Summary of Contents for RTS DSI 2008
- Page 1 User Instructions DSI 2008 Digital System Interface ADAM, ADAM-M, ADAM CS, Zeus, and Zeus III Intercoms Rev. 05 SEPTEMBER/2012 F.01U.193.295...
- Page 2 For warranty and service information, refer to the appropriate web site below: WARNING: APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, RTS Intercoms ........www.rtsintercoms.com/warranty SHALL BE PLACED ON THE APPARATUS. RTS Digital RTSTW WARNING: THE MAIN POWER PLUG MUST REMAIN READILY OPERABLE.
- Page 3 DSI-2008 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
- Page 4 DSI-2008 Bosch Security Systems, Inc. Rev. 05 F.01U.193.295 User Manual...
-
Page 5: Table Of Contents
4-wire Call Send and Call Enable/Inhibit ........................15 4-wire Call Receive ................................. 16 2-Wire Call Signal ..........................17 Call Signal Connections for Audiocom and RTS TW ..................17 Call Signal Connections for Other 2-Wire Communication Systems ............... 17 OPERATION ..........................19 Setup Instructions ...........................19... - Page 6 DSI-2008 User Manual F.01U.193.295 Bosch Security Systems, Inc. Rev. 05...
-
Page 7: Description And Specifications
The result is easy and accurate setup. With the DSI 2008, all need for test tones, nulling adjustments and ducking adjustments have been eliminated. -
Page 8: Front And Back Panel Descriptions
Front Panel There is a power on/off and call indicator at the left of the front panel. This indicator lights continuously when the DSI 2008 is turned on and flashes when an incoming call signal is detected, if the call signal option board is installed. The remainder of the front panel is divided into controls and indicators for the two separate hybrids, labeled SYSTEM A and SYSTEM B. -
Page 9: Specifications
DSI-2008 Description and Specifications 5 Specifications 2-Wire Ports Input / Output Impedance 5,000, nominal Operating Level Audiocom: 1 V , nominal RTSTW: 775 mV , nominal 4-Wire Ports Input Impedance 10k , nominal Output Impedance 200 Operating Levels -10dBu, 0dBu, +4dBu, +8dBu, +12dBu System to System Frequency Response 200Hz to 3.5kHz, ±4dB... - Page 10 6 Description and Specifications DSI-2008 User Manual Bosch Security Systems, Inc. F.01U.193.295 Rev. 05...
-
Page 11: Installation
Mounting Place the DSI 2008 on a desktop, or install it in an equipment rack using an RTS MCP Rack Mount Kit. Several rack mount options are available. There are no special ventilation requirements for the DSI 2008, but allow for ventilation around the power pack. -
Page 12: Audio Connections For The Other 4-Wire Communications Systems
Pin 6 No Connection On the DSI 2008 front panel, set the 4W LEVEL REF SEL switches to the position which most closely matches the audio input and output levels of your 4-wire system. NOTE: If you don’t know the levels, select the +8dB position for now. - Page 13 DSI-2008 Installation 9 Rack Mount Configurations FIGURE 2. Bosch Security Systems, Inc. User Manual F.01U.193.295 Rev. 05...
-
Page 14: 2-Wire Audio Connections
Use standard TW intercom cables. Standard TW system cables can carry either one (1) or two (2) channels. Each hybrid in the DSI 2008 can only interface one (1) TW channel to one (1) 4-wire channel, the channel is determined by the front panel 2W CHAN SEL switch. -
Page 15: Other 2-Wire Audio Connection
Other 2-wire Audio Connection Use the J1A connector on the back of the DSI 2008 to connect one 2-wire line to the System A hybrid. Use the J1B connector to connect a second 2-wire line to the System B hybrid. The pin configuration for the J1A and J1B connec- tors depend on whether you are connecting a balanced or unbalanced 2-wire line, as follows: NOTE: TW systems must provide termination on the audio channel. -
Page 16: 4-Wire Call Signal Connections
By default, these output are set to duplicate the action of the RTS FR9528 Relay Frame accessory. This is the correct setting for use with the DSI 2008. To check the AZedit setting, select Intercom Configuration in the Options menu. Click on the Options tab, then verify that Configure onboard GPI outputs in FR9528 mode is selected. - Page 17 DSI-2008 Installation 13 This example uses GPI outputs #1 and #2 and GPI Input #1; however, you may use any other available GPI inputs and outputs. The Call Enable/Inhibit connection is optional. It gives you the ability to disable call signalling using a GPI output.
- Page 18 14 Installation DSI-2008 UIO-256 GPI Input Connector (J7) TABLE 2. GPI INPUT PIN NUMBERS GPI INPUT NUMBERS UIO-256 Frame UIO-256 Frame UIO-256 Frame UIO-256 Frame Input Height Common (5-18 VDC) a. Dependent on UIO-256 DIP Switch SW1 Settings for Input/Output Range as summarized in the UIO-256 Manual. User Manual Bosch Security Systems, Inc.
-
Page 19: Call Signal Connections For Other 4-Wire Communications Systems
4-Wire Call Send and Call Enable/Inhibit The DSI 2008 accepts a switch-contact input from the 4-wire system and then generates a call signal output to the 2-wire system. The DSI 2008 also accepts an optional switch contact input to enable or inhibit call signaling between the 4-wire and 2-wire systems. -
Page 20: 4-Wire Call Receive
4-Wire Call Receive The DSI 2008 receives call signals from the 2-wire system, then converts this to relay contact closure for use as a 4-wire call receive indication. The DSI 2008 also provides +5 VDC which can be connected to the relay contacts to generate a DC output signal instead of a contact closure. -
Page 21: 2-Wire Call Signal
DSI-2008 Installation 17 2-Wire Call Signal Call Signal Connections for Audiocom and RTS TW The call signals are superimposed on the audio signal, so no separate call signal connections are required. Call Signal Connections for Other 2-Wire Communication Systems Any other 2-wire device must be able to generate and receive a 20kHz signal superimposed on the audio as follows:... - Page 22 18 Installation DSI-2008 User Manual Bosch Security Systems, Inc. F.01U.193.295 Rev. 05...
-
Page 23: Operation
NOTE: The power indicator flashes when a call signal is received from a 2-wire line, if the call signal option board is attached. The DSI 2008 level displays should help to confirm which line is calling. Use the level adjust trimmers to fine tune the listen levels. -
Page 24: Operating Notes For Adam, Adam-M Adam Cs Zeus And Zeus Iii Intercom Systems
Another way to generate a call signal is by assigning the GPI output as a level 2 talk key assignment for any key that is assigned to talk to the DSI 2008. However, this will cause the call lights to flash on the 2-wire line during the entire conversation. -
Page 25: Access And Configuration
APPENDIX A Access and Configuration Internal Access Remove six screws from the back cover. Remove the top cover. This provides access to all internal adjustments. For option card installation, slide the circuit board out toward the back to remove it from the bottom cover. Telex Communications, Inc., Made in U.S.A. -
Page 26: Mode Dip Switch Settings
Assemble the standoffs to the circuit board using the supplied screws and lock-washers. Connect the supplied power cable from J8 on the option card to J303 on the main board of the DSI 2008. Insert the connectors on the option card into the connectors on the main board. -
Page 27: Notes
DSI-2008 Notes Bosch Security Systems, Inc. User Manual F.01U.193.295 Rev. 05... - Page 28 Bosch Security Systems, Inc. 12000 Portland Avenue South Burnsville, MN 55337 U.S.A. www.boschcommunications.com...
