HEDS-9930PRGEVB User Guide
1 HEDS-9930EVB Evaluation Board
1.1 Top and Bottom Views
Figure 1: Bottom Side of the PCB HEDS-9930EVB
Mounting slot
Mounting hole
Figure 2: Top Side of the PCB 397 LPI
Code wheel OD
alignment guide
lines
Remove the protective kapton tape covering the encoder ASIC before use.
NOTE:
Broadcom
Evaluation Board and Programming Kit
HEDS-9930PRGEVB-UG100
4
