SmartDesk Commercial
A S S E M B L Y I N S T R U C T I O N S
I
I. Leg
J. Adapter
K. Keypad
L. Desk Top
M. Side Panel
N. Power cord
O. Adapter cable
P. Frame
Q. Foot
T o o l s n e e d e d :
3mm Allen wrench
4mm Allen wrench
(included)
I n c l u d e d i n t h e b o x e s
K
J
X2
X1
X1
X1
X2
X1
X1
X1
X2
Screwdriver
(included)
(not included)
L
M
N
O
P
Q
S c r e w s i n c l u d e d
( a c t u a l s i z e ) :
A
B
C
(1 pc)
(1 pc)
M6*10
(12 pcs)
F
(1 pc)
D
E1
E2
M6*35
ST5*16
ST3.5*16
(8 pcs)
(12 pcs)
(2 pcs)
G
H
(10 pcs)
(4 pcs)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartDesk Commercial and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Autonomous SmartDesk Commercial

Summary of Contents for Autonomous SmartDesk Commercial

  • Page 1 SmartDesk Commercial A S S E M B L Y I N S T R U C T I O N S I n c l u d e d i n t h e b o x e s S c r e w s i n c l u d e d I.
  • Page 2 I N S T R U C T I O N S F O R A S S E M B L Y 1. Loosen four screws (H) of the frame (P) with an 3mm Allen wrench (A), adjust the frame to the right position to fit the desk top (L), and then tighten the screws to fix it.
  • Page 3 4. Use M6 x 35mm screws (D) to attach the foot (Q) and leg (I) ×8 5. Use ST5 x 16mm screws (E1) to attach the whole frame to the desk top (L). ×12...
  • Page 4 6. Use ST3.5 x 16mm (E2) screws to attach the keypad (K) to the desk top (L). 7. Use Velcro (F) to attach the adaptor (J) with the desk top (L). Note: The length of the adapter cable is limited (8’’) and should not be too far from the keypad (K).
  • Page 5 5 seconds, when the keypad screen display "RST", release the button, press and hold the down button until the keypad screen displays the number. Congratulation, you are finished setup and your desk is ready to use. Designed by Autonomous...
  • Page 6 Do not place any objects underneath the desk that are taller than 25”. ABOUT Autonomous is a global network of innovators. We’re engineers who take apart your day, examine the pieces, and then reassemble your routine to help you #worksmarter. Our sole focus is towards realizing the gold standard of the smart office industry.
