OWNER'S MANUAL
Triumph
Advance
™
Child Restraint System
Child Requirements
Weight: 5 – 50 lbs (2.3 – 22.6 kg)
Height: 19 – 50 inches (48 – 127 cm)
WARNING
To reduce the risk
of SERIOUS INJURY or
DEATH, read this owner's
manual prior to installing
and using this child
restraint.
25700172
5/07
© Evenflo Company, Inc. 2007
