Eliminator Lighting and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...
C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Battery Precautions Maintenance Guidelines Overview Installation Instructions IR Remote Functions IR Remote Range Trouble Shooting Tips | FAQs Technical Specifications Dimensional Drawings...
G E N E R A L I N F O R M A T I O N INTRODUCTION Please read and understand all instructions in this manual carefully and thoroughly before attempting to operate this product. These instructions contain important safety and use information. UNPACKING: This product has been thoroughly tested and has been shipped in perfect condition.
This warranty is the only written warranty applicable to Eliminator Lighting, an ADJ Products, LLC brand, and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. ELIMINATOR LIGHTING is not responsible for injury and/or damages resulting from the misuse of these devices due to the disregard of the information printed in this manual. Only qualified and/or certified personnel should perform installation of these devices and only the original rigging parts included with these devices should be used for installation.
B A T T E R Y P R E C A U T I O N S DO NOT EXPOSE PRODUCT TO EXTREME HOT OR COLD TEMPERATURES. DO NOT EXPOSE PRODUCT TO WATER OR WET ENVIRONMENTS. KEEP FLAMMABLE MATERIALS AND/OR FIRE AWAY FROM THE PRODUCT. DO NOT OPEN AND/OR DISASSEMBLE THE PRODUCT.
Regular inspections are recommended to ensure proper function and extended life. There are no user serviceable parts inside these devices; please refer all other service issues to Eliminator Lighting. Should you need any spare parts, please order genuine parts from Eliminator Lighting.
O V E R V I E W Included items: LED BP Tubes (x4) Carry Bag (x1) Support Feet (x12) Mounting Wireless IR Brackets (x4) Remote (x1) Mounting Clips (x8) Thumb Screws (x4) Power Cable / Charger (x4)
Page 10
O V E R V I E W Vertical Hanging Set Up Free-Standing Set Up Surface Mounted Set Up 4. Thumb Screw 1. LED BP Tube 5. Power Button 2. Support Feet 6. Mounting Clips 3. Mounting Bracket...
I N S T A L L A T I O N I N S T R U C T I O N S DO NOT INSTALL THE DEVICES IF YOU ARE NOT QUALIFIED TO DO SO! DO NOT SET UP ON UNSTABLE OR UNEVEN SURFACES! DO NOT CONNECT POWER UNTIL INSTALLATION IS COMPLETED! FLAMMABLE MATERIAL WARNING Keep devices minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics.
Page 12
I N S T A L L A T I O N I N S T R U C T I O N S VERTICAL HANGING SET UP 1. Find and remove the thumb screw located on the end of the LED BP tube. 2. Align the small hole on the mounting bracket with the thumb screw hole on the LED BP...
Page 13
I N S T A L L A T I O N I N S T R U C T I O N S 3. Use the large hole on the mounting bracket to affix the LED BP tube to your desired mounting point.
Page 14
NOTE: THE THUMB SCREW MUST BE REMOVED IN THIS SET UP. 2. AC POWER OPERATION: Connect the power supply to the cable lead on the LED BP tube. Plug the power supply into an electrical outlet and press the red button on the end of the LED BP tube to switch the device ON.
Page 15
I N S T A L L A T I O N I N S T R U C T I O N S SURFACE MOUNT SET UP Each LED BP tube requires two mounting clips. It is advisable to first install the mounting clips at the desired mounting point using appropriate hardware (not included), then attach the LED BP tube to the mounting clips.
I R R E M O T E F U N C T I O N S Remote Button Function Position LED Tube ON LED Tube OFF Color Selection A. Red G. Amber B. Green H. Cyan C. Blue I. Magenta D.
Page 17
I R R E M O T E F U N C T I O N S LED Tube On/Off: Switches the LED light tube on and off. Please note that the LED light tube must be activated using the red button on the end of the tube in order for the on and off buttons on the remote to work.
Page 18
I R R E M O T E F U N C T I O N S Flash Mode: In this mode, the unit will strobe a single solid color. The color can be changed on the fly by using the COLOR SELECTION buttons. Additionally, the strobe speed can be adjusted by using the + and –...
LED BP Tubes: • Ensure that a direct line of sight path exists from the IR Remote to the LED BP Tube, as the signal from the IR Remote cannot travel through walls, around corners, or through obstacles.
Page 20
60 feet (18 m) apart in order to minimize the risk of interference, and each LED BP Tube should be placed within range of the IR Remote being used to configure its desired display mode.
The LED BP tube does not hang vertically straight. Check that the unit is mounted to a level, stable mounting point, and that the mounting bracket is not deformed or bent. If there is an issue with the bracket, please contact Eliminator Lighting Customer Support for replacement parts.
Surface Material: Plastic Working Position: Upright (all mounting methods) or horizontal (with mounting clips only) Input Voltage: 12.6 VDC/1A Max Power Consumption: 14.0 watts (for each LED BP tube) LED BP Tube Battery Battery Rating: 12V 2500MA Battery Life: Up to 8 hours...
