SET BACNET ACCESS:
By Pressing the "Set BACnet Access
4).
The window is divided in two parts, the
slaves; and "BACnet in Write" that contains the BACnet objects that the Converter goes to write into the slaves.
Figure 4a: "BACnet Set Access
The means of the fields in the window (Read) are the follows:
If the field "Enable" is checked, the BACnet variable is enabled;
In the field "Slave ID" insert the IP address or ID of the slave that contains the data to be read;
In the field "Object Type" select the object to be read;
In the field "Instance", define the instance number of the object;
In the field "Property" select the property to be read;
In the field "NByte", define the number of bytes reserved for saving the information on Modbus;
By checking the field "En
Address (D Adr). These informations are used for make a request to other segments of network;
In the field "D Net" define the destination network (from 1 to 65535);
ADFweb.com S.r.l.
" button from the main window of SW67712 (Fig. 2), the window "Set Communication" appears (Fig.
"BACnet in Read" that contains the BACnet objects that the Converter goes to read from the
 BACnet Read" window
Dest" is possible to enable the Destination Network (D Net), Destination Length (D Len) and Destination
