Datascope System 98 Service Manual page 315

2 $0108-11-0100
INDUCTOR MOLDED SURFACE
MOUNT 1812. 10UH
L3,L4
5 10136-21-0012
CONNECTOR PC HEADER RIGHT
ANGLE SINGLE ROW .100 PITCH
6 |0136-62-1020
CONNECTOR PC HEADER RIGHT
ANGLE DUAL ROW .100 PITCH
7 10151-00-0190 TRANSISTOR SMD N CHANNEL
TMOS FET 2N7002
8 [0155-00-0640-04
IC DS1231 POWER SUPPLY
BIT DE-MULTIPLEXER
MONITOR
9 İ0155-00-0711-01 IC OCTAL BUFFERILINE DRIVER U10
74HCT244
10 Î0155-00-0840-01 IC 74BCT541 OCTAL BUFFERS AND [US
LINE DRIVERS
11 f0155-90-0385 IC XC1765 SERIAL CONFIGURATION JU1
PROM |
12 10155-00-0923-01 iC DS80CR212 LVDS RECEIVER 12 us
GATE ARRAY 64 LOGIC CELL
0155-00-0939-02 IC 7C1009 CMOS STATIC RAM 128K JUS
X 8 HIGH SPEED
14 |0155-00-0940-02 IC 74ABT574 OCTAL D-TYPE FLIP- U4
FLOP WITH TRI-STATE OUTPUTS
15 [0155-00-0941-03 IC 70441 FIFO 512 X 9 14NSEC US
16 10155-00-0946-02 IC XCS202 FIELD PROGRAMMABLE [U7
17 10287-01-1104 CAPACITOR SMD 1206 CERAMIC C1-C5,C7-C11,C13,C14, C17-C22
X7R 10%, 0.1UF
1%, 4.75K
0289-00-3106 CAPACITOR SMD TANTALUM 20%, [C12
10UF
19 』0289-00-5106 CAPACITOR SMD TANTALUM 20%, 106
10UF
20 |0324-01-1002 RESISTOR SMD THICK FILM 1/4W R1
1%, 10K
21 10324-01-1100 RESISTOR SMD THICK FILM 1/4W R11-R14
1%, 110
22 §0324-01-4751 RESISTOR SMD THICK FILM 1/4W R2,R3,R5,R6
0324-01-4752 RESISTOR SMD THICK FILM 1/4W
1%, 47.5К
R4,R7-R10
24 10388-00-0641 PCB, Video Receiver
25 40012-00-1101
Cable, 20-pin ribbon, to EL panel
26 10136-78-0020 Socket, SMD,20 PLCC IC
Fernte Bead, SMD 27 40108-00-0067
28 §0326-00-0101 RESISTOR SMD THICK FILM 1/10W {R16
%, 100 Ohm
29 #0324-00-0473 RESISTOR SMD THICK FILM 1/10W. [R27
5%, 47KOhm
30 10136-00-0201 Test Point TP1-TP8
System 98 Service Manual
Chapter 6, Parts
6-37
