• Pin layout XLR-3pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+)
• Pin layout XLR-5pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) ~ Pins4+5
not used.
• To prevent strange behavior of the light effects, due to interferences, you must use a 90Ω to 120Ω
terminator at the end of the chain. Never use Y-splitter cables, this simply won't work!
• Make sure that all units are connected to the mains.
• Each light effect in the chain needs to have its proper starting address so it knows which commands
from the controller it has to decode.
DMX CHARTS
Different DMX channels modes are available:
1CH MODE
Ch.
Value
248-255
1
006-247
000-005
3CH MODE
Ch.
Value
006-255
1
000-005
2
000-255
006-255
3
000-005
4CH MODE
Ch.
Value
006-255
1
000-005
2
000-255
006-255
3
000-005
000-005
006-042
043-085
4
086-128
129-171
172-214
215-255
4CH+ MODE
Ch.
Value
006-255
1
000-005
2
000-255
006-255
3
000-005
000-005
006-041
042-083
084-125
4
126-167
168-209
210-255
BRITEQ
®
What It Does
BLINDER effect
Strobe rate (0-30Hz)
Blackout (no output)
What It Does
Dimmer (0% - 100%)
Blackout (no output)
Flash Duration (0% - 100%)
Strobe Rate (0-30Hz)
No flash
What It Does
Dimmer (0% - 100%)
Blackout (no output)
Flash Duration (0% - 100%)
Strobe Rate (0-30Hz)
No flash
Built-In Programs
Ramp up effect (slow ↔ fast)
Ramp down effect (slow ↔ fast)
Ramp up-down effect (slow ↔ fast)
Random effect (slow ↔ fast)
Lightning effect (slow ↔ fast)
Spike effect
What It Does
Dimmer (0% - 100%)
Blackout (no output)
Flash Duration (0% - 100%)
Strobe Rate (0-30Hz)
No flash (1 single flash can be triggered with CH1)
No Pixel effects: CH1 to 3 are active
PIXEL EFFECT 1 (slow ↔ fast)
PIXEL EFFECT 2 (slow ↔ fast)
PIXEL EFFECT 3 (slow ↔ fast)
PIXEL EFFECT 4 (slow ↔ fast)
PIXEL EFFECT 5 (slow ↔ fast)
PIXEL EFFECT 6 (slow ↔ fast)
8/11
OPERATION MANUAL
BT-MAGICFLASH
