ENGLISH
3CH PIXEL MODE
Ch. Value
000-005
1
006-255
000-005
2
006-255
000-005
3
006-255
9CH PIXEL MODE
Ch. Value
000-005
1
006-255
000-005
2
006-255
000-005
3
006-255
000-005
4
006-255
000-005
5
006-255
000-005
6
006-255
000-005
7
006-255
000-005
8
006-255
000-005
9
006-255

MAINTENANCE

• Make sure the area below the installation place is free from unwanted persons during servicing.
• Switch off the unit, unplug the mains cable and wait until the unit has been cooled down.
During inspection the following points should be checked:
• All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded.
• Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation.
• When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced.
• The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
• In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly.
• The interior of the device should be cleaned annually using a vacuum cleaner or air-jet.
• The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit's optics.
• Clean with a soft cloth using normal glass cleaning products.
• Always dry the parts carefully.
Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!
BRITEQ
®
What It Does
No Function
Segment 1-3 Intensity (0-100%)
No Function
Segment 4-6 Intensity (0-100%)
No Function
Segment 7-9 Intensity (0-100%)
Function
No Function
Segment 1 Intensity (0-100%)
No Function
Segment 2 Intensity (0-100%)
No Function
Segment 3 Intensity (0-100%)
No Function
Segment 4 Intensity (0-100%)
No Function
Segment 5 Intensity (0-100%)
No Function
Segment 6 Intensity (0-100%)
No Function
Segment 7 Intensity (0-100%)
No Function
Segment 8 Intensity (0-100%)
No Function
Segment 9 Intensity (0-100%)
10/11
