Structural Concepts Reveal NE3613RSSV User Manual page 7

Installation: Case Removal From Skid
Levelers:
• There are levelers on each corner of the case.
• Raise levelers to their highest position to engage the
casters.
Carefully Remove Case From Pallet:
• Check that levelers are fully raised.
• Use handles to slide the case to rear of the pallet
carefully.
• Caution! 4 people are required for this task!
• Carefully lower to the floor (using a ramp if available).
• Slide pallet from under case as required.
• Maintain support of the case at all times, or the center of
gravity may cause the case to fall.
• See the illustration at right.
Levelers:
• After the case is at the desired position, lower the levelers
to secure the case in position. Check that the case is
level.
• Readjust height as needed.
Reveal® User Manual
Levelers
Levelers
Support
case while
moving
Ramp
7
