SEWOO TECH CO.,LTD.
Doosung BD, 689-20, Geumjung-dong, Gunpo-si, Gyeonggi-do, 435-862 South Korea
TEL : +82-31-459-8200 FAX : +82-31-459-8880
www.miniprinter.com
MODEL : LK-P31
MOBILE PRINTER
All specifications are subject to change without notice
Rev. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-P31 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEWOO LK-P31

Summary of Contents for SEWOO LK-P31

  • Page 1 SEWOO TECH CO.,LTD. Doosung BD, 689-20, Geumjung-dong, Gunpo-si, Gyeonggi-do, 435-862 South Korea TEL : +82-31-459-8200 FAX : +82-31-459-8880 www.miniprinter.com MODEL : LK-P31 MOBILE PRINTER All specifications are subject to change without notice Rev. 1.0...

  • Page 2: Table Of Contents

    Table of Contents 1. Unpacking 2. Product overview 3. Usage and Installation 3-1. Control panel usage 3-2. Battery Installation 3-3. Battery removal 3-4. Battery charging 3-5. Battery charger usage 3-6. Roll paper installation 3-7. Printer Case Usage 3-8. Self test 4.

  • Page 3: Unpacking

    1. Unpacking 2. Product overview Standard Front Power switch Control Printer Panel Open Button Paper feed button Charger Battery USB Cable Shielded Rear USB / DC JACK Roll paper Quick Manual Optional Battery Case Usage Battery Holder (Cradle)

  • Page 4: Usage And Installation

    3. Usage and Installation 3-1 Control panel usage 3-2 Battery Installation Hook Button Name function This button is used to turn the printer on and off. Power When the printer is off, press this button for approximately 3 seconds button and it will turn on the power.

  • Page 5: Battery Removal

    3-4 Battery charging 3-3 Battery removal Lamp 1. Be sure that the printer is turned off After putting up the belt clip, remove the battery holding it up as shown above. 2. After open the DC JACK cover, insert DC JACK into the printer. 3.

  • Page 6: Battery Charger Usage

    3-5 Battery charger usage 3-6 Roll paper installation Optional Lamp DC Jack 1. Insert the battery into the battery holder as shown above Press the PUSH button to open Insert the paper in the right the paper cover direction 2. Connect the DC JACK to the power electrical outlet. 3.

  • Page 7: Printer Case Usage

    3-7 Printer Case Usage 3-8 Self Test Optional Turn off the power pressing the While you are pressing the FEED Put the printer into the case power button for approximately button, press the power button following the direction as shown 3 seconds.

  • Page 8: Peripherals Connection

    4. Peripherals connection This printer can communicate with Peripherals device via Bluetooth The sample of self test printout and cables. 4-1 Bluetooth Connection 1. Printer can be connected to the PDA and PC which can do wireless communication. When the printer is installed initially or when you face a problem, you can run the self test and check the information about 2.

  • Page 9: Interface Cable Connection

    5. Pritner Specification 4-2 Interface Cable Connection 5-1 Specification Printing Method Direct Thermal Printing Speed 60mm/sec Resolution 203 DPI X 203 DPI Character Font A (12X24), Font B (9X17) Character per line Font A : 48pt , Font B : 64pt Character set ALPHA NUMERIC Character, Extension Character...

  • Page 10: Certification

    6. Certification FCC Information Battery Battery type Li-ion output 7.4V, 1130mAh This device complies with part 15 of the FCC Results. Operation is subject to the following two conditions: Charging time 2~3hours (1) This Device may not cause harmful interface, and Size W X D X H(mm) 110 X 105 X 30...
