Hytronik HIR32 Installation And Instruction Manual

Installation and Instruction Manual
FLUSH MOUNT PIR MOTION SENSOR
Two DALI Channels Output
1. Technical Specifications
Mains voltage 220~240VAC 50/60Hz
<0.5W
Stand-by power
DALI Channel 1 Max. 25pcs devices, 50mA
DALI Channel 2 Max. 15pcs devices, 30mA
Warming-up Appr. 20s
Sensor principle PIR detection
Detection range (Max.)* Installation Height : 6m
Detection Range (Ø) :9m
Detection angle 360°
Operation temperature
Ta: -20°C ~ +50°C
IP rating
IP20
EMC standard (EMC) EN55015, EN61000
Safety standard (LVD)
EN60669, AS/NES60669
Certification
CB, CE , EMC, RCM
2. Installation
Ø 66~68mm
1
2
3
4
5
A B
* Install blind as required
* Install lens as required
1. Ceiling (drill hole φ66~68mm)
2. Carefully prise off the cable clamps.
3. Make connections to the pluggable
terminal blocks.
6
4. Insert plug connectors and secure using
the provided cable clamps, then clip
terminal covers to the base.
5. Fit detection blind (if required) and
desired lens.
7 6. Clip fascia to body.
7. Bend back springs and insert into ceiling.
HIR32
3. Functions
3.1 Daylight Harvest (Daylight Regulating)
Daylight sensor measures the available surrounding natural light, calculates how much electrical light is
needed to reach the total lux expected. The demand is given to the LED driver by DALI signal, so as to
deliver the needed amount of electric light.
Light level
Hold time
Normal Electric Light
Energy Saving Zone Daylight controlled light
Stand-by time
Natural light
0 24
3.2 Lux Off Function
The built-in daylight sensor can measure ambient natural light and switch off the fixture
automatically whenever artificial light is not required (natural light lux level exceeds daylight
threshold).
3.3 Dual DALI Output Control
Two channels of self-powered DALI output are available on HIR32 for connection of two groups of
LED drivers. Please note that both channels share the same control settings sent from the occupancy
sensor and photocell.
System Capacity DALI channel DALI Driver < 2mA
DALI PSU Channel 1 (max 50mA) 25 pcs
HIR32 includes 2 channels
total 80mA max. DALI PSU
DALI PSU Channel 2 (max 30mA) 15 pcs
3.4 Manual Override (Push Function)
Three push terminals (P1, P2, P3) are available on the HIR32 for end-users to switch on/off, change the
light brightness, colour temperature of the two DALI channels temporarily. The settings will revert to
daylight harvest mode after sensor time-out.
* Long push on P1: adjust the hold-time light brightness of DALI channel 1;
Short push (<1s) on P1: on/off function
* Long push on P2: adjust the hold-time light brightness of DALI channel 2;
Short push (<1s) on P2: on/off function
* Long push on P3: cycles through colour tuning on both channels. (work with DT8 LED driver only)
Short push (<1s) on P3: resume automatic daylight harvest mode .
Wire Preparation
0.75 - 2.5mm
8mm
(min 6mm, max 11mm)
Pluggable screw terminal. It is recommended to make
connections to the terminal before fitting to the sensor.
1. 200 metres (total) max. for 1mm² CSA (Ta = 50℃)
2. 300 metres (total) max. for 1.5mm² CSA (Ta = 50℃)
HIR32-20230509-A0
4. Wiring Diagram
L
N
P3 P2 P1N L
DA1
Time (hrs)
5. Description of the Button Functions (remote control HRC-11)
4
1
2
5
3
6
7
8
10
9
15 11
12
& A
4 h h 4 h
13
14
HRC-11
- + L N
LED
LED Driver
DA DA
Max.15pcs
- + L N
LED
LED Driver
HIR32
DA DA
Max.25pcs
DA2
4. Press button
Permanent ON/OFF [ button 1 ]
Press button 1 , to select permanent ON or permanent OFF mode.
* Press button / to to quit this mode.
2 4
RESET[ button 2 ]
Press button , all settings go back to default values as below:
2
Hold-time 5min, Daylight sensor 100Lux, Stand-by time: 10min, Stand-by
dimming level: 20% Detection range [ zone
These two buttons are disabled.
Test Mode[ button ]
15
This button is for testing purpose only. The sensor goes to test mode
Daylight threshold [ zone
(hold-time is 2s) after commissoning, meanwhile the stand-by period and
Press buttons in zone
daylight sensor are disabled.
50Lux / 100Lux / 300Lux / 500Lux / Disable.
* This mode can be ended by pressing "reset", or any button of
Note: To set daylight sensor at 100Lux / 300Lux / 500Lux, press
"scene mode" and "hold-time". The sensor settings are changed
3
accordingly.
Ambient daylight threshold [ button
Shift [ button 3 ]
1. Press button
Press button 3 , the LED on the top left corner is on to indicate mode
2. Press button
selection. All values / settings in RED are in valid for 20 seconds.
Auto Mode [ button 4 ]
Press button 4 to initiate automatic mode. The sensor starts working Hold time [ zone
and all settings remain as before the light is switched ON/OFF.
Press buttons in zone
5min / 10min / 15min / 20min / 30min.
Note: 1.To set hold-time at 30s / 5min / 15min / 30min, press button
Semi-auto Mode [ button 3 & 4 ]
1. Press button Shift (the red LED is on for indication).
3
2. Press button to initiate semi-auto mode. The fixture is manually
4
on by push-switch and automatically off in semi-auto mode.
*To exit from Test mode, press button
Power output [ button ]
5
Stand-by time [ zone
Press button 5 , the light output shifts between 80% and 100%.
Press buttons in zone
Note: the function of "Sensor off" and "Twilight" are disabled.
1min / 5min / 10min / 30min / 1h / +∞.
Note: "0s" means on/off control; "+∞" means bi-level control, 100%
Brightness +/- [ button ]
6
on when motion detected, and remains at the stand-by dimming
Press button 6 to adjust the light brightness and color temperature
level when no presence after hold-time.
between 10%~100%.
Stand-by dimming level [ zone
Scene prog. [ zone 7 ] (One-key-commissioning)
Press buttons in zone
1. Press button "Start" to program.
20% / 30% / 50%.
2. Select the buttons in 8 "Detection range", / "Daylight threshold",
9 10
Note: the function of 24h/12h/4h/30s are disabled.
"Hold time", "Stand-by time", "Stand-by dimming level" to
11 12 13
set all parameters.
Dual tech & RF mode [ zone
3. Press button 7 "Memory" to save all the settings programmed in the
All buttons in zone
remote control.
- + L N
LED
LED Driver
DA DA
- + L N
LED
LED Driver
DA DA
"Apply" to set the settings to each sensor unit(s).
7
For example, to set detection range 100%, daylight threshold
Disable, hold time 5min, stand-by time +∞, stand-by dimming level
30%, steps should be:
Press button Start, button 100%, Disable, Shift, 5min,
7 8 10 3 11
Shift, +∞ , 30%, Memory. By pointing to the sensor unit(s)
3 12 13 7
and pressing Apply, all settings are passed on the sensor(s).
7
8 ]
9 ]
to set daylight sensor at 2Lux/ 10Lux /
9
Shift button first.
10 ]
3 Shift, the red LED starts to flash.
, the ambient lux level is sampled and set as
10
the new daylight threshold / target Lux level.
]
11
to set the hold time at 2s / 30s / 1min /
11
Shift at first.
3
2. 2s is for test purpose only, stand-by period and daylight
sensor settings are disabled in this mode.
2 or any button in zone 11 .
12 ]
to set the stand-by period at 0s / 10s /
12
13 ]
to set the stand-by dimming level at 10% /
13
14 ]
are disabled.
14
