Adjustable Buckle Strap - Evenflo Revolve360 Extend Owner's Manual

As your child grows, you will need to
change the Buckle Strap position. The
Buckle Strap should ALWAYS be as
close to but NEVER underneath your
child's bottom.
1. Remove Body Pillow if used.
2. Pull the Seat Cover forward and slide
the Buckle Strap through the pad
opening q.
3. Grasp the bottom of the Buckle Strap
and twist it to align with the lengthwise
slot w.
4. Move to slot position closest to but not
underneath your child's bottom e.
5. Twist Buckle Strap back into position
r, then slide through pad opening and
replace Seat Cover.
44
Car Seat Features

Adjustable Buckle Strap

q q
e e
IMPORTANT: Children over 40
lbs (18 kg) MUST use the Buckle
Strap in the outermost position
from the seat back.
w w
r r
