RL-DBS
Digital Baby Scale
Technical Manual
September 18, 2024
PN 118764 Rev I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL-DBS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rice Lake RL-DBS

Summary of Contents for Rice Lake RL-DBS

  • Page 1 RL-DBS Digital Baby Scale Technical Manual September 18, 2024 PN 118764 Rev I...
  • Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
  • Page 3 September 18, 2024 Updated troubleshooting procedures Table i. Revision Letter History Technical training seminars are available through Rice Lake Weighing Systems. Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department.

  • Page 4: Table Of Contents

    7.0 Specifications ............... . . 16 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost.

  • Page 5: Introduction

    Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals.

  • Page 6: Disposal

    RL-DBS Digital Baby Scale Disposal Product Disposal The product must be brought to appropriate separate waste collection centers at the end of its life cycle. Proper separate collection to recycle the product helps prevent possible negative effects on the environment and to health, and promotes the recycling of the materials.

  • Page 7: Setup

    Figure 2-1. AC Power Connection Site The RL-DBS can also be powered by four AA alkaline batteries if an additional power source is not available. A battery powered scale automatically turns off after two minutes of not being used to save battery life. Replace the batteries or connect to an AC power source as soon as possible if the low battery indicator (Lo) displays.

  • Page 8: Operation

    RL-DBS Digital Baby Scale Operation The RL-DBS accurately weighs babies up to 44 lb (20 kg). The weighing surface also includes a ruler for measuring the length of the baby. The built-in ruler can measure babies up to 22.5 in (57 cm).

  • Page 9: Initial Setup

    13. If the problem is not resolved, refer to a qualified service provider. Set Units The RL-DBS can be set to display weights in lb/oz only, kg only, or to toggle between lb/oz and kg units on the scale. 3.3.1 KG Units Only Lock the weight units to display in kg only.

  • Page 10: Weigh With A Tare

    RL-DBS Digital Baby Scale Weigh With A Tare The tare function removes the weight of additional items on the scale, such as a pad or blanket, at the time the baby is weighed. 1. Turn on the scale. 0:0.0 lb oz or 0.00 kg displays.

  • Page 11: Calibration

    Calibration Calibration This section contains procedures on how to calibrate the RL-DBS based on the year of the firmware version. Firmware Version 2016 and After Use the following instructions to calibrate the RL-DBS with a newer version of firmware. NOTE:Ensure the scale is installed on a level surface.

  • Page 12: Firmware Version Prior To 2016

    RL-DBS Digital Baby Scale Firmware Version Prior to 2016 Use the following instructions to calibrate the RL-DBS with an older version of firmware. 1. Ensure the scale is installed on a level surface. NOTE: The scale needs to be off at the start of the calibration procedure.

  • Page 13: Maintenance

    Maintenance Maintenance The following section provides instructions for maintaining, cleaning and troubleshooting the RL-DBS. IMPORTANT: Maintenance operations not described in this section must be performed by qualified service personnel. Basic Maintenance • Check the scale for proper operation and function before first use and after periods of non-use.

  • Page 14: Compliance

    RL-DBS Digital Baby Scale Compliance DECLARATIONOF CONFORMITY RL-DBS, RL-DBS-2 baby scale 2014/30/EU EMC EN 55022:2006+A1:2007, EN 55024:1998+A1:2001+A2:2003, EN 61000-3-2:2006, EN 61000-3-3:2008 2014/35/EU EN 60950-1:2006+A11 low voltage directive 2011/65/EU RoHS EN 50581:2012 ___________________ ______ __________________________ __________________________ April 16, 2020 __________________________ __________________________ www.RiceLake.com...

  • Page 15: Specifications

    Humidity: < 80% relative humidity Dimensions (L x W x H): 23.6" x 15.0" x 3.9'' (60.9 x 38.1 x 9.9 cm) Weight: 5.26 lb (2.5 kg) Warranty: Two-year limited warranty © Rice Lake Weighing Systems ● All Rights Reserved...
  • Page 16 RL-DBS Digital Baby Scale www.RiceLake.com Visit our website...
  • Page 18 © Rice Lake Weighing Systems Content subject to change without notice. 230 W. Coleman St. • Rice Lake, WI 54868 • USA USA: 800-472-6703 • International: +1-715-234-9171 September 18, 2024 PN 118764 Rev I www.ricelake.com...
