Before Use - Briteq BT-MAGICFLASH Operation Manual

ENGLISH
OPERATION MANUAL
Thank you for buying this Briteq
please read these operating instructions very carefully before you start using this unit.
FEATURES
• Powerful LED strobe with 9 separately controllable segments!
• 324 strobe LEDs for an exceptional light output of +/-35.000 lm
• Long time blinder function with auto fade down function
• Stunning built-in random pixel strobe effects, no extra programming needed.
• Full DMX-control with:
• 7 different channel modes for strobe effects (1ch to 13ch)
• 3 different pixel control modes (1ch to 9ch)
• LCD-display for easy setup menu navigation
• Can be used as wash projector at reduced output (ex. light up the stage during technical buildup of a gig)
• TV-Studio ready:
• Natural white: 4500K with CRI > 90
• Flicker free 2000Hz LED refresh rate
• Low noise cooling system
• Compact and sturdy ALU-housing with tempered glass in front of the leds, perfect for rental companies!
• Strong hanging bracket, prepared for use with omega clamps for fast installation.
• In case of DMX failure you can choose between blackout and freeze mode.
• Lock function to avoid unwanted altering of the settings.
• Default factory settings can be loaded.
• 3pin XLR & power in/outputs for easy daisy chaining of several units up to 16A.
• Power supply with active PFC.

BEFORE USE

• Before you start using this unit, please check if there's no transportation damage. Should there be any, do
not use the device and consult your dealer first.
• Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
• Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check that the carton contains the following items:
• English operating instructions, other languages can be downloaded from our website.
• BT-MAGICFLASH
• Mains powercable
BRITEQ
®
®
product. To take full advantage of all possibilities and for your own safety,
1/11
OPERATION MANUAL
BT-MAGICFLASH
