RMC 48
Operator's & Parts Manual
P.T.O.
Model No. 914800-0435.03
RENN
Mill Center LP.
R.R. #4
Lacombe, Alberta, Canada
T4L 2N4
Phone: (403) 784-3518
Fax : (403) 784-2060
Email : rennmill@rennmill.com
www.rennmill.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RENN RMC 48 and is the answer not in the manual?

Questions and answers

Related Manuals for Degelman RENN RMC 48

Summary of Contents for Degelman RENN RMC 48

  • Page 1 RMC 48 Operator’s & Parts Manual P.T.O. Model No. 914800-0435.03 RENN Mill Center LP. R.R. #4 Lacombe, Alberta, Canada T4L 2N4 Phone: (403) 784-3518 Fax : (403) 784-2060 Email : rennmill@rennmill.com www.rennmill.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of Contents ................... 1.1 Introduction ....................1.3 Renn Warranty Policy ................. 1.4 Mill Serial Number Location ..............1.5 2 Safety ......................2.1 2.1 General Safety ..................2.2 2.2 Operating Safety ................2.3 2.3 Maintenance Safety ................2.3 2.4 Hydraulic Safety ................

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 9 Troubleshooting Guide ..............9.1 10 Specifications ................10.1 10.1 General Specifications ..............10.1 10.2 Tire Specifications ................. 10.1 10.3 Bolt Torque Specifications ............10.1 10.4 Overall Dimensions ................ 10.3 11 Parts ....................11.1 11.1 Top Hopper ..................11.1 11.1.1 Top Hopper (Knob) ............

  • Page 4: Introduction

    INTRODUCTION Congratulations on your decision to purchase a Renn Roller Mill. This machine has been designed to provide you with the highest standards of quality, reliability and durability. This manual has been prepared to familiarize you with the opera- tion and maintenance of your mill. We urge you to read the publication carefully and refer to it extensively for correct operating procedure.
  • Page 5 LIMITED WARRANTY • • NEW EQUIPMENT WARRANTY WHAT YOU MUST DO TO ENFORCE THIS WARRANTY Subject to the limitations and exclusions set out herein, RENN Mill Center LP. Warranty services must be performed by a dealer authorized by Renn. (“Renn”) warrants that if any component or part of a machine manufactured by The purchaser must , at the purchaser’s expense, deliver, mail or ship Renn proves to be defective in material or workmanship within the defective part to any duly authorized dealer in the purchasers area.
  • Page 6 SERIAL NUMBER LOCATION The serial number plate is located on the inside face of the back panel of the top hopper, on the driver’s side of the machine. IMPORTANT: For fast, correct service when ordering parts, supply the following information to your local Renn Dealer: 1) The model number 2) The serial number This information is essential when order-...

  • Page 7: Safety

    2 SAFETY Safety Alert Symbol This Safety Alert symbol The Safety Alert symbol identifies important means safety messages on the Renn Mill and in the manual. When you see this symbol, be alert to the possibility of ATTENTION! personal injury or death. Follow the BE ALERT! instructions in the safety message.

  • Page 8: General Safety

    2 SAFETY You are responsible for the SAFE operation and maintenance of your Renn Roller Mill. YOU must ensure that you and anyone else who is going to operate, maintain or work around the mill be familiar with the operating and maintenance procedures and related SAFETY information contained in this manual.

  • Page 9: Operating Safety

    2 SAFETY 2.2 Operating Safety 1. Read and understand the Operator’s Manual and all safety signs before using the machine. 2. Keep hands, feet, hair and clothing away from all moving and/or rotating parts. 3. Do not allow riders on the mill or tractor during operation or transportation. 4.

  • Page 10: Hydraulic Safety

    2 SAFETY 2.4 Hydraulic Safety 1. Always place all tractor hydraulic controls in neutral before dismounting. 2. Make sure that all components in the hydraulic system are kept in good condition and replace any worn, cut, abraded, flattened or crimped hoses. 3.

  • Page 11: Safety Shield Placement

    2 SAFETY 2.7 Safety Shield Placement After servicing or maintenance, these shields should be back in place. PTO/Front Bearing and Cam Shield Inspection Plate & gearbox door Rear Shield Transfer Auger shield and mesh PTO: Front and Rear Covers Transfer auger gearbox shield - 2.5 -...

  • Page 12: Sign-Off Form

    2 SAFETY 2.8 Sign-off Form Make these periodic reviews of SAFETY Anyone operating and/or maintaining the and OPERATION a standard practice for all mill must read and clearly understand ALL of your equipment. We feel that an untrained of the Safety, Operating, and Maintenance operator is unqualified to operate this ma- information presented in this manual.
  • Page 13 PAGE INTENTIONALLY LEFT BLANK...

  • Page 14: Decal Locations

    3 DECAL LOCATIONS 3.1 Safety Decal Locations The types of safety decals and locations on the equipment are shown in the following illustra- tions. Good safety requires that you familiarize yourself with the various safety decals, the type of warning and the area, or particular function related to that area, that requires your SAFETY AWARENESS.
  • Page 15 3 DECAL LOCATIONS 3.1 Safety Decal Locations - 3.2 -...

  • Page 16: Information Decal Locations

    3 DECAL LOCATIONS 3.2 Information Decal Locations The types of informational and operational decals and locations on the equipment are shown in the following illustrations. Good operation requires that you famil- iarize yourself with the various operational decals, the type of warning and the ar- ea, or particular function related to that area, that requires your AWARENESS.
  • Page 17 3 DECAL LOCATIONS 3.2 Information Decal Locations - 3.4 -...

  • Page 18: Operation

    4 OPERATION 4.1 To the New Operator or Owner The Renn Mill is designed to receive dry grain from an auger, process it, and deposit it via the discharge auger. Be familiar with the machine before starting. In addition to the design and configuration of equipment, hazard control and accident preven- tion are dependent upon the awareness, concern, and prudence of personnel involved in the op- eration, transportation, maintenance and storage of equipment and in the use and maintenance of facilities.

  • Page 19: Setting Up The Roller Mill

    4 OPERATION Setting up the Roller Mill 4.4.1 Roll Setting Figure 4.1 Figure 4.2 Loosen the wing nuts holding down the top hopper (Figure 4.2) and tip it over center, rotating on the hinge pin until it hits the stoppers. If using flat rolls to roll dry grain, set the rolls a very small distance apart.

  • Page 20: Roll Gap Adjustment

    4 OPERATION 4.4.2 Roll Gap Adjustment The cam control ( Figure 4.4) serves as a mechanism to make roll gap adjustments accurately and quickly using a 3/4” wrench or socket. The cam positional indicator is set at the factory to the “1”...

  • Page 21: Feed Gate Control

    4 OPERATION 4.4.3 Feed Gate Control Set the friction knob (Figure 4.6) so that it supports the weight of the feed gate and yet allows the gate to be opened and closed by hand. Note that the setting of the feed gate helps to spread the feeding of grain evenly across the face of the roll.

  • Page 22: Roll Drive Belt Tension

    4 OPERATION 4.4.6 Roll Drive Belt Tension To increase belt tension, loosen the jam nut and turn the tensioning bolt until approximately 15lbs of force at the center of the longest belt span causes a 3/8” deflection. Reset the jam nut to lock the adjustment bolt in place.

  • Page 23: Transfer Auger Set Up

    4 OPERATION 4.4.9 Transfer Auger Set Up A) Remove the top or bottom lynch pin on the auger rest holding the transfer auger to the mill trailer (Figure 4.12). B) Slide the auger retaining rod off the auger rest (Figure 4.13). Figure 4.12 Figure 4.13 Once the retainer ring is removed, swing the auger out of the auger rest and use the hydrau-...

  • Page 24: Discharge Auger Set Up

    4 OPERATION Use the hydraulic controls to unfold the transfer auger into the working position. Use the over center latch and safety pin to secure the two sections together. Figure 4.16 Note: When setting up the auger, use the hydraulics in a slow and steady manner, watching for any components that can get caught in between and damaged while swinging into position.
  • Page 25 4 OPERATION B) When unfolding the auger, check if the locking mechanism (Figure 4.19) or anything else is in the way. C) Upon completion of unfolding the auger, use the catch assembly to clamp the auger in posi- tion (Figure 4.20) Unlocked position Locked position Figure 4.19...

  • Page 26: Hose Hanger

    4 OPERATION E) Hold the transport lock up along the discharge auger tube, lining up the holes in the middle of the transport lock with the tabs on the discharge auger tube (Figure 4.23). F) Insert the lock pin and lynch pin to secure the cylinder lock to the auger tube (Figure 4.24). The angle of the discharge auger can now be adjusted using the hydraulics.

  • Page 27: Operating The Roller Mill

    4 OPERATION C) Hang the hoses on the hanger. D) Place the lock plate and the pin back on. 4.5 Operating the Roller Mill 1. Make sure to read and understand all of the safety items in Section 2. 2. Ensure that the feed gate is closed (Figure 4.6) before starting the mill. Even a few grains will keep the rolls from turning.

  • Page 28: Roller Mill Break-In

    4 OPERATION 4.6 Roller Mill Break-in It is recommended that the mill be run at moderate to full operational speed and at 1/2 to 2/3 capacity during the first hour of operation. This allows the frictional forces to diminish signifi- cantly within the auger tube, and allows the free flow of grain to approach acceptable levels in the system.

  • Page 29: Service And Maintenance

    5 SERVICE AND MAINTENANCE 5.1 Servicing Record See the Lubrication and Maintenance sections for details of service. Copy this page to con- tinue record. ACTION CODE: CL…….CLEAN T……...TIGHTEN L……….LUBRICATE CH…….CHECK Hours Serviced MAINTENANCE 8 Hours of Driveline Use U-Joint - PTO Main Bearings - Rolls Cross Auger Bearing Discharge Auger Bearing...

  • Page 30: Servicing Intervals

    5 SERVICE AND MAINTENANCE 5.2 Servicing Intervals Grease Use an S.A.E. multi-purpose high temperature grease with extreme pressure (EP) performance. An S.A.E. multi-purpose lithium base grease is also acceptable. Use the Maintenance Checklist provided to keep a record of all scheduled maintenance. 1.
  • Page 31 5 SERVICE AND MAINTENANCE 5.2 Servicing Intervals (Cont’d) Cam adjuster bearings (grease lightly Jack: grease zerk every 50 hours) (once per season) Wheel hub, grease zerk and torque bolts (once per season) Discharge Auger (Check every 50hrs, replace every 200hrs) For discharge gearbox oil level check - 1.

  • Page 32: Removal Of Rolls For Servicing

    5 SERVICE AND MAINTENANCE 5.3 Removal Of Rolls For Servicing 1. With the power disconnected, loosen the jam nuts on each of the spring push bolts and re- lieve all pressure from the spring (see section 4.4.8). 2. Relieve the tension on the roll drive belts and remove. 3.

  • Page 33: Pdi Setup

    6 PDI SETUP Your Renn Roller Mill is shipped fully assembled. Take all necessary precautions when moving and operating the equipment. Note: • Practice proper safety procedures when lifting heavy objects. • All hoses should be on the hose hanger when not in use. NOTE: Do not grease the Over Running Clutch when you receive the Mill as they are already greased at the factory.

  • Page 34: Transportation

    7 TRANSPORTATION 1. Check with local authorities regarding mill transportation on public roads. Obey all appli- cable laws and regulations. 2. Always travel at a safe speed. Use caution when going around corners or meeting traffic. 3. Make sure an SMV (Slow Moving Vehicle) emblem and all the lights and reflectors that are required by local highway and transportation authorities are in place, are clean and can be seen clearly by all overtaking and oncoming traffic.

  • Page 35: Storage

    8 STORAGE 8.1 Placing in Storage At the end of the operating season, the machine should be thoroughly inspected and prepared for storage. Repair or replace any worn or damaged components to prevent any unnecessary down time at the beginning of the next season. Follow this procedure: 1.

  • Page 36: Troubleshooting Guide

    9 TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Whole grain in sample Wear plate not adjusted. With power disconnected & rolls not rotating, use a 3/4” wrench to loosen the jam nut on the wear plate adjust- er. Adjust the wear plates in so that there is minimal clearance between the end of the rolls &...
  • Page 37 9 TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Wear plates and poly ‘V’, roll Grain smaller than the space Need finer groove pattern. gap & spring pressure set between the grooves. properly, still whole grain in Rolls need re-grooving or are sample no longer true (badly worn).

  • Page 38: Specifications

    10 SPECIFICATIONS 10.1 General Specifications Weight ..........................8305 lbs Minimum Tractor Horsepower ................120 hp - PTO Auger Discharge Size....................12” x 12’ Transfer Auger Size..................... 12” x 12’ Machine Capacity.………………………………………………….………...up to 4000 bu/hr (dry corn)* *Capacity will change with moisture content, roll configuration and particle size desired. 10.2 Tire Specifications Tire/Rim ..................
  • Page 39 10 SPECIFICATIONS - 10.2 -...

  • Page 40: Overall Dimensions

    10 SPECIFICATIONS 10.4 Overall Dimensions 10.4.1 Working Mode - 10.3 -...
  • Page 41 10 SPECIFICATIONS 10.4 Overall Dimensions 10.4.2 Transport Mode - 10.4 -...

  • Page 42: Top Hopper

    11 PARTS 11.1 Top Hopper REF # PART # DECRIPTION 614800-0041.00 Grate Magnet - 48" RM (Large Grain) 170000-0180 Cotter Pin - 3/16" x 1" 614800-0008.00 Hinge Pin - Top Hopper 414800-0520.00 Top Hopper Grain Containment Belt 167200-0648 Nyloc Nut - 5/16" NC Gr.5 PL 168000-0040 Flat Washer - 5/16"...
  • Page 43 11 PARTS 11.1 Top Hopper - 11.2 -...

  • Page 44: Top Hopper (Knob)

    11 PARTS 11.1.1 Top Hopper (Knob) REF # PART # DECRIPTION 168000-0049 Flat Washer - 3/8" USS PL 163000-0506 Carriage Bolt 3/8" NC x 3/4" Gr.5 PL 168000-0540 Flat Washer - 3/8" SAE 167200-0412 Lock Nut - 3/8" NC 140000-0224 Lock Knob 168600-0071 Lock Washer - 3/8"...
  • Page 45 PAGE INTENTIONALLY LEFT BLANK...

  • Page 46: Roller Mill - Upper Half

    11 PARTS 11.2 Roller Mill - Upper Half REF # PART # DECRIPTION 168000-0544 Flat Washer - 1/2" SAE PLTD 167100-0995 Wing Nut 1/2" NC 615100-0765.00 Brg Hold-Down Bracket - Mill Frame - 2020 159400-0427 Hex Bolt - 1/2" NC x 2" Gr.5 PL 168600-0098 Lock Washer - 1/2"...
  • Page 47 11 PARTS 11.2 Roller Mill - Upper Half - 11.5 -...

  • Page 48: Worm Drive Roll Adjustment

    11 PARTS 11.3 Worm Drive Roll Adjustment REF # PART # DECRIPTION 159400-0636 Hex Bolt - 5/8" NC x 2-1/2" Gr.5 PL 168000-0580 Flat Washer - 5/8" SAE PL 167200-0690 Nyloc Nut - 5/8" NC Gr.5 PL 159400-0580 Hex Bolt - 5/8" NC x 1" GR5 PL 168600-0120 Lock Washer - 5/8"...
  • Page 49 11 PARTS 11.3 Worm Drive Roll Adjustment 168600-0071 Lock Washer - 3/8" PL 615100-0527.00 Bearing Cam Base 414000-0239.00 Cam Pivot Pin - 1" x 2-1/2" 113500-0126 Oilite Bushing - 1" x 1-1/4" x 1" 615100-0705.02 Pivot Eye Rod 615100-0704.02 Main Adjuster Arm - 11.7 -...

  • Page 50: Roll Drive - Front

    11 PARTS 11.4 Roll Drive - Front REF # PART # DECRIPTION 144000-0685 Double V-Belt - BB85 414000-0653.02 Spacer Plate 114100-0021 1-1/4" Bearing - Cylindrical 72mm OD 124000-0016 5" x 72mm 3-Groove Pulley 143300-0097 Pulley - 3 Groove 9.75" x SF Bushing 124000-0095 9.75"...
  • Page 51 11 PARTS 11.4 Roll Drive - Front - 11.9 -...

  • Page 52: Roll Drive - Rear

    11 PARTS 11.5 Roll Drive - Rear REF # PART # DECRIPTION 144000-0685 Double V-Belt - BB85 414000-0653.02 Spacer Plate 114100-0021 1-1/4" Bearing - Cylindrical 72mm OD 124000-0016 5" x 72mm 3-Groove Pulley 143300-0097 Pulley - 3 Groove 9.75" x SF Bushing 124000-0095 9.75"...
  • Page 53 11 PARTS 11.5 Roll Drive - Rear - 11.11 -...

  • Page 54: Pulley Tensioner Assembly

    11 PARTS 11.6 Pulley Tensioner Assembly REF # PART # DECRIPTION 415400-0015.00 0.75" Spacer Bar - Idler Assembly 412400-0518.04 1/2" Spacer - Idler Tensioner 163100-0145 Carriage Bolt - 3/4" NC x 4-1/2" Gr.5 PL 168000-0080 Flat Washer - 5/8" USS PL 167200-0690 Nyloc Nut - 5/8"...

  • Page 55: Bottom Hopper

    11 PARTS 11.7 Bottom Hopper REF # PART # DECRIPTION 614800-0518.00 Rear Panel Weldment - 12" 159400-0401 Hex Bolt - 1/2" NC x 1-1/2" Gr.5 PL 167200-0688 Nyloc Nut - 1/2" NC Gr.5 PL 674800-0024.00 Strut Assembly - 48" 167200-0652 Nyloc Nut - 3/8"...

  • Page 56: Cross Auger Assembly

    11 PARTS 11.8 Cross Auger Assembly REF # PART # DECRIPTION 670000-0131.00 Transition Tube - Cross Auger - 12" 167200-0652 Nyloc Nut - 3/8" NC Gr.5 PL 159300-0961 Hex Bolt - 3/8" NC x 1" Gr.5 PL 674800-0064.00 12" Cross Auger - 90deg Gbx - Non-diff 674800-0098.00 1-1/4"...
  • Page 57 11 PARTS 11.8 Cross Auger Assembly - 11.15 -...

  • Page 58: Hitch Assembly

    11 PARTS 11.9 Hitch Assembly REF # PART # DECRIPTION 614800-0586.00 SAC Spec, 48" 1:1 Drive Non-aux, Mech w/ Hyd Tilt - HD 341100-0050 Jack - 7000lb x 10" - Side Wind 159400-0628 Hex Bolt - 5/8" NC x 2" Gr.5 168000-0580 Flat Washer - 5/8"...
  • Page 59 11 PARTS 11.9 Hitch Assembly - 11.17 -...

  • Page 60: Trailer Assembly

    11 PARTS 11.10 Trailer Assembly REF # PART # DECRIPTION 614800-0586.00 SAC Spec, 48" 1:1 Drive Non-aux , Mech w/ Hyd Tilt - HD 480100-0722.01 Hose Clamp 167200-0652 Nyloc Nut - 3/8" NC Gr.5 PL 614800-0516.00 Bushing Bolt Plate - 14" Discharge Auger 159400-0427 Hex Bolt - 1/2"...
  • Page 61 11 PARTS 11.10 Trailer Assembly - 11.19 -...
  • Page 62 11 PARTS 11.10.1 Hub Assembly (340800-0615) REF # PART # DECRIPTION 340100-0016 Grease Seal - SE-16 114500-0135 Inner Cone - LM-603049 115000-0026 Inner Cup - LM-603011 340000-0614 614 Hub 340300-0012 Wheel Bolt - 9/16" - 18 NF x 1-1/4" 115000-0027 Outer Cup - LM-48510 114500-0022 Outer Cone - LM-48548...

  • Page 63: Discharge Auger

    11 PARTS 11.11 Discharge Auger 11.11.1 Discharge Auger - Upper Assembly REF # PART # DECRIPTION 167200-0688 Nyloc Nut - 1/2" NC Gr.5 PL 168000-0544 Flat Washer - 1/2" SAE PLTD 671300-0465.00 Floating Bearing Mount - 10" 172200-0792 Spring Pin - 5/16" x 3" 303100-0124 Compression Spring - 1.125"...
  • Page 64 11 PARTS 11.11.2 Discharge Auger - Gear Box REF # PART # DECRIPTION 155500-0140 14" Band Clamp 159300-0961 Hex Bolt - 3/8" NC x 1" Gr.5 PL 167200-0652 Nyloc Nut - 3/8" NC Gr.5 PL 671300-0063.00 Clean out Door Weldment - HD - 14" Discharge 159400-0395 Hex Bolt - 1/2"...
  • Page 65 11 PARTS 11.11.2 Discharge Auger - Gear Box - 11.23 -...
  • Page 66 11 PARTS 11.11.3 Discharge Auger - Lower Assembly REF # PART # DECRIPTION 167200-0652 Nyloc Nut - 3/8" NC Gr.5 PL 480100-0722.01 Hose Clamp 671300-0600.00 Discharge Auger Tube - Lower - 12" Turbo Folding 159300-0792 Hex Bolt - 5/16" x 2" Gr5 PL 167200-0648 Nyloc Nut - 5/16"...
  • Page 67 11 PARTS 11.11.3 Discharge Auger - Lower Assembly - 11.25 -...

  • Page 68: Transfer Auger

    11 PARTS 11.12 Transfer Auger 11.12.1 Transfer Auger - Upper Assembly REF # PART # DECRIPTION 167200-0688 Nyloc Nut - 1/2" NC Gr.5 PL 167200-0690 Nyloc Nut - 5/8" NC Gr.5 PL 168000-0080 Flat Washer - 5/8" USS PL 159400-0427 Hex Bolt - 1/2"...
  • Page 69 11 PARTS 11.12.1 Transfer Auger - Upper Assembly - 11.27 -...
  • Page 70 11 PARTS 11.12.2 Transfer Auger - Lift & Swing Pedestal REF # PART # DECRIPTION 167200-0694 Nyloc Nut - 1" NC Gr.5 PL 168000-0139 Flat Washer - 1" USS PL 670000-0523.00 Tee Post - Lift and Swing 133200-0040 Grease Nipple - 1/8" NPT 167200-0652 Nyloc Nut - 3/8"...
  • Page 71 11 PARTS 11.12.2 Transfer Auger - Lift & Swing Pedestal - 11.29 -...
  • Page 72 11 PARTS 11.12.3 Transfer Auger - Fold REF # PART # DECRIPTION 113200-0030 Split Spring Bushing - 1" x 1" 107200-0539 4 x 14Cylinder 107000-0103 Cylinder Pin - 1" Dia x 3" 613600-0592.00 Pivot Weldment 413600-0700.00 Cross Pin - 6" 167200-0648 Nyloc Nut - 5/16"...
  • Page 73 11 PARTS 11.12.3 Transfer Auger - Fold 303100-0207 Comp. Spring .25W x 1.938" OD x 1.438" ID x 6" Long 168600-0098 Lock Washer - 1/2" PL 781200-0538.00 Grease Port Bolt 671300-0412.00 Auger Support Assembly - Mid 671300-0411.01 Pilot pin weldment 480200-0792.00 Oilite Bushing - 1-15/16"...
  • Page 74 11 PARTS 11.12.4 Transfer Auger - Hopper Body REF # PART # DECRIPTION 671300-0525.01 Transfer Auger Tube - Bottom - SAC WF Folding 671300-0511.01 Hopper / Auger Transition Weldment 167200-0690 Nyloc Nut - 5/8" NC Gr.5 PL 159400-0594 Hex Bolt - 5/8" NC x 1-1/2" Gr.5 PL 671300-0669.00 Interior Tire Pin - 3/4"...
  • Page 75 11 PARTS 11.12.4 Transfer Auger - Hopper Body - 11.33 -...
  • Page 76 11 PARTS 11.12.5 Transfer Auger - Bottom End REF # PART # DECRIPTION 471300-1203.00 Center Drive Shaft 128800-0515 5020 Plate Sprocket 129000-0510 Sprocket - 15 Tooth #50 x 1" 671300-0629.00 Hopper Auger 7 x 5 x 62" LH 167200-0690 Nyloc Nut - 5/8" NC Gr.5 PL 168000-0080 Flat Washer - 5/8"...
  • Page 77 11 PARTS 11.12.6 Transfer Auger - Transition REF # PART # DECRIPTION 160200-0805 Docket Set Screw - 3/8" x 3/8' NC 471300-1296.00 End Yoke - Series 6 - Added Tapped Hole 90° 380000-0006 End Yoke Cross - 6R 159300-0961 Hex Bolt - 3/8" NC x 1" Gr.5 PL 167200-0652 Nyloc Nut - 3/8"...

  • Page 78: Hydraulic Control Valve

    11 PARTS 11.13 Hydraulic Control Valve REF # PART # DECRIPTION H50000-0074 HYD HOSE 2WB THIN COVER 1/2" X 118" 104000-0610 Hydraulic - Q/C Male Poppet 1/2" FNPT 071000-0808 Hose End - 1/2" Dia x 1/2" MNPT H50000-0073 HYD HOSE 2WB THIN COVER 1/2" X 113" 073600-0808 Hose End - 1/2"Dia x # 8 JICF-sw 082400-0808...
  • Page 79 11 PARTS 11.13 Hydraulic Control Valve - 11.37 -...

  • Page 80: Transfer Auger Hydraulics

    11 PARTS 11.14 Transfer Auger Hydraulics 11.14.1 Transfer Auger Hydraulics - Lift REF # PART # DECRIPTION 107700-0020 3" Bore x 10" Storke Hyd Cylinder 086800-0808 Elbow 90deg sw #8 JICM x #8 ORB 073600-0608 Hose End - 3/8"Dia x # 8 JICF-sw H37500-0260 Hyd Hose 2WB Thin Cover 3/8"...
  • Page 81 11 PARTS 11.14.2 Transfer Auger Hydraulics - Fold REF # PART # DECRIPTION 107200-0539 4 x 14Cylinder 086800-0808 90° Elbow - #8 ORB x #8 JICM-sw 073600-0608 Hose End 3/8"Dia x # 8 JICFsw H37500-0262 Hyd Hose 2WB Thin Cover 3/8" X 89" H37500-0261 Hyd Hose 2WB Thin Cover 3/8"...
  • Page 82 11 PARTS 11.14.3 Transfer Auger Hydraulics - Drive REF # PART # DECRIPTION 111200-0026 Hydraulic Motor - 2000 Series 9.6cu.in. ORB 086400-0820 Hex Nipple - #10 ORBM x #12 JICM 073800-0912 Hose End - 3/4" Dia x #12 90JICFsw H75000-0223 HYD HOSE 2WB THIN COVER 3/4"...
  • Page 83 11 PARTS 11.14.3 Transfer Auger Hydraulics - Drive - 11.41 -...

  • Page 84: Discharge Auger Hydraulics

    11 PARTS 11.15 Discharge Auger Hydraulics 11.15.1 Discharge Auger Hydraulics - Tilt REF # PART # DECRIPTION 110100-0416 Spool Valve - Q25 4 Bank 081000-0100 Orifice Adapter - #6 ORBM to #6 JICM x.062" 071000-0607 Hose End - 3/8" Dia x #6 JICF-sw 90° Long 086400-0606 Hex Nipple - #6 JICM x #6 ORBM 073800-0606...
  • Page 85 11 PARTS 11.15.1 Discharge Auger Hydraulics - Tilt - 11.43 -...
  • Page 86 11 PARTS 11.15.2 Discharge Auger Hydraulics - Fold REF # PART # DECRIPTION 107700-0021 3" Bore x 14" Storke Hyd Cylinder 086800-0808 90° Elbow - #8 ORB x #8 JICM-sw 073600-0608 Hose End - 3/8"Dia x # 8 JICF-sw H37500-0264 Hyd Hose 2WB Thin Cover 3/8"...

  • Page 87: Hose Hanger

    11 PARTS 11.16 Hose Hanger & Cable Clamp REF # PART # DECRIPTION 161500-0498 Quick Pin, 3/8" x 1-5/8" 414000-1023.00 Lock Plate - Hose Hanger - 2 Sets 614000-0321.00 Hose Hanger - Vertical Mount - 2 Sets 670000-0212.00 Hydraulic Control Mounting Bracket - 4 Spool 159300-0961 Hex Bolt - 3/8"...

  • Page 88: Roll Bushing Assembly - B-Loc Bushing

    11 PARTS 11.17 Roll Bushing Assembly - B-Loc Bushing [ #2 ] [ #1 ] [ #3 ] Tightening Roll Size B-Loc B-Loc Hub Socket Head Cap Screw Torque Dia. x Length Spacer Ring Part # & I/D (QTY) & Size (ft-lbs) &...
  • Page 89 Notes - 12.1 -...
  • Page 90 Printed in Canada RENN MILL CENTER LP. RR#4, Lacombe, AB, T4L 2N4, Canada | P. 403.784.3518 | F 403.784.2060 | rennmill@rennmill.com | rennmill.com...
