Electro 64 BLED
CAUTION! Please read and understand these
instructions before installing or operating this unit.
I
ntroduction:
This unit 4 channel DMX intelligent LED par can. The Electro 64 BLED has 6 operating modes; sound active
mode, auto mode, color mode, color change mode, color fade mode, or DMX control mode. The unit can be
run as a stand alone unit or in a Master/Slave configuration. This unit has been tested and there is no assem-
bly required. The unit is ready to be plugged in to a power outlet. To enhance the beams effects you can use a
fog machine.
CAUTION! Please read and understand these instructions before installing or operating this unit.
1 Year Limited Warranty:
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: motors, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
SPECIFICATIONS:
Model:
LED:
Weight:
Size:
Beam Angle:
Fuse:
Supply Voltage:
Power Consumption:
Working Position:
Duty Cycle:
DMX Channels:
Warranty:
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Eliminator Lighting warranty is valid from the date of purchase. Our
Electro 64 BLED
36 x 1W LEDs (12 Red,
12 Green, & 12 Blue)
19lbs./ 3.6kgs.
12" (H) x 10.5" (W) x
10" (L)
30 Degrees
1 Amp
110V/230V 50/60Hz
40W
Any Safe position
None
4 DMX Channels
1 Year
DMX TRAITS: 4 CHANNELS
CHANNEL 1:
COLORS
0 - 255 =
RED 0%-100%
CHANNEL 2:
COLORS
0 - 255 =
GREEN 0%-100%
CHANNEL 3:
COLORS
0 - 255 =
BLUE 0%-100%
CHANNEL 4:
DIMMER/STROBE
0 - 189 =
DIMMER 0% - 100%
190 - 250 =
STROBE SLOW - FAST
251 - 255 =
NO FUNCTION
Fuse Replacement: Locate and remove the
unit's power cord. Using a phillips-head screw
driver unscrew and remove the . Remove the bad
fuse and replace with a new one. The fuse holder
has a built-in socket for a spare fuse be sure not
to confuse the spare fuse with active fuse.
