Installation Guide
Fix the Column (2) and the Column Connectors (3) to the Desktop Components (1) with 4x M6*10 Screws
(A) and 1x M4 Wrench (D). Connect the Adapter Cable (pre-assembled on the Desktop Components (1)
to the motor cable on the Column (2)). Plug the Power Cord (8) into the Adapter Cable.
1
Protect the desktop well to avoid any damages and scratches.
Insert the Extension Socket (4) to the Metal Tray (6) and pass the Metal Tray (6) through the Column (2).
Make sure two cables pass through the round hole on the Metal Tray (6). Fix the Metal Tray (6) to the
Desktop Components (1) with 1x M3 wrench (F) and 4x M5*14 screws (B).
Two cables need to pass through the Metal Tray (6) before screws are tightened.
Assemble the Column (2) and Feet (5) with 1x M4 wrench (D) and 4x M6*20 screws (C).
4
D
E
4
D
5
8
A
Adapter Cable
Motor Cable
C
B
