Summary of Contents for Briteq BTX-700BEAM
-
Page 3: Safety Instruction
In the event of serious operating problem, stop using the unit immediately. Never turn on and off the unit time after time. The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged. BRITEQ® BTX-700BEAM... -
Page 4: Installation
(6) through the bottom of the base and over the support. Fig.1 Fig.2 Attention: Always ensure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. BRITEQ® BTX-700BEAM... -
Page 5: Technical Specification
- Optional multiple preset colors and macros available. Gobo wheel - Gobo size: Ø26.8mm (Ø24mm for image) - Gobo Wheel: 7 rotating, index able, easily replaceable gobos + open. - Easy calibration and maintenance by magnetic home positioning. BRITEQ® BTX-700BEAM... - Page 6 Prism - 3 facets prism with rotating effect. Frost - Variable, separate effect. Cool - Fan cooled Protocols - DMX 512 - Date input/output: 3/5 Pin XLR socket Weight - 21.5kgs Dimension - 447× 369×604 mm Photometric diagram BRITEQ® BTX-700BEAM...
- Page 7 Yellow Gobo Pan Fine CMY Speed R-Gobo Tilt Gobo Prism Tilt Fine R-Gobo R-Prism Pan /Tilt Speed R-Gobo Fine Frost Frost Prism Function Function R-Prism R-Prism Fine Frost P/T Macro P/T Macro Speed Preset Color Color Macro Function BRITEQ® BTX-700BEAM...
-
Page 8: Front View
To enter into move backward or leave the menu To go backward to move up in the menu DOWN To move down in the menu ENTER To perform the desired functions ○ ,4 Antenna (optional) Receive wireless signal from a wide range BRITEQ® BTX-700BEAM... -
Page 9: Gobo And Lamp
4. Remove the original gobo and inset a new one (glazy side towards the lamp). Insert the ring to secure it in the gobo holder. 5. Install the gobo plate back into the gobo wheel. Make sure the gobo plate is installed under the pressure plate. BRITEQ® BTX-700BEAM... - Page 10 4. Inset a new lamp follow the groove, turn it clockwise to fix the lamp. 5. Tighten the screws (A) to fix the lamp cover. 6. Turn the screws (B) to adjust the lamp position be sure it is located in the center of the reflector for the best projection. BRITEQ® BTX-700BEAM...
-
Page 11: How To Set The Unit
In the event of disconnecting with mains power, press UP button for one minute to enter into menu mode. Press MENU button or let the unit idle one minute to exit. The main functions are shown below（the grayed boxes are preset settings）: BRITEQ® BTX-700BEAM... - Page 12 BRITEQ® BTX-700BEAM...
-
Page 13: Dmx Functions
Select View DMX Value, press ENTER button to confirm. Channel function and its value will show on the display, use UP and DOWN button to view other DMX value. Press MENU button back to the last menu or let the unit idle one minute to exit menu mode. BRITEQ® BTX-700BEAM... -
Page 14: Fixture Setting
UP and DOWN button to select No (normal while pan/tilt moving) or Yes (blackout while pan/tilt moving), press ENTER button to store. Press MENU button back to the last menu or let the unit idle one minute to exit menu mode. BRITEQ® BTX-700BEAM... -
Page 15: Lamp Setting
No (keep the present state), press ENTER button to store. Press MENU button back to the last menu or let the unit idle one minute to exit menu mode.(If the lamp is off via DMX signal, you can reconnect the DMX controller to make the lamp on). BRITEQ® BTX-700BEAM... -
Page 16: Display Setting
UP and DOWN button to adjust backlight intensity from 1 (dark) to 10 (bright), press ENTER button to store. Press MENU button back to the last menu or let the unit idle one minute to exit menu mode. BRITEQ® BTX-700BEAM... -
Page 17: Fixture Test
MENU button back to exit. Reset Functions Enter menu mode, select Reset Function, press ENTER button to confirm, use UP and DOWN button to select Pan/Tilt, Color/CMY, Gobo, Shutter/Dimmer, Focus/Zoom/Prism/Frost , Iris/Flatb or All. BRITEQ® BTX-700BEAM... -
Page 18: Special Functions
Remain Time Select Remain Time, press ENTER button to confirm, the remaining time will show on the display, press ENTER button to confirm, use UP and DOWN button to select Exit or Reset time, press MENU button to exit. BRITEQ® BTX-700BEAM... - Page 19 Enter offset mode, Select Dimmer, press ENTER button to confirm, the present position will blink on the display, use UP and DOWN button to offset the value from 0 to 255, press ENTER button to store. Press MENU button to exit. BRITEQ® BTX-700BEAM...
- Page 20 ENTER button to store. Press MENU button to exit. 6.4. Error Information Lamp Startup Fail It appears when there is no lamp or some wires are damaged. Temperature Sense Error It appears when temperature check board is damaged. BRITEQ® BTX-700BEAM...
-
Page 21: Control By Universal Dmx Controller
Reset Fail, Gobo Reset Fail, R-Gobo Reset Fail, Effect Reset Fail, R-Effect Reset Fail, and Frost Reset Fail They may appear when turn on or reset the unit, for some parts such as board P.C are damaged. Please contact the qualified maintenance. 7. Control By Universal DMX Controller 7.1 Connection BRITEQ® BTX-700BEAM... - Page 22 Please refer to the following diagram to address your DMX512 channel for the first 4 units. Unit 1 Unit 2 Unit 3 Unit 4 Channel mode Address Address Address Address 18 channels 25 channels BRITEQ® BTX-700BEAM...
- Page 23 1. The unit will maintain the last condition until reset if you cut-off the DMX signal) 2. For the channel Function, keep the value for about 5 seconds, then the corresponding function will take into effect. 18 Channels mode 1: BRITEQ® BTX-700BEAM...
- Page 24 18 Channels mode 2: BRITEQ® BTX-700BEAM...
- Page 25 BRITEQ® BTX-700BEAM...
- Page 26 25 Channels mode: BRITEQ® BTX-700BEAM...
- Page 27 BRITEQ® BTX-700BEAM...
-
Page 28: Update Software
8. Update Software Download update file (if available) from www.briteq-lighting.com , follow the user manual of our firmware updater (not included, order code: 4319) to update the fixture. 9. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. -
Page 29: Maintenance And Cleaning
8 hours per day, which can reduce the output in some degree. The lens is consumable with a warranty of three months only. Please change with genuinely new lens when necessary. BRITEQ® BTX-700BEAM... - Page 32 WWW.BRITEQ-LIGHTING.COM Copyright © 2012 by BEGLEC NV ‘t Hofveld 2C ~ B1702 Groot-Bijgaarden ~ Belgium Reproduction or publication of the content in any manner, without express permission of the publisher, is prohibited.
