By checking the field "Change" the BACnet write request is made only if Modbus data are changed; otherwise (if is selected the field
"Timer") is sent cyclically, using the "Poll Time";
By checking the field "OnCMD" the BACnet write request is sent at the reception of a Modbus request;
In the field "Poll Time" define the frequency of the request;
In the field "Max Error" insert the number of consecutive errors that the Master waits before discard the row from the cycle of
requests;
In the field "Position" is possible to select the position where take the data to write in the request from a 1440 bytes array (writeable
by Modbus);
The field "Start Bit" is used for the "Binary Output" BACnet objects. Is possible to select the position in the byte where save the
data;
By checking the field "Swap" is possible to swap the order of data written to the BACnet slave;
By checking the field "Float To
In the field "Molt. Factor" it is possible to define a factor for the converted data;
In the field "Mnemonic" is possible to insert a description of the data inserted in the row.
ADFweb.com S.r.l.
Int" it is possible to convert the format from Int to Float;
