A
Connect Hydraulics
FLOAT Transport
Cylinders
5
JACK
3
FLOAT
2
1
(Tractor controls and arrangement will vary )
B
Put in Field Position
1"
C
Set Cutting Depth
* Quick-Start Guide is for reference purposes only. Refer to operators manual for complete safety and operation information before operating.
QUICK-START GUIDE
TRANSPORT
4
5
(if available)
4
FLOAT
1"
*
3
WINGS
2
ROLLERS
1
WHEELS
FLOAT Wing
Cylinders
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Degelman PRO-TILL Series
Summary of Contents for Degelman PRO-TILL Series
- Page 1 QUICK-START GUIDE Connect Hydraulics FLOAT Transport Cylinders TRANSPORT JACK WINGS FLOAT Wing Cylinders ROLLERS FLOAT WHEELS (if available) FLOAT (Tractor controls and arrangement will vary ) Put in Field Position 1” 1” Set Cutting Depth * Quick-Start Guide is for reference purposes only. Refer to operators manual for complete safety and operation information before operating.
- Page 2 Wing Cylinders & Transport Cylinders into FLOAT. FLOAT Transport FLOAT Wing Cylinders Cylinders Test. Check. Adjust. 10-12 MPH 100m 100m Lower Wheels for Headland Turns. Transport Information Put into Transport Position Ensure Rollers are Properly Positioned MAX Transport Speed Transport Dimensions Height - 4m (13 ft) Width - 6m (20 ft) 40-50 km/h (25-30 MPH)
