PARTS AND TERMINOLOGY
The following page shows every individual part of an assembled
Magnitude CPU Water Block, all of the terminology labelled is used
throughout this manual. In addition, there is a list of every physical
variation of these parts and which versions they are used in. While
some parts may be physically cross compatible between different
Magnitude CPU Water Blocks, they should be assembled as stated
for optimal performance. Material, finish and color variations are not
listed as it does not affect fitment or performance.
Magnitude CPU Water Blocks which do not feature a D-RGB LED
Strip are assembled with a fourth O-Ring between the Top and
Accent, this is not used to seal the assembly! It may be exchanged
with an LED Strip when adding the D-RGB Accent. Note that the LED
Strip connector does not fit through the hole in the Frame!
- 5 -
