- Page 1 5500 SERIES COVER CROP DEVASTATOR 5500-001B 48” 5500-002B 60” 5500-003B 90” OWNER’S MANUAL PART IDENTIFICATION 2565-976_REV_C ● 08/2024 YETTER MANUFACTURING CO. Founded 1930 Colchester, IL 62326 Toll free: (800)447-5777. Fax: (309)776-3222 Website: yetterco.com E-mail: info@yetterco.com...
-
Page 2: Warranty Policy
It is the user’s responsibility to deliver his machine to the Yetter dealer who sold him the product for service or replacement of defective parts, which are covered by the warranty policy. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS A brief description of signal words that may be used in this manual: DANGER: Indicates an imminently hazardous situation which, if not avoided “will” result in death or serious injury. This signal word is to be limited to the most extreme situations. WARNING: Indicates a potentially hazardous situation which, if not avoided, “could”... -
Page 4: Bolt Torque
TABLE OF CONTENTS FOREWARD............2 WARRANTY............2 SAFETY INFORMATION........2-3 TORQUE............4 ASSEMBLY INSTRUCTIONS......5 – 6 MAINTENANCE / LOCK UP………………………………7 PART IDENTIFICATION........9 - 13 BOLT TORQUE Important: Over-tightening hardware can cause just as much damage as under-tightening. Tightening hardware beyond the recommended range can reduce its shock load capacity. - Page 5 ASSEMBLY INSTRUCTIONS NOTE: SEE PAGE 12 & 13 FOR PLANTER/TOOLBAR MOUNT BRACKET ASSEMBLY. MODIFICATIONS TO MOUNTING BRACKETS MAY BE REQUIRED IN CERTAIN SITUATIONS! REAR VIEW FRONT VIEW SIDE VIEW Step 1: Attach the 5000-187 torsion mount bracket to the frame using 4) M16 X 110 flange head bolts & 2) 5000-420 clamp straps.
- Page 6 ASSEMBLY INSTRUCTIONS Step 3: Attach the roller mount to the pivot arms using the ½” x 2-1/2” x 3-1/2” U-bolts & lock nuts. NOTE: The bearing support tab on the roller mount tube should be on the backside of the bearing mount plate. Step 4: Install the roller, shim washer, &...
- Page 7 BEARING REPLACEMENT / MAINTENANCE Put bearing housing in a vice, use a pry bar to turn bearing in the housing parallel with the slots, remove old bearing, apply anti-seize lubricant to the interior of the bearing housing, insert the new bearing in the slots, & use a pry bar to move back to position.
- Page 8 5500-001B PARTS IDENTIFICATION 48 INCH COVER CROP ROLLER KIT ITEM PART NO. DESCRIPTION 2502-353 1/2-13 X 2 1/2HHCS GR8 ZP 2502-430 3/4-10 X 8 HHCS GR8, ZP 2502-805 M16 X 2 X 120 HEX FLANGE SCREW, THREADLOCK, ZP 2502-806 M16 X 2 X 110 HEX FLANGE SCREW, THREADLOCK, ZP 2520-357 1/2-13 LOCK HEX NUT, GR A, ZP 2520-604...
- Page 9 5500-002B PARTS IDENTIFICATION 60 INCH COVER CROP ROLLER KIT ITEM PART NO. DESCRIPTION 2502-353 1/2-13 X 2 1/2HHCS GR8 ZP 2502-430 3/4-10 X 8 HHCS GR8, ZP 2502-805 M16 X 2 X 120 HEX FLANGE SCREW, THREADLOCK, ZP 2502-806 M16 X 2 X 110 HEX FLANGE SCREW, THREADLOCK, ZP 2520-357 1/2-13 LOCK HEX NUT, GR A, ZP 2520-604...
- Page 10 5500-003B PARTS IDENTIFICATION 90 INCH COVER CROP ROLLER KIT ITEM PART NO. DESCRIPTION 2502-353 1/2-13 X 2 1/2HHCS GR8 ZP 2502-430 3/4-10 X 8 HHCS GR8, ZP 2502-805 M16 X 2 X 120 HEX FLANGE SCREW, THREADLOCK, ZP 2502-806 M16 X 2 X 110 HEX FLANGE SCREW, THREADLOCK, ZP 2520-357 1/2-13 LOCK HEX NUT, GR A, ZP 2520-604...
- Page 11 5500-031 PARTS IDENTIFICATION SHORT MOUNT KIT...
- Page 12 5500-032 PARTS IDENTIFICATION LONG MOUNT KIT...
- Page 13 5500-102 PARTS IDENTIFICATION COVER CROP ROLLER SHIELD KIT 5500-103 PARTS IDENTIFICATION ITEM PART NO. DESCRIPTION 5500-313 COVER CROP ROLLER END PLATE...
- Page 14 NOTES...
- Page 15 NOTES...
- Page 16 2565-976_REV_C – 08/2024...
