Shelf and Deck Load Limits

The chart below are the load limits for the shelves and decks. All weights below are for a uniformly distributed load. All
values in pounds.
MODEL
NE3613RSSV
NE3620RSSV
NE3627RSSV
NE3635RSSV
NE4813RSSV
NE4820RSSV
NE4827RSSV
NE4835RSSV
NE6020RSSV
NE6027RSSV
NE6035RSSV
NE7220RSSV
NE7227RSSV
NE7235RSSV
NR3633RSSV
NR3640RSSV
NR3647RSSV
NR3655RSSV
NR4833RSSV
NR4840RSSV
NR4847RSSV
NR4855RSSV
NR6040RSSV
NR6047RSSV
NR6055RSSV
NR7240RSSV
NR7247RSSV
NR7255RSSV
Reveal® User Manual
M A X 10 " D SH E L F MAX 1 2 "D S H E L F
LO A D L OAD
NA NA
NA 66
66 NA
66 66
NA NA
NA 92
92 NA
92 92
NA 118
118 NA
118 118
NA 145
145 NA
145 145
NA NA
NA 66
66 NA
66 66
NA NA
NA 92
92 NA
92 92
NA 118
118 NA
118 118
NA 145
145 NA
145 145
M A X 1 4 "D SH E L F M A X D E CK P A N
L OA D L OA D
NA 132
NA 132
88 132
88 132
NA 184
NA 184
123 184
123 184
NA 237
158 237
158 237
NA 277
193 277
193 277
NA 132
NA 132
88 132
88 132
NA 184
NA 184
123 184
123 184
NA 237
158 237
158 237
NA 277
193 277
193 277
