Proﬁle
[Icon] allows you to select the icon for the "Proﬁle". Enter any comments in [Comment] as needed. NOTE You can enter up to 31 characters for [Name] and up to 255 characters for [Comment]. Using the Various Printing Functions 5-73...
Page 311 Click [View Settings]. ❑ When [OK] is clicked, the [Add Proﬁle] dialog box reappears. Click [OK]. The Properties dialog box reappears. Make sure that the name of the added "Proﬁle" is in [Proﬁle List]. 5-74 Using the Various Printing Functions...
Page 312: Editing/Deleting A Proﬁle
Editing/Deleting a Proﬁle You can change or save the Proﬁle information or delete it from [Proﬁle List]. Click [ ] (Edit Proﬁle). Edit information about the "Proﬁles". ● Editing a Proﬁle ❑ You can change the settings for [Name], [Icon], and [Comment].
Page 313: Editing Jobs With Pagecomposer
❑ When [Export] is clicked, information about the selected "Proﬁle" is saved into the ﬁle. The "Proﬁle" saved in the ﬁle can be used again even if it is deleted from the list. ❑ When the [Apply Settings from Application] check box is selected, the settings for [Page Size], [Orientation], and [Copies] speciﬁed in the application are...
Page 314 The message that informs you that the output method is going to be switched to the [Edit and Preview] mode is displayed. Click [OK]. Specify the printing preferences in each sheet, then click [OK]. The [Print] dialog box reappears. Using the Various Printing Functions...
Page 315 • For more details on the setting procedures for the [Canon PageComposer] dialog box, see Help for Canon PageComposer. • When the [Edit and Preview] mode is selected in the [Printer Properties] dialog box and [ ] (Lock) is set, the [Canon PageComposer] dialog box appears each time you print.
Page 316: How To Use Online Help
Displaying Online Help on the Options Displayed on the Screen There are three methods to display Online Help on the windows of the printer driver or the Printer Status Window. • Right-click the item of which you want to display Online Help, then click [What's This?] from the pop-up menu.
Page 317: Displaying Online Help On The Operation Procedures
] (Help) on [Titlebar], move the [?]-attached cursor to the item of which you want to display Help, then click it. • Press the [TAB] key on your keyboard to select the item of which you want to display Help, then press the [F1] key.
Page 318 Click [Contents]. Double-click the title of which you want to know the operation procedure. How to Use Online Help 5-81...
Page 319: Retrieving The Option About Which You Want To Know With Keywords And Displaying Its Online Help
Retrieving the Option about Which You Want to Know with Keywords and Displaying its Online Help Retrieve the option about which you want to know with keywords and display its Online Help using the following procedure. Click [Help]. 5-82 How to Use Online Help...
Page 320 Click [Index]. Enter the keyword to display the option about which you want to know. How to Use Online Help 5-83...
Page 321 Depending on your operating system, a list of words created automatically may be displayed on [Find]. You can also display Online Help by selecting a word that is related to the option about which you want to know from the displayed word list.
Page 322: Manuals
Insert the supplied "LBP5100 User Software" CD-ROM into the CD-ROM drive. If the CD-ROM is already in the drive, eject the disk and re-insert it into the drive. IMPORTANT If CD-ROM Setup does not appear, select [Run] from the [Start] menu, enter "D:\English\MInst.exe", and then click [OK].
Page 323 Clear the [Printer Driver] check box, then click [Install]. Conﬁrm the contents, then click [Yes]. Installation of the instruction manuals starts. 5-86 Manuals...
Page 324 Click [Exit]. The installation of the manuals is completed. To see the manuals, double-click [LBP5100 Online Manuals] created on the desktop to display respective manuals or select [Canon LBP5100] - [LBP5100 Online Manuals] added to [All Programs] ([Programs] for Windows 98/Me/2000) under the [Start] menu.
Page 325: Uninstalling The Manuals
If the manuals are installed on Windows 2000/XP/Server 2003 logged on by a user who is a member of Administrators, they cannot be uninstalled from the computer logged on by anyone other than users who are members of Administrators. Be sure to log on as a member of Administrators before the uninstallation.
Page 326: Printer Status Window
• You can check the amount of toner remaining (See p. 5-95) • You can register the size of paper to be loaded in the paper cassette (See p. 3-17) • You can check information (the user name, document name, etc.) about the current print job.
Page 327: Functions On The Printer Status Window
Functions on the Printer Status Window The functions on the Printer Status Window are the same on both Windows 98/Me and Windows 2000/XP/Server 2003. For more details on operations, see Online Help. For details on methods for displaying Online Help, see "How to Use Online Help," on p. 5-79.
Page 328: Other Functions
Obtains the printer status and refreshes the Printer Status Window display. [Resolve Error] Button Allows you to resume a job when the job is paused for some reason. [Current Print Job] Tab [Progress Bar]: Indicates the progress of the current job by showing the number of printed pages or changing the background color.
Page 329: Displaying The Printer Status Window
[Page Setup] sheet in the [Document Properties] dialog box. • Display the [Printer Properties] dialog box and display the [Conﬁguration]/[Device Settings] sheet, and then select the [Show Icon in the Taskbar] check box. The icon for the Printer Status Window is displayed in the Windows taskbar. Click the icon, then click the printer name to run it.
Page 330 When a toner cartridge Blinks with the needs to be replaced Does not change Does not change window minimized* soon Indicates the status of the Printer Status Window displayed in the Windows taskbar as follows. Printer Status Window 5-93...
Page 331: [Preferences] Menu
When [Display Settings] in the [Preferences] dialog box is set to [When Starting Printing] (See "[Preferences] Menu," on p. 5-94) When [Display Settings] in the [Preferences] dialog box is set to [When Starting Printing] or [Only when Errors Occur] (See "[Preferences] Menu," on p. 5-94)
Page 332: [Consumables/Counters] Menu
Select [Consumables/Counters] from the [Options] menu to display the [Consumables/Counters] dialog box. In the [Consumables/Counters] dialog box, icons and messages that indicate life of toner cartridges of each color and the number of total printed pages are displayed. You can obtain the same result by clicking [ ] (Consumables/Counters) in the Printer Status Window.
Page 333: [Utility] Menu
Specify whether to use the sleep mode or the time to switch to the sleep mode. When data is not sent from the computer or when the printer status remains as it is longer than the time speciﬁed in [Time to Enter Sleep Mode], the printer switches to the sleep mode.
Page 334: [Refresh]
Also, you can specify whether the printer performs calibration automatically when data is not sent from the computer or when the printer status remains as it is longer than the ﬁxed period. Additionally, you can specify whether calibration should be prioritized immediately after the printer is turned ON or when calibration needs to be performed for some reason.
Page 335: Displaying Printer Status When Using A Print Server
[Delete Job]: Deletes the ﬁrst The [My Job Operation] tab is displayed by clicking the [Pause Job] button. If any job is printed by the computer as the print server, the job is displayed. - Plays a sound. - If the print server is running Windows 2000/XP/Server 2003, the status is not displayed when no one is logged on.
Page 336 - You cannot use the [Resolve Error] button when another user's job is paused. - While another user's job is being printed, [Progress Bar] is displayed in gray. - Sounds are played only from the clients whose user name is veriﬁed by the print server.
Page 337 5-100 Printer Status Window...
Page 338: Routine Maintenance
Performing Calibration Automatically..........6-19 Specifying Whether Calibration Should Be Prioritized ....... .6-20 Cleaning the Fixing Roller.
Page 339: Replacing Toner Cartridges
When a Message Appears Toner cartridges are consumable products. When a toner cartridge is nearing the end of its life, a message will appear in the Printer Status Window. Follow the directions in the message. When it is...
Page 340 If the printing appears faint or inconsistent even when a message does not appear, this may be due to any toner cartridge reaching the end of its life. Do not continue to use the toner cartridge and replace it with new one when there is deterioration in print quality.
Page 341: Replacing Toner Cartridges
• For details on how to handle a toner cartridge, see "Precautions for Handling Toner Cartridges," on p. 6-13. • The packing materials may be changed in form or position to be placed, or may be added or removed without notice.
Page 342 ETB unit (A) as shown in the ﬁgure so that the paper is not shifted. IMPORTANT • When installing or removing the toner cartridges, be sure to place paper on the transfer belt of the ETB unit to protect the belt. Replacing Toner Cartridges...
Page 343 ETB unit is supplied with a function that cleans itself, therefore, do not clean the belt even when the toner is on it. If the ETB unit is broken or transfer belt is damaged, this may result in misfeeds or deterioration in print quality.
Page 344 Holding the toner cartridge that you want to replace by the blue tabs on the both sides, pull it horizontally. Holding the toner cartridge with your both hands ﬁrmly, pull it out so that you do not touch the transfer belt of the ETB unit.
Page 345 Take the new toner cartridge out of the protective bag after taking it out of the package. There is a cut near the arrow on the protective bag, so you can open it by hand. However, if you cannot open it by hand, use scissors to open the protective bag so as not to damage the toner cartridge.
Page 346 • Be sure to shake the toner cartridge gently. If you do not shake the cartridge gently, toner may spill out. Place the toner cartridge on a ﬂat surface, detach the tab of the sealing tape from the side of the toner cartridge...
Page 347 • Pull out the sealing tape completely from the toner cartridge. If any tape remains in the toner cartridge, this may result in poor print quality. • When pulling out the sealing tape, be careful not to hold the drum protective shutter (A) with your hands.
Page 348 Hold the toner cartridge with both hands and install it into the printer. Align (A) of the toner cartridge that you want to replace with the slots (B) to which the label of the same color is attached, then insert the cartridge until it stops.
Page 349 • If you cannot close the front cover, check if the toner cartridge is installed properly. If you try to close the front cover forcefully, this may result in damage to the printer. • Do not leave the front cover open for a long time after installing the toner cartridge.
Page 350: Precautions For Handling Toner Cartridges
IMPORTANT • When you take the toner cartridge out of the printer for servicing the printer, place the toner cartridge into the original protective bag, or wrap it with a thick cloth immediately.
Page 351 • Do not jolt the toner cartridge memory (D) or bring it near a magnetic ﬁeld. This may result in damage to the cartridge. • When handling a toner cartridge, hold it properly as shown in the ﬁgure and handle it with the arrowed side facing up.
Page 352: Storing Toner Cartridges
IMPORTANT • Do not take a new toner cartridge out of the protective bag until it is ready to be used. • When you take the toner cartridge out of the printer for servicing the printer or other purposes, place the toner cartridge into the original protective bag, or wrap it with a thick cloth immediately.
Page 353: Calibrating The Printer
Calibrating the Printer Perform calibration when the colors have changed and the data is not printed in the correct colors (speciﬁed colors) or a phenomenon of "Out-of-Register Colors" occurs. You can perform calibration manually or automatically at the designated time everyday. Also, you can specify whether the printer performs calibration automatically when data is not sent from the computer or when the printer status remains as it is longer than the ﬁxed period, or whether calibration should be...
Page 354: Performing Calibration Automatically At The Designated Time
Perform calibration automatically at the designated time using the following procedure. IMPORTANT When the printer is under any of the following status, calibration is not performed even if the speciﬁed time has come. - During printing (Calibration is performed after the print job ﬁnishes. However, calibration is also performed when approximately 150 pages are printed.)
Page 355 Display the Printer Status Window. For details on methods for displaying the Printer Status Window, see "Displaying the Printer Status Window," on p. 5-92. From the [Options] menu in the Printer Status Window, select [Device Settings] ➞ [Calibration Settings]. Select the [Use Periodical Calibration Timer] check box in the [Calibration Settings] dialog box, then specify the time to perform calibration in [Time].
Page 356: Performing Calibration Automatically
ﬁxed period*, perform the following procedure. * First, calibration is performed in an hour, and then another calibration is performed in four hours (calibration is not performed anymore afterward).
Page 357: Specifying Whether Calibration Should Be Prioritized
Printing is to be prioritized by default. IMPORTANT • When any toner cartridge is replaced, calibration is prioritized even if [Print Priority] is selected. • If calibration is performed for some reason by the completion of the printing, another calibration is not performed even with [Print Priority] selected after the completion of the printing.
Page 358 Display the Printer Status Window. For details on methods for displaying the Printer Status Window, see "Displaying the Printer Status Window," on p. 5-92. From the [Options] menu in the Printer Status Window, select [Device Settings] ➞ [Calibration Settings]. Select [Print Priority] or [Calibration Priority] from [Action for Calibration Request].
Page 359: Cleaning The Fixing Roller
Print quality deterioration can be prevented by cleaning the ﬁxing roller. IMPORTANT The cleaning page cannot be printed on any paper other than A4. Be sure to use A4 size paper. NOTE • When the printer is used as a shared printer, you cannot perform cleaning from a client computer.
Page 360 Do not touch the cleaning page until it is output to the output tray completely. The cleaning page is ﬁrst output partially after the front side is printed, and then it is fed again to be printed on the reverse side.
Page 361: Cleaning The Static Charge Eliminator
Cleaning the Static Charge Eliminator When the print quality has deteriorated compared to when you just purchased the printer, there is a possibility that the static charge eliminator is dirty. Clean the static charge eliminator using the following procedure. IMPORTANT...
Page 362 Move the static charge eliminator cleaner back to its original position (left edge) after the cleaning ﬁnishes. If you do not move back the static charge eliminator cleaner to the proper position, some of the printed image may be missing in the shape of a band.
Page 363: Cleaning The Outside Of The Printer
• When using a mild detergent, be sure to dilute it with water. • Grease or oil does not have to be applied to this printer. Be sure not to apply grease or oil.
Page 364 Firmly wring a soft cloth dampened with water or a mild detergent diluted with water, and wipe off the dirt. If you use a mild detergent for cleaning, be sure to wipe away the detergent with a soft cloth dampened with water.
Page 365 After wiping off the dirt, wipe the printer with a dry cloth. When the printer is completely dry, plug the power plug into the AC power outlet, and then connect the USB cable. 6-28 Cleaning the Outside of the Printer...
Page 366: Moving The Printer
When changing the location of the printer or moving the printer for maintenance, be sure to perform the following procedure. CAUTION Do not carry the printer with the paper cassette attached. If you do so, the paper cassette may drop resulting in personal injury. IMPORTANT Make sure that the front cover and output tray are closed before carrying the printer.
Page 367 WARNING Be sure to turn the printer and computer OFF, unplug the power plug, and then disconnect all the interface cables from the printer before moving the printer. Otherwise, the power cord or interface cables may be damaged, resulting in a ﬁre or electrical shock.
Page 368 While holding the paper cassette with both hands, remove it from the printer unit as shown in the ﬁgure b. Remove the cassette protective cover. Pressing the right side of the cassette protective cover a, remove it b. Moving the Printer...
Page 369 Move the printer unit from the installation site. Carry the printer with 2 or more people by holding the center of the lift handles on the lower portion of the printer and lifting it up at the same time. CAUTION •...
Page 370 • • • • Be sure not to hold the printer by the front panel, delivery slots, or any portions other than the lift handles. If you do so, you may drop the printer, resulting in personal injury. • • • • The front portion of the printer (A) is relatively heavy. Be careful not to get off-balanced when lifting the printer.
Page 371 • • • • Do not carry the printer with the paper feeder installed. If you do so, the paper feeder may drop resulting in personal injury. NOTE If the optional paper feeder was previously installed in the printer, place the paper feeder on the new installation site before carrying the printer to the site.
Page 372 Install the cassette protective cover. Install the left side of the cassette protective cover a on the printer, then while pressing the right side of the cover b, insert the cover into the back of the printer c as shown in the ﬁgure.
Page 373 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. CAUTION When setting the paper cassette in the printer, be careful not to catch your ﬁngers.
Page 374 ● Transporting the Printer When transporting the printer for reasons such as relocating, remove the toner cartridges and store the printer and the parts in the package that they came in with the packing materials attached in order to prevent them from being damaged while being transported.
Page 375: Handling The Printer
• For details on how to handle the printer, also read "Important Safety Instructions" (See p. xviii). • Do not place any heavy objects on the printer, trays, or covers. This may result in damage to the printer. • Do not leave each cover open longer than required. Exposing the printer to direct sunlight or strong light may result in deterioration in print quality.
Page 376 OFF and allow the printer to cool down sufﬁciently before covering the printer. • If you do not plan to use the printer for a long period of time, unplug the power plug from the AC power outlet.
Page 377 6-40 Handling the Printer...
Page 378: Troubleshooting
The Alarm Indicator is On (a Service Error Appears)....... . .7-21...
Page 379: Troubleshooting Map
Troubleshooting Map If any problem occurs while you are using the printer, follow the ﬂow chart shown below to check the problem. The printer The printer driver is not installed properly. driver fails (See "Installation Problems," on p. 7-39) to print.
Page 380: Paper Jams
There are some areas inside the printer which are subject to high-voltages. When removing jammed paper or when inspecting the inside of the printer, do not allow necklaces, bracelets, or other metal objects to touch the inside of the printer, as this may result in burns or electrical shock.
Page 381 CAUTION • • • • The ﬁxing unit and its surroundings inside the printer are hot during use. Make sure the ﬁxing unit is completely cool before removing the jammed paper. Touching the ﬁxing unit when it is still hot may result in burns.
Page 382 • If paper is torn, be sure to ﬁnd and remove any remaining pieces of paper. • Do not place any object on or touch the transfer belt (A) of the ETB unit. The transfer belt of the ETB unit is supplied with a function that cleans itself, therefore, do not clean the belt even when the toner is on it.
Page 383: Paper Jam Area
Paper Jam Area The messages displayed in the Printer Status Window indicate where the paper is jammed, and there are the following kinds. Output Tray Duplex Print Transport Area Cassette 1 Manual Feed Slot Paper Feeder Unit (Optional) Cassette 2...
Page 384: Procedure For Clearing Paper Jams
IMPORTANT The error message may remain if jammed paper is removed without opening the front cover or top cover. In this case, open and close the front cover or top cover once. Open the front cover. Holding the opening of the front cover, open it gently.
Page 385 Remove any jammed paper by pulling it in the direction of the arrow. Remove the jammed paper in the direction of the arrow gently to prevent unﬁxed toner from spilling. Remove the paper, being careful not to touch the transfer belt of the ETB unit or toner cartridge.
Page 386 IMPORTANT If the jammed paper cannot be removed easily, do not try to remove it forcefully but proceed to the next step. If a paper jam occurs when performing 2-sided printing, perform the following procedure. If you are not performing 2-sided printing, proceed to the next step.
Page 387 ❑ Pull the rear edge of the jammed paper a, then pull out the paper in the direction of the arrow to remove the paper b as shown in the ﬁgure. 7-10 Paper Jams...
Page 388 Holding the top cover by the hooks (A) on the both side a a a a open the top cover b b b b Paper Jams 7-11...
Page 389 When the paper is caught in the top cover, pull out the top edge of the paper , and then remove the paper as shown a a a a b b b b in the ﬁgure. 7-12 Paper Jams...
Page 390 Holding the opening of the front cover, close it gently. CAUTION When closing the front cover, be careful not to catch your ﬁngers. Perform the following procedure with the top cover open. Be careful so that the top cover does not close.
Page 391 Pull out the paper cassette. Pull out the paper cassette gently a. While holding the paper cassette with both hands, remove it from the printer unit as shown in the ﬁgure b. 7-14 Paper Jams...
Page 392 If the optional paper feeder is installed, pull out the paper cassette of the paper feeder. Pull out the paper cassette gently a. While holding the paper cassette with both hands, remove it from the paper feeder as shown in the ﬁgure b. Paper Jams...
Page 393 Remove any jammed paper while pushing it downward to some extent. In case of the printer unit In case of the paper feeder 7-16 Paper Jams...
Page 394 IMPORTANT Do not touch the feed rollers (A) in the printer unit and paper feeder. This may result in damage to the printer or printer error. Paper Jams 7-17...
Page 395 Set the paper cassette in the printer. Push the paper cassette into the printer ﬁrmly until the front side of the paper cassette is ﬂush with the front surface of the printer. 7-18 Paper Jams...
Page 396 If the paper feeder is installed, set the paper cassette of the paper feeder also. CAUTION When setting the paper cassette in the printer, be careful not to catch your ﬁngers. Close the top cover. Paper Jams 7-19...
Page 397: The Alarm Indicator Is On/Blinking
When a problem has occurred in the printer, the (Alarm) indicator (orange) comes on or blinks. If the (Alarm) indicator is on, see "The Alarm Indicator is On (a Service Error Appears)" (p. 7-21), and if the (Alarm) indicator is blinking, see "The Alarm Indicator is Blinking"...
Page 398: The Alarm Indicator Is On (A Service Error Appears)
The Alarm Indicator is On (a Service Error Appears) When a problem has occurred and the printer does not work properly, the (Alarm) indicator (orange) comes on and the following service error appears in the Printer Status Window. Service Call...
Page 399 Turn the power OFF, wait for 10 seconds or longer, and then turn it ON again. If the message does not reappear, the printer can be used as normal. If the error message still appears, proceed to the next step.
Page 400 Window. Perform the following procedure. Turn the printer OFF a. If a USB cable is connected, turn the computer off b, and then disconnect the USB cable c. Disconnect the power plug from the AC power outlet d. The Alarm Indicator is On/Blinking...
Page 401: The Alarm Indicator Is Blinking
When contacting your Canon dealer, please report the problems and the error code that you have noted. The Alarm Indicator is Blinking When an error has occurred in the printer and the printer needs some measures, (Alarm) indicator (orange) blinks and the following error message appears in the Printer Status Window.
Page 402: Print Quality Problems
• When a paper jam occurs, see "Paper Jams," on p. 7-3. • If a symptom that is not indicated in this section occurs, if none of the indicated remedies solve the problem, or if you cannot determine the problem, contact your local authorized Canon dealer.
Page 403 Remedy Change the paper and print again. (See "Paper Requirements," on p. 3-2) Cause 2 Paper of a wider width was printed just after paper with a narrower width (A5 size etc.) was printed continuously. Remedy To lower the temperature of the ﬁxing unit, wait for a while before printing again.
Page 404 The printer is exposed to direct sunlight or strong light. Remedy Move the printer to a place where it will not be exposed to direct sunlight or strong light. Alternatively, move the strong light source away from the printer. The print is uneven.
Page 405 IMPORTANT Normally, use the printer with [Special Print Mode] set to [Off]. Set [Special Print Mode] to [Special Settings 5] only when this problem occurs. Thin streaks appear on the top or rear edge portion of the printed paper. Cause Data in halftones was printed in a low-humidity environment.
Page 406 [Advanced Settings] in the [Finishing Details] dialog box. IMPORTANT Normally, use the printer with [Special Print Mode] set to [Off]. Set [Special Print Mode] to [Special Settings 1] only when this problem occurs. Thin lines or halftone areas come out faint.
Page 407 A document with no margins was printed. Remedy 1 Data cannot be printed within a 5 mm margin (10 mm for envelopes (7.6 mm for the right margin)) on all sides of the paper. Secure a margin around the data.
Page 408 Remedy 2 Select the [Print with Upper Left of Sheet as Starting Point] check box in the printer driver, then print the document. In order to specify the setting for [Print with Upper Left of Sheet as Starting Point], display the [Finishing Details] dialog box by clicking [Finishing Details] in the [Finishing] sheet.
Page 409 Cause 2 Coarse paper is being used. Remedy 1 Set [Paper Type] to [Heavy Paper 1] or [Heavy Paper 2] in the printer. In order to specify the setting for [Paper Type], display the [Paper Source] sheet. Remedy 2 Set [Special Print Mode] to [Special Settings 4] in the printer driver.
Page 410 Remedy 1 Perform calibration. (See "Calibrating the Printer," on p. 6-16) Remedy 2 If [Use Pure Black] in the printer driver is set to [Never], poor print quality (a phenomenon of "Out-of-Register Colors") may be alleviated. In order to specify the setting for [Use Pure Black], display the [Custom Settings] dialog box by clicking [Settings] in the [Quality] sheet.
Page 411 "Specifying Whether Calibration Should Be Prioritized," on p. 6-20) • If you want to perform calibration manually, see "Performing Calibration Manually," on p. 6-16. The colors of thin lines or ﬁlled-in patterns are different from the speciﬁed colors, or do not appear at all. Cause 1 Some colors cannot be reproduced due to the combination of colors or patterns.
Page 412 In order to specify the setting for [Use Pure Black], display the [Custom Settings] dialog box by clicking [Settings] in the [Quality] sheet. Data is not printed in the correct color (speciﬁed color) even after specifying the same color for a ﬁlled-in pattern and its border.
Page 413 Clean the static charge eliminator. (See "Cleaning the Static Charge Eliminator," on p. 6-24) Square areas that cannot be seen on the display appear around lines or text and are printed in a different color from the other areas. Cause A process that is different from the speciﬁed halftone process or color process...
Page 414: Paper Problems
Paper Problems Paper comes out wrinkled. Cause 1 Paper is loaded in the paper cassette or manual feed slot at an angle. Remedy Load the paper in the paper cassette or manual feed slot straight. (See "Loading Plain Paper, Heavy Paper, Transparencies, or Labels in the Paper Source," on p.
Page 415 Remedy 2 Specify the setting for [Paper Curl Correction at Output] as follows in the printer driver. Specify [Front Side Correction (Minus Curl)] when the paper output to the output tray curls as shown in the following ﬁgure. Specify [Back Side Correction (Plus Curl)] when the paper output to the output tray curls as shown in the following ﬁgure.
Page 416: Installation Problems
If "USB Class Driver" and "LBP5100 Printer Driver" cannot be installed properly, perform the following procedure to check problems. NOTE For details on problems on the network installation, see "Chapter 4 Troubleshooting" in Network Guide. A problem has Check the power supply, cables, etc.
Page 417: Problems On Local Installation
Cause 4 An inappropriate USB cable is being used. Remedy Use a USB cable appropriate for the USB interface of this printer. The USB interface of this printer is USB 2.0 Hi-Speed (Windows 2000/XP/Server 2003 only) and USB Full-Speed (USB1.1 equivalent).
Page 418: Installation Problems When The Printer Is Shared On A Network
Ask your network administrator to change the user permissions. The shared printer cannot be accessed. Cause 1 The user of the computer to be used has not been registered, or the password has not been speciﬁed yet. Remedy Register the user registration of the computer to be used or specify the password on the print server.
Page 419: Printing A Test Page
If you cannot ﬁnd the icon for this printer, ask your network administrator. To install the printer driver, double-click the icon for this printer or drag and drop it into the [Printers and Faxes] folder or [Printers] folder and follow the instructions on the screen.
Page 420: When Uninstallation Fails
● For Windows 2000/XP/Server 2003 ❑ Select the icon for this printer in the [Printers and Faxes] or [Printers] folder, then select [Properties] from the [File] menu. ❑ Click [Print Test Page] in the [General] sheet in the [Printer Properties] dialog box.
Page 421 Properties] dialog box, then click [Add/Remove]. NOTE If [Canon LBP5100] is not displayed in the [Add or Remove Programs] dialog box (the [Add/Remove Programs] dialog box for Windows 2000; the [Add/Remove Programs Properties] dialog box for Windows 98/Me), perform "Uninstalling the USB Class Driver"...
Page 422 Click [Yes]. When the printer is used as a shared printer, the following screen appears. Conﬁrm the contents of the message, and then click [Yes] if you want to uninstall the printer driver. Uninstallation starts. Please wait a moment. Click [Exit].
Page 423: Uninstalling The Usb Class Driver
Uninstalling the USB Class Driver Uninstalling the USB class driver is required when you cannot install the CAPT software properly after uninstalling it once or when you cannot uninstall the CAPT software. Make sure that the computer is connected to the printer with the USB cable and that the printer is ON.
Page 424 NOTE If [Canon LBP5100] is displayed in the [Add or Remove Programs] dialog box (the [Add/Remove Programs] dialog box for Windows 2000; the [Add/Remove Programs Properties] dialog box for Windows 98/Me), see "When Uninstallation Fails" (p. 7-43) to delete [Canon LBP5100] from the [Add or Remove Programs] dialog box (the [Add/Remove Programs] dialog box for Windows 2000;...
Page 425 USB Device], and then click [Remove]. IMPORTANT • If the USB class driver is under [Other Devices], the printer is not installed properly. According to your operating system, select and delete any one of [Canon LBP5100], [Canon CAPT USB Device], or [Unknown device].
Page 426 Disconnect the USB cable from the computer, then restart Windows. After Windows restarts, reinstall the CAPT software. (See "Installing the CAPT Software," on p. 4-4) Installation Problems 7-49...
Page 427: When Data Is Not Sent To The Printer
Cable The following are probable causes when the printer and computer are connected by a USB cable, and the data cannot be printed because it is not sent to the printer. Take the appropriate measures. The printer is not turned ON.
Page 428 If the appropriate port is not selected, select the appropriate one, and then click [OK]. If you cannot ﬁnd the port to be used, uninstall the printer driver and install it again. (See "Uninstalling the CAPT Software," on p. 4-76, "Installing the CAPT Software,"...
Page 429: When The Printer Is Shared On A Network
There is a break in the power cord. Remedy If the printer is turned ON after replacing the power cord with the one that is of the same type and is used for other device, there is a break in the power cord.
Page 430 Cause 2 The print server is not connected to the network properly. Remedy 1 Make sure that the print server and network are connected by a LAN cable properly. Remedy 2 Make sure that the network settings for the print server are appropriate.
Page 431: Miscellaneous Problems
Please wait a moment. The printer cools down the ﬁxing unit automatically. When the printer ﬁnished cooling down the ﬁxing unit, it stops operation and becomes ready to print. If the printer was in the middle of printing, it resumes the job after ﬁnishing the cool down process.
Page 432 When the printer is shared over a network, it takes a long time to obtain the status in the Printer Status Window. Cause You are using a computer with Windows XP Service Pack 2 or another operating system equipped with Windows Firewall as the print server, and Windows Firewall is conﬁgured to block communication with the client...
Page 433: Conﬁrming The Printer Features
NOTE • Conﬁguration Page Print is designed to be printed on A4 size paper. Load A4 size paper. • For details on Network Status Print, see "Chapter 4 Troubleshooting" in Network Guide. Display the Printer Status Window.
Page 434 [Options] menu in the Printer Status Window, and the current printer status such as [Number of Total Printed Pages]. IMPORTANT This is a sample of Conﬁguration Page Print. The contents may differ from the Conﬁguration Page Print printed by your printer. The six-digit alphanumeric...
Page 435 7-58 Confirming the Printer Features...
Page 436 Moving the Printer ............8-3 Removing the Packing Materials and Installing the Paper Feeder ..... . .8-8 Removing the Paper Feeder .
Page 437: Paper Feeder
• Do not touch the connector (A) in the paper feeder. This may result in damage to the printer or misfeeds. • If you are printing from Cassette 2, make sure that Cassette 1 is set before printing. If you print from Cassette 2 when Cassette 1 is not set, this will cause paper jams.
Page 438: Moving The Printer
NOTE Load paper in the paper feeder in the same manner as you load paper in Cassette 1. For more details, see "Chapter 3 Loading and Outputting Paper". Moving the Printer When installing the paper feeder in the printer after installing the printer, move the printer to an appropriate location temporarily using the following procedure.
Page 439 Remove all the interface cables and the power cord from the printer. Close the output tray. Pull out the paper cassette. Pull out the paper cassette gently a. Paper Feeder...
Page 440 While holding the paper cassette with both hands, remove it from the printer unit as shown in the ﬁgure b. Remove the cassette protective cover. Pressing the right side of the cassette protective cover a, remove it b. Paper Feeder...
Page 441 Move the printer unit from the installation site. Carry the printer with 2 or more people by holding the center of the lift handles on the lower portion of the printer and lifting it up at the same time. CAUTION •...
Page 442 • • • • Be sure not to hold the printer by the front panel, delivery slots, or any portions other than the lift handles. If you do so, you may drop the printer, resulting in personal injury. • • • • The front portion of the printer (A) is relatively heavy. Be careful not to get off-balanced when lifting the printer.
Page 443: Removing The Packing Materials And Installing The Paper Feeder
• • • • Put the printer or paper feeder down slowly and carefully. Be careful not to hurt your hands. • • • • Do not carry the printer with the paper cassette attached. If you do so, the paper cassette may drop resulting in personal injury.
Page 444 Pull out the paper cassette. IMPORTANT Do not touch the rubber pad (A) in the paper cassette. This may result in misfeeds. Paper Feeder...
Page 445 While holding the lock release lever of the side paper guides, slide the paper guides. The side paper guides move together. While holding the lock release lever of the rear paper guide, slide the paper guide. 8-10 Paper Feeder...
Page 446 IMPORTANT The paper cassette is provided with a packing material. Be sure to take out the paper cassette to remove the packing material. Place the paper feeder at the installation site. When carrying the paper feeder, hold the lift handles on both sides with both hands as shown in the ﬁgure.
Page 447 • Do not touch the connector (A) in the paper feeder. This may result in damage to the printer or misfeeds. • Do not install the paper feeder on a platform that may warp from the weight of the printer and optional accessories, or where the printer is liable to sink (such as a carpet or mat).
Page 448 IMPORTANT If the printer unit cannot be placed on the paper feeder properly, lift the printer unit once, hold it horizontally, and place it again. If you try to set the printer unit forcefully without lifting it, the connector and positioning pins may be broken.
Page 449 Install the left side of the cassette protective cover a on the printer, then while pressing the right side of the cover b, insert the cover into the back of the printer c as shown in the ﬁgure.
Page 450: Removing The Paper Feeder
ﬁre or electrical shock. CAUTION • • • • Do not carry the printer with the paper cassette attached. If you do so, the paper cassette may drop resulting in personal injury. • • • • Do not carry the printer with the paper feeder installed. If you do so, the paper feeder may drop resulting in personal injury.
Page 451 Turn the printer OFF. If a USB cable is connected, turn the computer off, and then disconnect the USB cable. Disconnect the power plug from the AC power outlet. Remove all the interface cables and the power cord from the printer.
Page 452 Connect the interface cables except for the USB cable, and connect the power cord. Plug the power plug into the AC power outlet. Connect the USB cable. Paper Feeder 8-17...
Page 453: Network Board
Network Board Install the network board in the expansion slot located on the rear of the printer. 1 0 0 L N K E R R Screws (2 pieces) NB-C2 User Software CD-ROM Network board (NB-C2) By installing the optional network board, you can use LBP5100 directly connected to a network.
Page 454 * If you connect this printer via a print server, you can use it as a network printer, which enables printing from other computers that are not directly connected to this printer. If you connect this printer via a print server, you need to perform the following settings: 1.
Page 455: Parts And Their Functions
LAN Connector e e e e ERR Indicator (Orange) Connects to a 10BASE-T/100BASE-TX LAN cable. Comes on or blinks when the network board is not working properly. c c c c 100 Indicator (Green) f f f f MAC Address Comes on when the network board is connected to the network by 100BASE-TX.
Page 456: Installing The Network Board
USB cable c. Disconnect the power plug from the AC power outlet d. Remove the power cord. If there is not enough space to install the network board, move the printer to a place where you can work easier. Network Board...
Page 457 Hold the metal panel portions of the network board and insert the board straight while aligning it with the guide rails inside the expansion slot. IMPORTANT • Do not touch the network board parts, printed wire, or connectors with your hands. • Insert the network board securely. 8-22...
Page 458: Connect The Lan Cable
NOTE This network board does not come with a LAN cable. A Category 5 twisted pair cable is required for installing the network board and connecting the printer to a network. Have cables or a hub ready as needed.
Page 459 Press " " of the power switch to turn the printer ON. IMPORTANT If the printer does not operate properly, or an error message appears in the Printer Status Window, see "Troubleshooting," on p. 7-1. Make sure that the LNK indicator (green) on the network board is on.
Page 460: Setting The Network Board
Set the DIP switches according to the transmission speed of the connected network as follows. IMPORTANT When setting the DIP switches, be careful not to damage the main board with the tip of a ball-point pen etc. Do not use a sharp object such as a mechanical pencil. DIP switches...
Page 461 Disconnect the power plug from the AC power outlet. Remove all the interface cables and the power cord from the printer. Remove the two screws and remove the network board. IMPORTANT Do not touch the network board parts, printed wire, or connectors with your hands. 8-26 Network Board...
Page 462 When setting the DIP switches, be careful not to damage the main board with the tip of a ball-point pen etc. Do not use a sharp object such as a mechanical pencil. Insert the network board into the expansion slot.
Page 463: Resetting The Network Board
If you are going to print via USB also, connect the USB cable. Resetting the Network Board If you want to reset the network board to the default values, use the Remote UI or FTP Client. For details on the Remote UI, see "Chapter 3 Various Functions of the Remote UI"...
Page 464 When setting the DIP switches, be careful not to damage the main board with the tip of a ball-point pen etc. Do not use a sharp object such as a mechanical pencil. Insert the network board into the expansion slot.
Page 465 L N K E R R IMPORTANT When setting the DIP switches, be careful not to damage the main board with the tip of a ball-point pen etc. Do not use a sharp object such as a mechanical pencil. 8-30 Network Board...
Page 466: Removing The Network Board
CAUTION • • • • Be sure to turn the printer and computer OFF and disconnect all the interface cables and power cord from the printer before removing the network board. If a USB cable is connected, turn the computer off, and then remove the USB cable.
Page 467 Store the network board in the protective bag that it came in. IMPORTANT • Do not touch the network board parts, printed wire, or connectors with your hands. • The removed two screws are required when the network board is installed. Keep them where they will not get lost.
Page 468: Appendix
Achieving More Beautiful Color Printing........
Page 469: Speciﬁcations
Black and white printing: 12 pages/min. Color printing: 10 pages/min. * Print speed may drop in stages depending on the Print speed (60 to 90 g/m paper size, paper type, print copies, and the settings of the ﬁxing mode. (This is because the safety function that prevents damage caused by heat becomes active.)
Page 470 Full-Speed (USB1.1 equivalent) User interface 8 LED indicators Expansion slot 110 - 127 V (± 10 %) 50/60 Hz (± 2 Hz) Power supply 220 - 240 V (± 10 %) 50/60 Hz (± 2 Hz) 110 - 127 V Average during operation: approx.
Page 471: Software Speciﬁcations
Software Speciﬁcations Printing software CAPT (Canon Advanced Printing Technology) Data cannot be printed within a 5.0 mm margin on all sides of the paper. (10 mm for envelopes) * The data may be printed with the edges missing when a document...
Page 472: Dimensions Of Each Part
• Standard state Front Surface (mm) Paper cassette Output tray Top cover Front cover Cassette protective cover • State with the paper feeder installed (mm) Front Surface Top cover Paper cassette Output tray Front cover Cassette protective cover Dimensions of Each Part...
Page 473 ■ PAPER FEEDER PF-92 (mm) Front Surface Dimensions of Each Part...
Page 474: About Color Printing
The colors that you see on a computer screen are reproduced from the three basic colors red, green and blue. The 3 primary colors of light, which are red, green and blue, can be combined to give white (additive color mixing).
Page 475: Method For Expressing Color
The three primary colors of light and color are thus in a complementary color relationship. The red in light and cyan in color, green in light and magenta in color, and blue in light and yellow in color complement one another.
Page 476: About Color Printing
In the case of a printer, it is not possible to change the intensity of toner colors. Because of this, a much larger number of dots are used compared to a computer display, and various colors are reproduced by adding K (black) to the C (cyan), M (magenta) and Y (yellow).
Page 477: Achieving More Beautiful Color Printing
ﬁxing unit and is output. Achieving More Beautiful Color Printing If the color in the print are not as expected, or the image quality is low, or the printout takes a long time, the printer performance is halved. By making minor adjustments and taking a little bit of care, we can make sure we get 100% out of the printer.
Page 478: Adjusting The Resolution
■ Adjusting the resolution It does not matter how high the resolution of printing data is, you cannot get better picture quality than the resolution of the printer. A resolution of 600 dpi at printer sizes is sufﬁcient. If the resolution of print data is too high, print processing will take a large amount of time, and the data size will also grow.
Page 479: Netspot Device Installer
The supplied CD-ROM includes the "NetSpot Device Installer", which is a utility that can initialize the settings of a printer connected to the network. The NetSpot Device Installer is software that allows you to easily initialize the settings of printers connected to the network.
Page 480: Print Monitor Installer
- Windows 2000/XP/Server 2003: Standard TCP/IP Port - Windows 98/Me: Canon CAPT Port Use "Print Monitor Installer" as needed such as when you want to create a port (Canon CAPT Port) without using CD-ROM Setup. Print Monitor Installer...
Page 481: Windows Firewall
IMPORTANT If you want to copy "CAPT Windows Firewall Utility" to your hard disk to run it, copy all of the ﬁles (CNAC6FW.EXE, CAPTRGFW.DLL, CNAC6FW.INI) from the [WF_UTIL] folder on the supplied "LBP5100 User Software" CD-ROM to your hard disk.
Page 482: Conﬁguring Windows Firewall To Unblock Communication With The Client Computers
You can also run the utility by selecting [Run] from the [Start] menu, entering "D:\English\WF_UTIL\CNAC6FW.EXE", and then clicking [OK]. (The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using.) Click [Unblock].
Page 483 Panel] from the [Start] menu, then click [Network and Internet Connections] ➞ [Windows Firewall]. Make sure that the [Canon LBP5100 RPC Server Process] check box is selected in the [Exceptions] sheet in the [Windows Firewall] dialog box. Windows Firewall is now conﬁgured to unblock communication with client computers.
Page 484: Conﬁguring Windows Firewall To Block Communication With The Client Computers
You can also run the utility by selecting [Run] from the [Start] menu, entering "D:\English\WF_UTIL\CNAC6FW.EXE", and then clicking [OK]. (The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using.) Click [Block].
Page 485 Click [OK]. Windows Firewall is now conﬁgured to block communication with the client computers. 9-18 Windows Firewall...
Page 486: Conﬁguring Windows Firewall To Unblock Communication With The Print Server
Print Server IMPORTANT If you do not perform the following settings on the client computers, the printer status may not be displayed properly in the Printer Status Window, and some of the printer functions may not operate properly.
Page 487: Index
Custom Settings, 5-38 Add Printer Wizard Windows 2000, 4-39 Windows 98/Me, 4-45 Windows XP/Server 2003, 4-32 Administrators Permission, 4-14, 4-19, 4-32, 4-39 Deleting/Pausing/Resuming a Print Job, 5-16 Advanced Settings, 5-36 Detailed Settings, 5-33 Alarm Indicator, 1-10 Detailed Settings for Booklet, 5-32...
Page 488 Gutter Settings, 5-33 Transparencies, 3-17 Local Installation, 4-55 Local Printer, 4-33, 4-40, 4-46 Heavy Paper, 3-4 M (Magenta) Toner Cartridge Slot, 1-9 MAC Address, 8-20 Manual Color Settings, 5-38, 5-67 Important Safety Instructions, xviii Manual Feed Slot, 1-8, 3-13 Index Card, 3-4...
Page 489 Print Color Sample, 5-38, 5-71 Page Options, 5-30 Print in Different Orientations, 5-31 Page Order, 5-27 Print Monitor Installer, 9-13 [Page Setup] Sheet, 5-26 Print on the Other Side, 5-37 Page Size, 5-26 Print Server, 4-56 PageComposer, 5-78 Print Server Settings, 4-56 Paper...
Page 490 Display, 5-92 Displaying Printer Status When Using a Print Server, 5-98 Scaling, 5-50 Parts and Functions, 5-90 Self-diagnostic Test, 2-36 Preferences Menu, 5-94 Serial Number, 9-25 Refresh, 5-97 Service Error Display, 7-21 Resolve Error, 5-97 Settings, 5-38 Utility Menu, 5-96...
Page 491 Ventilation Slots, 1-7, 1-8 View Settings, 5-44 Watermark, 5-27, 5-53 Windows Firewall, 9-14 Y (Yellow) Toner Cartridge Slot, 1-9 9-24 Index...
Page 492: Location Of The Serial Number
ﬁgure. IMPORTANT The label on which the serial number is indicated is required for service or maintenance. Be sure not to remove them. ■ Inside of the Printer Serial Number ■...
Page 493 9-26 Location of the Serial Number...
Page 494 CANON AUSTRALIA PTY. LTD 1 Thomas Holt Drive, North Ryde, Sydney, N.S.W. 2113, Australia CANON CHINA CO., LTD 15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China CANON SINGAPORE PTE. LTD. 1 HarbourFront Avenue #04-01 Keppel Bay Tower, Singapore 098632 USRM1-1126 (00) ©...
