XR 250（BEAM）
PR-2206
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-light ing.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR250

Summary of Contents for PR Lighting XR250

  • Page 1 XR 250（BEAM） PR-2206 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-light ing.com...
  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU DMX PROTOCOL MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check if there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.

  • Page 4: Fitting The Lamp

    INSTALL THE PROJECTOR SAFETY CORD WARNING CLAMP To pass 1 SAFETY CORD through 2 holes for safety CONTROL PANEL HANDLE Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp.

  • Page 5: Power Supply-Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector.

  • Page 6: Dmx Terminator

    DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.

  • Page 7: Standalone Mode

    STAND-ALONE MODE Operate the projector without connecting a controller, enable the master mode in the operation panel, the projector will run in Stand-Alone mode automatically. MASTER/SLAVE MODE Without using a controller, many projectors can run synchronously in the Master/Slave mode by linking them with each other.

  • Page 8: Operation Menu

    OPERATION MENU LEVEL LEVEL LEVEL LEVEL DMX Address Set 0 1-512 Universe Set 1 0-5120 382 0-255 IP2 384 0-255 IP Address Set 2 IP3 385 0-255 IP4 386 0-255 SubnetMask1 387 0-255 PortSet SubnetMask 2 388 0-255 Subnet Mask Set 3 SubnetMask 3 389 0-255 SubnetMask 4 390...
  • Page 9 0-127 XXX 43 Tilt amend 22 0-127 Unlink Wireless 23 YES 51 ResetLampHours 24 YES 52 ResetUserData 25 YES 53 ResetOptionSet 26 YES 54 YES 55 FactorySettings 27 ParameterTransm 28 YES 56 Step 61 Color Positions31 Linear 62 （Default：Step） F- Gobo Positions32 Step 63 （Default：Step）...
  • Page 10 X Hall Ok/Er Y Hall Ok/Er Prism Hall Ok/Er Effect Roat Hall Ok/Er 136 Effect Hall Ok/Er Focus Hall Ok/Er R- gobo Hall Ok/Er 139 Gobo- R Hall Ok/Er 140 F- gobo Hall Ok/Er Color Hall Ok/Er 142 Self Test61 Open Strobe1 Strobe62...
  • Page 11 Revers Rotating Diming 75 0-255 Focus 80 0-255 Pan Location 82 0-255 Tilt Location 83 0-255 Pan & Tilt Speed 84 0-255 DMX Operation 91 Preset Memory 92 User Memory 93 Strobe/ 0-255 Diming 0-255 Colour Wheel 0-255 Fixed gobo 0-255 Rotating gobo 0-255...

  • Page 12: Dmx Protocol

    display setting, operation mode(user memory); 2. all projectors Accepting parameters will automatically be set to slave mode. Specifications for the SIGN on the top right: S: Slave M:Master D:DMX512 I: Preset Memory U:User Memory T: Test Mode The sign of LOCK:: All keys are locked, Press Enter key for more than 3s to unlock the keys with the sign of LOCK disappearing.
  • Page 13 065-069 Color7 070-073 Color 7/ Color 8 074-078 Color 8 Color 8/ Color 9 079-082 083-087 Color 9 088-091 Color 9/ Color 10 Color 10 092-096 Color 10/ Color 11 097-100 101-105 Color 11 Color 11/ Color 12 106-109 Color 12 110-114 115-118 Color 12/ Color 13...
  • Page 14 228-231 Shake 10（From Fast to slow） 232-235 Shake 11（From Fast to slow） 236-239 Shake 12（From Fast to slow） 240-243 Shake 13（From Fast to slow） 244-255 Shake 14（From Fast to slow） 000-007 White 008-017 Gobo 1 018-027 Gobo 2 028-037 Gobo 3 038-047 Gobo 4 048-057...

  • Page 15: Maintenance

    Stop 000-063 Clockwise rotation from slow to fast 064-127 Effect Wheel Stop 128-191 Rotation Anti-Clockwise rotation from slow to fast 192-255 White 000-016 Prism Prism 017-255 Stop 000-063 Clockwise Rotation （From slow to 064-127 Fast） Stop 128-191 Prism Rotation Anti-clockwise Rotation （From slow 192-255 to Fast）...

  • Page 16: Keeping The Projector Clean

    LUBRICATION To ensure the continuous rotation of the rotating gobos and linear motion of the lens for focusing, it is recommended that the bearings for the rotating gobos and the 2 shafts for the focusing lens holder be lubricated periodically, preferably every two months. Use only high quality, high-temperature resistant grease instead of any type of oil.

  • Page 17: Technical Data

    TECHNICAL DATA VOLTAGES: 100V/200V/220V/230V/240V AC，50/60Hz POWER CONSUMPTION: 330W@220V LAMP: PHILIPS MSD Platinum 11 R 7800K Colour Temperature Manufacturers Rated Lamp Life 2000 hrs COLORS: 1 Color Wheel 13dichroic colour filters plus white Variable speed and bi-directional rainbow effect Linear colour changing is available GOBOS: 1 Fixed gobo wheel : 14 interchangeable gobos+ white...

  • Page 18: Other Functions

    CONTROL: DMX512, 3 pins and 5 pins interfaces 15channels in short mode, 19channels in standard mode Adjustable mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed Fixture and lamp usage time display Modular construction for easy maintenance DMX512 wireless receiver (optional) DMX512 wireless transmitter (optional) HOUSING: Composite plastic, IP20...

  • Page 19: Light Output

    LIGHT OUTPUT: 1260433 315108 140048 78777 50417 35102 射距（m） 0.31 0.62 0.93 1.24 1.55 1.86 19/22...
  • Page 20 Electrical Circuit Diagram 20/22...

  • Page 21: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 11R BALLAST 040070 11R LAMP 100070 200W POWER SWITCH 190010133 190010116 400W POWER SWITCH FUSE 270041065 T20A250V 6.3*32mm PAN DRIVER BELT 290151322 HTD-531-3M 290151331 HTD-399-3M TILT DRIVER BELT 290151255 HTD-270-3M PRISM WHEEL BELT FOCUSING BELT 290151310 72MXL...
  • Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: Version: (Preliminary） 22/22...
