2.1. Installation Environment of PC

This manual describes how to operate User Program(GUI) for Ezi-SERVO Plus-R. For more
information, refer related manuals.
(1) User Manual-Text
(2) User Manual-Communication Function
(3) User Manual-Position Table Function

2. Installation and Connection of the Program

2.1 Installation Environment of PC
Ezi-SERVO Plus-R consists of two operation modes as follows:
1) Using Motion Library(DLL) provided for the program from Windows 2000/XP/WINDOW7.
2) Using Position Table(PT) and external signals input by the user.
For the operation modes above, refer to each related manual.
This chapter describes the user program used for installation and running test of the controller. Ezi-
SERVO Plus-R is associated with RS-485. So, the user needs to convert RS-232C or USB for the
PC into RS-485.
2.2

Program Version

There are 2 kinds of program version for Ezi-SERVO Plus-R.
1) Firmware program in drive :
After connect the User Program(GUI),
version number can be check in 'Board List'
Window.
2) User Program(GUI) in PC :
After connect the User Program(GUI), version number can be
check in 'About Plus-R GUI...'menu in 'Help' menu.
