Page 1: Operation Instructions
RL-DBS Digital Baby Scale Operation Instructions To be the best by every measure 107801... -
Page 3: Table Of Contents
Technical training seminars are available through Rice Lake Weighing Systems. Course descriptions and dates can be viewed at www.ricelake.com or obtained by calling 715-234-9171 and asking for the training department © 2011. Rice Lake Weighing Systems. All rights reserved. Specifications subject to change without notice. April 2011... - Page 4 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars. RL-DBS Operating Instructions...
-
Page 5: Introduction
Rice Lake Weighing Systems is an ISO 9001 registered company. Figure 1-1. RL-DBS Digital Baby Scale With the RL-DBS Digital Baby Scale, there are certain precautions that should be taken to prevent injury to the baby and damage to your scale. Please follow these instructions carefully;... -
Page 6: Assembly Instructions
Assembly Instructions The RL-DBS Digital Baby Scale comes fully assembled and includes the scale and a 120V AC adaptor. To set up the scale: 1. Select a sturdy, flat surface on which to place the scale on. 2. Plug in the 120V AC adaptor. The AC power adaptor plugs into the back of the indicator as shown below in Figure 2-1. -
Page 7: Scale Setup
When the scale is on, this display indicates that the scale is weighing in pounds/ounces When the scale is on, this display indicates that the scale is weighing in kilograms Table 3-1. Front Panel, Showing Annunciators RL-DBS Operating Instructions - Scale Setup... -
Page 8: Scale Operation With Tare
Scale Operation with Tare The RL-DBS Digital Baby Scale can accurately weigh babies up to 44 Lbs (20 Kg). Use the following steps to weigh a baby. key to turn the scale on. -
Page 9: Troubleshooting & Testing
The display show Err The RECALL key was pressed with Place more than 2 lb, 30 Oz on the scale insufficient weight on the scale. Table 5-1. Troubleshooting Table RL-DBS Operating Instructions - Troubleshooting & Testing... -
Page 10: Maintenance
Maintenance The following section provides instructions for maintaining and cleaning the RL-DBS Digital Baby Scale. Maintenance operations other than those described in this section should be performed by qualified service personnel. Basic Maintenance Before the first use of the scale and after periods of non-use, check the scale for proper operation and function. If the scale does not operate correctly, contact qualified service personnel. -
Page 11: For More Information
For More Information System Manuals • RL-DBS Technical and Operating Instructions, PN 118764 Literature • Medical Scales, Digital Baby Scale, 4 Color, PN 110619 Web Site • http://www.ricelake.com/health Contact Information Hours of Operation Knowledgeable customer service representatives are available 6:30 a.m. - 6:30 p.m. Monday through Friday and 8 a.m. -
Page 12: Rl-Dbs Digital Baby Scale Limited Warranty
RL-DBS Digital Baby Scale Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years. - Page 14 PN 118764 04/11...
