RTS TM-2000 User Manual

Trunk master, switch over panel, interconnect panel, intelligent trunking system
Hide thumbs Also See for TM-2000:

Advertisement

Quick Links

USER MANUAL
Model
TM-2000 Trunk Master
SWP-2000 Switch Over Panel
ICP-2000 Interconnect Panel
Intelligent Trunking System
9350-7715-000 Rev C, 2/2002
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM-2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for RTS TM-2000

  • Page 1 USER MANUAL Model TM-2000 Trunk Master SWP-2000 Switch Over Panel ICP-2000 Interconnect Panel Intelligent Trunking System 9350-7715-000 Rev C, 2/2002...
  • Page 2 This warranty is the sole and exclusive express warranty given with All shipments of RTS products should be made via United Parcel respect to RTS products. It is the responsibility of the user to Service or the best available shipper, prepaid. The equipment determine before purchase that this product is suitable for the should be shipped in the original packing carton;...
  • Page 3: Table Of Contents

    TM-2000 ..................................9 SWP-2000 ..................................9 ICP-2000 ..................................9 Environment ................................. 9 Approvals ..................................9 DRAWINGS ............................10 Example of Non-redundant TM-2000 System ......................10 Example of Redundant TM-2000 System ........................ 11 Cable Diagrams ..............................12-15 Recommended Cables ..............................15...
  • Page 4: Introduction

    2000 and one or more RTS Model ICP-2000 Inter-Connec- tion Panels, depending on the number of intercom systems to be trunked. A backup TM-2000 may also be added to the system to prevent downtime in the event of a failure of the main master control unit.
  • Page 5: Icp-2000 Description

    RS-485 communication card on the TM-2000 has 8 ports based PC), status monitoring of both TM-2000 units and provided on the SCSI type II connector. The ICP-2000 control of both TM-2000 units when used in a redundant breaks these 8 ports into individual 9-pin D-Sub connec- configuration.
  • Page 6: Understanding Trunking

    4. Trunk Master A TrunkSupervisor connector. Connects to If more than two intercom systems are interconnected, COM port 2 of the TM-2000 assigned to be Trunk Master additional trunk lines must be reserved and intercon- nected between the systems. However, it is not always 5.
  • Page 7: Rack Mounting

    Figure 7 - Serial (COM) port labels on TM-2000. TrunkSupervisor works with a PC attached to COM port 2 of the TM-2000 or via the TRK SPVR port of the SWP- 2000. See Figure 7 for an example of how COM port 1 and 2 are labeled on the TM-2000.
  • Page 8 Select the RS-485 COM port to be used from the "Alpha" box. When the keypanel setup screen for that TM-2000 to each intercom system. The COM port can be intercom port appears, uncheck all of the Scroll Enable changed by right clicking anywhere along an intercom check boxes.
  • Page 9: Specifications

    SPECIFICATIONS assignment that will communicate with a remote intercom system. If you use the Key Assignment Select screen to TM-2000 assign keys, proceed as for normal key assignment, Height: 7.0” (177mm) except that you should select an intercom system before Width: 19.0”...
  • Page 12: Cable Diagrams

    Figure 16 - RJ-45 connector pinout. Figure 12 - 9-pin D-sub connector pinouts. Figure 17 - DE9S to DE9S audio cable. Figure 13 - 25 pin D-sub connector pinouts. Figure 18 - DE-9S to unspecified device audio cable. Figure 14- 50 pin SCSI type II connector pinout. Figure 15- RJ-11 connector pinout.
  • Page 13 Figure 22 - ICP-2000 to ADAM RS-485 data cable. Figure 26 - ADAM CS to unspecified device RS-485 data cable. Figure 23 - ICP-2000 to ADAM CS RS-485 data cable. Figure 27 - TM-2000 to TM-2000 network linking (standard networking crossover) cable.
  • Page 14 Figure 28 - TM-2000 to ICP-2000 RS-485 COM ports cable. Figure 29 - TM-2000 to SWP-2000 parallel port status and control cable.
  • Page 15: Recommended Cables

    RS-232 wired “Straight Through” for SWP-2000 to TM- 2000 connections. Us an RS-232 wired “Null Modem” for PC to TM-2000/SWP-2000 connections. 5. For TM-2000 to ICP-2000 RS-485 cables use the supplied cables. 6. For TM-2000 to SWP-2000 status/control cables use 25 conductor shielded cable.
